No matter which country or region you are in, our SD-WAN-Engineer exam questions can provide you with thoughtful services to help you pass exam successfully for our SD-WAN-Engineer study materials are global and warmly praised by the loyal customers all over the world. They have many advantages, and if you want to know or try them before your payment, you can find the free demos of our SD-WAN-Engineer learning guide on our website, you can free download them to check the excellent quality.
| Section | Weight | Objectives |
|---|---|---|
| Topic 1: Operations and Monitoring | 38% | - Monitoring and Troubleshooting
|
| Topic 2: Deployment and Configuration | 38% | - Prisma SD-WAN Deployment
|
| Topic 3: Planning and Design | 24% | - Architecture Design
|
>> Reliable SD-WAN-Engineer Exam Testking <<
We have authoritative production team made up by thousands of experts helping you get hang of our SD-WAN-Engineer study question and enjoy the high quality study experience. We will update the content of SD-WAN-Engineer test guide from time to time according to recent changes of examination outline and current policy. Besides, our SD-WAN-Engineer Exam Questions can help you optimize your learning method by simplifying obscure concepts so that you can master better. Furthermore with our SD-WAN-Engineer test guide, there is no doubt that you can cut down your preparing time in 20-30 hours of practice before you take the exam.
NEW QUESTION # 84
A remote branch site is reporting intermittent connectivity to the Data Center. The administrator checks the System > Alarms page and sees a "VPN_DOWN" alarm for the tunnel to the DC. However, the internet circuit status is "Up".
Which specific log file or diagnostic tool in the Prisma SD-WAN portal would provide the IKE (Internet Key Exchange) error codes (e.g., "NO_PROPOSAL_CHOSEN" or "AUTH_FAILED") to pinpoint the cause of the tunnel failure?
Answer: B
Explanation:
Comprehensive and Detailed Explanation
To diagnose specific VPN negotiation failures (Phase 1 or Phase 2 IPSec issues), the Event Logs (specifically filtered for System or VPN events) are the correct resource.
Event Logs: This section records the control plane signaling messages. If a VPN tunnel fails to establish, the Event Log will generate an entry containing the specific IKE failure reason sent by the peer or generated locally. Common errors found here include INVALID_COOKIE, NO_PROPOSAL_CHOSEN (mismatch in encryption algorithms), or PRE_SHARED_KEY_MISMATCH.
Flow Browser (A): This shows user traffic (TCP/UDP sessions). If the VPN is down, user traffic won't even enter the tunnel, so the Flow Browser will just show dropped flows or blackholes, but it won't explain why the tunnel itself is broken.
Link Quality (D): This shows latency/loss graphs for established tunnels. It cannot diagnose why a tunnel failed to form in the first place.
NEW QUESTION # 85
An administrator has configured a Path Policy for "ERP_Traffic". The policy allows two public internet links, "ISP-A" and "ISP-B", both marked as "Active". The Path Quality Profile (SLA) requires a latency of less than 150ms. Currently, both ISP-A and ISP-B have a latency of 40ms, well within the SLA.
How does the Prisma SD-WAN ION determine which link to use for a new flow of "ERP_Traffic" when both active paths meet the SLA requirements?
Answer: A
Explanation:
Comprehensive and Detailed Explanation
Prisma SD-WAN utilizes a sophisticated decision engine for Application-Based Path Selection that goes beyond simple failover. When configuring a Path Policy, the administrator defines "Active" paths and a "Path Quality Profile" (SLA).
SLA Compliance (The Filter): First, the system filters the available paths based on the Path Quality Profile. In this scenario, both ISP-A and ISP-B have 40ms latency against a 150ms threshold. Both are "green" or compliant paths.
Selection Criteria (The Tie-Breaker): When multiple paths are configured as "Active" and all meet the performance SLA, the ION device aims to optimize the overall user experience and network utilization. The default behavior for load balancing across healthy, compliant active paths is to select the path with the highest available bandwidth capacity.
By steering new flows to the link with the most "headroom" (available Mbps), the system prevents the saturation of a smaller link (e.g., a 20Mbps DSL line) while a larger link (e.g., 1Gbps Fiber) sits underutilized. This maximizes the aggregate throughput for the site. While latency is the qualifier, bandwidth availability is often the selector for compliant paths. Note that if the application was defined as "Real-Time" and configured for packet duplication, behavior would differ, but for standard traffic, capacity-based distribution is the standard active/active logic.
NEW QUESTION # 86
An administrator needs to ensure that critical VoIP traffic is not dropped even when the branch's primary internet link is fully saturated with bulk file transfers.
Which QoS mechanism does Prisma SD-WAN automatically apply to the "Platinum" priority class to prevent starvation by lower-priority classes?
Answer: C
Explanation:
Comprehensive and Detailed Explanation
Prisma SD-WAN utilizes a hierarchical QoS model (typically based on Hierarchical Token Bucket or similar shaping algorithms) to manage bandwidth contention.
Guaranteed Bandwidth: The "Platinum" class (used for Real-Time voice/video) is assigned a guaranteed bandwidth percentage (floor) in the QoS profile. This ensures that even if "Gold" (Transactional) or "Silver" (Bulk) traffic is trying to consume 100% of the link, the scheduler reserves the specific portion (e.g., 30%) for Platinum traffic, preventing starvation.
Shaping, not Policing: Unlike simple policing which drops excess traffic hard, the ION device shapes the egress traffic. If the link is congested, the scheduler delays the lower-priority packets (buffering) to allow the high-priority Platinum packets to exit immediately.
Why not Strict Priority (A)? While Platinum behaves like a priority queue, pure Strict Priority can completely starve lower queues if the high-priority traffic is misbehaving or voluminous. Prisma SD-WAN typically uses bandwidth guarantees (floors) and limits (ceilings) to ensure fair sharing while protecting critical apps.
NEW QUESTION # 87
Based on the HA topology image below, which two statements describe the end-state when power is removed from the ION 1200-S labeled "Active", assuming that the ION labeled "Standby" becomes the active ION?
(Choose two.)
Answer: A,C
Explanation:
Comprehensive and Detailed Explanation
This scenario depicts a High Availability (HA) topology utilizing the ION 1200-S model's Fail-to-Wire (bypass) capabilities to share WAN links between two devices without needing external switches for every WAN connection.
1. WAN Link Availability (Statement A):
The diagram illustrates a "daisy-chain" cabling method supported by the ION 1200-S bypass pairs.
* ISP A (Green): Connects directly to the "Standby" (Left) unit first. Since the Standby unit remains powered on, it maintains direct access to ISP A.
* LTE/5G (Blue): Connects to the "Active" (Right) unit first. The connection then loops through a bypass pair on the Active unit to the Standby unit. When power is removed from the "Active" unit, the fail-to-wire relays on its Ethernet ports close physically. This creates a passive electrical bridge that connects the LTE modem directly to the Standby unit. The Standby unit (now becoming Active) will detect the link state change and successfully utilize the LTE connection. Therefore, both WAN links remain usable.
2. LAN Failover Mechanism (Statement C):
Prisma SD-WAN ION devices typically use a VRRP-like mechanism for LAN redundancy.
* When the "Active" node fails (loses power), the "Standby" node stops receiving keepalives and promotes itself to the Active state.
* To ensure downstream switches and clients immediately send traffic to the new Active unit, it must update their ARP tables. It does this by broadcasting a Gratuitous ARP (GARP) packet for the Virtual IP (VIP) address of the Switch Virtual Interfaces (SVIs). This action informs the network that the MAC address associated with the Gateway I1P is now reachable via the port connected to the new Active ION.234
NEW QUESTION # 88
1000 branches are to be deployed on Prisma SD-WAN with the following constraints:
* Devices will be shipped in batches directly to the site
* Configuration Management Database (CMDB) has all the necessary details for a site deployment
* Field tech will be responsible for rack, stack, and cabling of the IONs at each site
* Field tech will need to spend minimum amount of time at each branch site to reduce the cost
* The NOC operates in shifts and is responsible for remote cutover support Which method will achieve the mass deployment in shortest possible time?
Answer: B
Explanation:
For a massive rollout involving 1,000 branch sites, Prisma SD-WAN (formerly CloudGenix) provides a specialized workflow known as Bulk Site Configuration. This method is designed to minimize manual intervention and maximize deployment velocity by leveraging Site Templates and Device Shells.
In this scenario, the primary architectural advantage of Option C is the use of Pre-Staging. By exporting an empty SD-WAN device CSV from the Prisma SD-WAN Controller and populating it with data from the corporate CMDB, administrators can perform a bulk upload to create hundreds or thousands of sites and device shells simultaneously in the management portal. A "Device Shell" acts as a placeholder for a physical ION device that has not yet connected to the cloud. It contains all the site-specific configuration-such as interface roles, circuit labels, and IP addressing-waiting for a serial number to be associated with it.
When the field technician performs the physical "rack and stack," they simply connect the ION device to the internet (via ISP modem or cellular). Through Zero Touch Provisioning (ZTP), the device automatically
"phones home" to the Prisma SD-WAN Cloud Controller using its Manufacturer Installed Certificate (MIC).
Because the configuration was pre-created via the CSV bulk upload, the controller recognizes the device (once assigned to its shell) and immediately pushes the complete configuration. This eliminates the need for the field tech to access a console port or perform local configuration, reducing their on-site time to the bare minimum. While APIs (Option D) can be used for automation, the built-in CSV template workflow is the standard, documented "best practice" for rapidly translating CMDB data into a functioning SD-WAN fabric at this scale.
NEW QUESTION # 89
......
But there are question is that how you can pass the SD-WAN-Engineer exam and get a certificate. The best answer is to download and learn our SD-WAN-Engineer quiz torrent. Our products will help you get what you want in a short time. You just need little time to download and install it after you purchase, then you just need spend about 20~30 hours to learn it. We are glad that you are going to spare your precious time to have a look to our SD-WAN-Engineer Exam Guide.
