Fortinet NSE5_FSW_AD-7.6 Prüfungsplan:

Thema	Einzelheiten
Thema 1	FortiSwitch concepts: This domain covers core FortiSwitch features including VLAN configuration, QoS, LLDP-MED, stacking, switching and routing, STP for loop prevention, and port and transceiver configuration. It focuses on essential switching operations and network integration.
Thema 2	Deployment and management: This domain includes provisioning and deploying FortiSwitch in supported topologies, including multi-tenancy environments. It emphasizes proper setup, scalability, and centralized management.
Thema 3	Monitoring and troubleshooting: This domain covers packet capture methods, FortiLink troubleshooting, and diagnostic tools used to monitor traffic and resolve network issues.
Thema 4	Layer 2 control and security: This section focuses on Layer 2 security features such as port security, filtering, antispoofing, ACLs, security profiles, and VLAN security mechanisms to protect switched networks.

>> NSE5_FSW_AD-7.6 Testantworten <<

NSE5_FSW_AD-7.6 Antworten, NSE5_FSW_AD-7.6 Testing Engine

Die NSE5_FSW_AD-7.6 Prüfung ist ein neuer Wendepunkt in der IT-Branche. Sie werden der fachlich qualifizierte IT-Fachmann werden. Mit der Verbreitung und dem Fortschritt der Informationstechnik werden Sie Hunderte Online-Ressourcen sehen, die Fragen und Antworten zur Fortinet NSE5_FSW_AD-7.6 Zertifizierungsprüfung bieten. Aber ITZert ist der Vorläufer. Viele Leute wählen ITZert, weil die Schulungsunterlagen zur Fortinet NSE5_FSW_AD-7.6 Zertifizierungsprüfung von ITZertI hnen Vorteile bringen und Ihren Traum verwirklichen können.

Fortinet NSE 5 - FortiSwitch 7.6 Administrator NSE5_FSW_AD-7.6 Prüfungsfragen mit Lösungen (Q37-Q42):

37. Frage
Which three are valid actions that a FortiSwitch access control list (ACL) can apply to matching traffic?
(Choose three answers)

A. Set outer VLAN tags
B. Assign the VLAN ID
C. Quarantine devices
D. QoS
E. Traffic processing

Antwort: A,D,E

Begründung:
According to theFortiSwitchOS 7.6 Administration Guideand theNSE 5 FortiSwitch 7.6 Administrator Study Guide, Access Control Lists (ACLs) are used to perform multiple actions on matching traffic as it passes through the switch pipeline. The documentation explicitly categorizes these valid actions into three distinct functional groups:Traffic processing,QoS (Quality of Service), andVLANmodifications.
* Traffic Processing (Option C):This is a primary category of ACL actions. It includes operations that dictate how a frame is physically handled or monitored. Valid specific actions under this category includedrop(discarding the packet),count(incrementing a packet counter for statistics),redirect (sending the packet to a specific interface or CPU queue), andmirror(copying the traffic to a monitor port).
* QoS (Option E):The QoS category allows the switch to manage traffic prioritization and bandwidth.
ACLs can be configured toset the egress queue(assigning a frame to one of the eight priority queues), remark CoS (Class of Service)orDSCP (Differentiated Services Code Point)values in the frame header, and applypolicersfor rate limiting.
* VLAN / Set outer VLAN tags (Option D):Under the VLAN category, the most notable action is the ability toset outer VLAN tagson frames. This is particularly useful in scenarios involving Q-in-Q tunneling or service provider environments where a secondary tag is required for transport across a managed fabric.
It is important to note thatAssign the VLAN ID (Option A)is typically a function ofNAC (Network Access Control)orDynamic VLAN Assignmentrather than a standard ACL action; within an ACL context, vlan-id is primarily used as aclassifier(to match traffic) rather than an action.Quarantine devices (Option B)is a high- level security response triggered by the FortiGate NAC engine and is not a direct action available within the FortiSwitch ACL configuration menu.

38. Frage
How are the 'by VLAN redirect MAC address quarantine' mode and the 'by redirect MAC address quarantine' mode on FortiGate similar?

A. Both modes add quarantined device MAC addresses to the blocked firewall address group.
B. Both modes require firewall policies to block inter-VLAN traffic.
C. Both modes block intra-VLAN traffic by FortiGate automatically.
D. Both modes move quarantined devices to the quarantine VLAN.

Antwort: D

Begründung:
The 'by VLAN redirect MAC address quarantine' mode and the 'by redirect MAC address quarantine' mode on FortiGate share specific similarities:
* Quarantine VLAN Assignment (A):
* Common Feature:Both modes utilize a designated quarantine VLAN to isolate quarantined devices. This helps in mitigating the risk of spreading potential security threats within the network.
* Operational Impact:Moving devices to a specific quarantine VLAN restricts their network access, effectively isolating them until further action or remediation is taken.

39. Frage
Refer to the exhibit.

You just connected three FortiSwitch devices:Core-1,Core-2, andAccess-1. Core-1 and Core-2 both connect to Access-1 for redundancy. All switches are managed by FortiGate, which uses port4 as the FortiLink interface. After you enable the uplink ports on Core-2, you notice that port3 on Access-1 enters the Discarding STP state. What is the most likely cause of this behavior? (Choose one answer)

A. FortiGate is not running Spanning Tree Protocol (STP) on the FortiLink interface.
B. Bridge Protocol Data Unit (BPDU) Guard is enabled, which shuts down the port after it receives BPDUs.
C. Core-2 has the lowest bridge priority.
D. Access-1 is not authorized by FortiGate.

Antwort: C

Begründung:
According to theFortiSwitchOS 7.6 Administration Guideand theFortiLink 7.6 Study Guide, the Spanning Tree Protocol (STP) is automatically enabled on managed FortiSwitches to ensure a loop-free Layer
2 topology within the FortiLink fabric. When multiple physical paths exist between switches (as shown in the redundant connections between the Core and Access tiers), STP must block one of the paths to prevent a broadcast storm.
The behavior described in the exhibit-whereport3 on Access-1enters aDiscarding state-is a result of the STP election process. In a standard STP environment, switches elect aRoot Bridgebased on the lowestBridge Priority(or lowest MAC address as a tie-breaker). Once a root is established, other switches identify the
"best" path to that root (the Root Port) and block all other redundant paths.
The provided exhibit shows that Access-1 has two paths to the core: one to Core-1 and one to Core-2. The fact that the path to Core-2 is discarded suggests that the STP topology was recalculated when Core-2 was enabled. In the context of Fortinet technical exams for this specific scenario,Option C (Core-2 has the lowest bridge priority)is the standard answer identifying that Core-2's priority settings influenced the STP tree such that Access-1's link to it was determined to be the redundant (alternate) path.
If the switches were configured withMCLAG (Multi-Chassis Link Aggregation), both physical links would be treated as a single logical trunk, and neither would be in a discarding state. However, without MCLAG, the system relies on bridge priorities to prune the loop.BPDU Guard (Option A)is incorrect because it would administratively shut down the port rather than placing it in an STP "Discarding" state.Option Bis incorrect as the switch would not appear in the managed topology if unauthorized.

40. Frage
Refer to the exhibits.

All three FortiSwitch-connected ports are configured in VLAN 10. FortiGate acts as the Dynamic Host Configuration Protocol (DHCP) server and is connected to a DHCP snooping trusted trunk port. PC1 and PC2 are connected to ports configured as untrusted for Dynamic ARP Inspection (DAI), and no static bindings are configured in the IP source guard (IPSG) database. PC2 is compromised and attempts to spoof the FortiGate IP address by sending forged Address Resolution Protocol (ARP) replies with its own MAC address. What will FortiSwitch do with the ARP packets from PC2? (Choose one answer)

A. Forward the ARP replies to all VLAN 10 ports because DAI is only active on trusted ports.
B. Forward the ARP replies because there are no IPSG bindings blocking them.
C. Drop the ARP replies because they fail DAI validation against the DHCP snooping database.
D. Accept the ARP replies because the VLAN has DAI enabled and FortiGate is a trusted DHCP server.

Antwort: C

Begründung:
According to theFortiSwitchOS 7.6 Administration Guideand theFortiSwitch 7.6 Study Guide, Dynamic ARP Inspection (DAI) is a security feature used to intercept, log, and discard ARP packets with invalid IP-to-MAC address bindings. DAI is primarily used to prevent " Man-in-the-Middle " attacks, such as ARP spoofing or ARP cache poisoning.
In this scenario, DAI is active on VLAN 10. When DAI is enabled, the FortiSwitch intercepts all ARP packets on untrusted ports and validates them against a trusted source-most commonly theDHCP snooping database.
As shown in the " DHCP Snooping database " exhibit, PC2 is correctly mapped to IP 10.0.10.30 and MAC 00:
09:0F:AB:00:0B.
When PC2 attempts to send a forged ARP reply claiming that IP 10.0.10.254 (the FortiGate ' s IP) is located at its own MAC address (00:09:0F:AB:00:0B), the FortiSwitch ' s DAI engine inspects the packet. It checks the DHCP snooping database for a binding that matches IP 10.0.10.254 to MAC 00:09:0F:AB:00:0B. Finding no such valid entry (because the database correctly identifies the MAC 00:09:0F:AB:00:0B as belonging to IP
10.0.10.30), the switch identifies the ARP packet as illegitimate.
Consequently, the FortiSwitch willdrop the ARP repliesbecause they fail the DAI validation check against the established DHCP snooping bindings. Option A is incorrect as DAI functions independently of IPSG once the database is populated. Option B is incorrect because " accepting " the spoofed packet is the opposite of DAI ' s purpose. Option C is incorrect because DAI is specifically designed to run on untrusted ports to protect the network from client-side attacks.

41. Frage
Which two rules used by MSTP are similar to rules used by other STP methods? (Choose two.)

A. MSTP uses timers for transitioning the ports, similar to regular STP.
B. MSTP uses alternate path and primary path, similar to regular STP.
C. MSTP uses port role election, similar to rapid STP on the instances.
D. MSTP uses root bridge selection, similar to rapid STP

Antwort: C,D

Begründung:
"MSTP is based on RSTP", so the same port role election and the same root bridge selection. Reference:
FortiSwitch 7.2 Study Guide, page 187

42. Frage
......
