NEW QUESTION # 68
A BIG-IP Administrator suspects that one of the BIG-IP device power supplies is experiencing power outages.
Which log file should the BIG-IP Administrator check to verify the suspicion? (Choose one answer)
Answer: C
Explanation:
According to official F5 documentation (K52015891 - Troubleshooting BIG-IP power supply issues), hardware-related alerts for power supplies, fans, and chassis components are logged in /var/log/ltm.
When a BIG-IP device experiences a power supply issue-such as failure, intermittent outages, or fan-related faults-the system generates alerts through internal platform monitoring services. These alerts are written to the /var/log/ltm file and often appear with messages similar to:
Chassis power supply 2 has experienced an issue. Status is as follows: FAN=bad; STATUS=bad.
This makes /var/log/ltm the authoritative log file for identifying and verifying power supply and chassis-related problems on BIG-IP systems.
The other log files are not appropriate for this purpose:
/var/log/daemon.log contains general daemon messages but is not the primary source for chassis hardware alerts.
/var/log/kern.log logs kernel-level events, not platform power status.
/var/log/audit records administrative actions and configuration changes.
Conclusion:
Per F5-supported guidance, when suspecting power supply outages or chassis hardware issues, the BIG-IP Administrator should always check /var/log/ltm first.
NEW QUESTION # 69
Refer to the exhibit.
The image shows the status of a virtual server named application_vs in the BIG-IP Configuration Utility.
What is the cause of the status shown? (Choose two answers)
Answer: A,D
Explanation:
The exhibit shows the virtual server application_vs with a status indicating it is offline but enabled. In BIG-IP terminology, this status means the virtual server itself is administratively enabled, but it is unable to pass traffic because no usable pool members are available.
Two common and documented causes for this condition are:
Pool member(s) administratively disabled (Option A):
When all pool members are administratively disabled, BIG-IP removes them from load-balancing decisions. Even though the virtual server remains enabled, it has no available pool members to send traffic to, resulting in an offline status.
Node(s) administratively disabled (Option C):
Pool members inherit the status of their parent nodes. If a node is administratively disabled, all associated pool members are also marked unavailable. This condition causes the virtual server to show as offline, even though the virtual server configuration itself is correct.
The other options are incorrect:
Forced offline pool members (Option B) result in a different operational intent and are explicitly set for maintenance scenarios.
Virtual server administratively disabled (Option D) would show the virtual server as disabled, not enabled/offline.
This behavior is consistent with BIG-IP traffic management logic and is commonly verified by reviewing pool and node availability states when diagnosing virtual server availability issues.
NEW QUESTION # 70
Users are unable to reach an application. The BIG-IP Administrator checks the Configuration Utility and observes that the Virtual Server has a red diamond in front of the status. What is causing this issue?
Answer: B
Explanation:
In the BIG-IP Configuration Utility, the status icon (shape and color) provides immediate feedback on why a virtual server is not working as expected. A "Red Diamond" indicates that the object is
"Offline" and unavailable to process traffic. For a virtual server, this specific status typically means it has inherited an offline state from its mandatory backend resources. If all pool members associated with the virtual server have failed their health monitors, the virtual server will transition to a red diamond status because it has no healthy destination for incoming requests. This is distinct from a "Black Circle," which would indicate the virtual server has been manually
"Disabled" by an administrator. To troubleshoot a red diamond, the administrator must examine the associated pool and its members to determine why the health monitors are failing (e.g., server crashes, network path failures, or incorrect monitor strings). Resolving the health check failures on the pool members will return the virtual server to an "Available" (Green) status.
NEW QUESTION # 71
Which menu should you use on the BIG-IP Configuration Utility to generate a QKView support file? (Choose one answer)
Answer: D
Explanation:
A QKView is the primary diagnostic file used by F5 Support to analyze BIG-IP system health, configuration, performance, and logs. It collects a wide range of data, including running configuration, license details, module provisioning, hardware status, logs, statistics, and diagnostic command output. Generating a QKView is a standard first step when troubleshooting issues or opening a support case with F5.
In the BIG-IP Configuration Utility (GUI), the correct location to generate a QKView is System > Support (Option C). This menu is specifically designed for support and troubleshooting activities. From this section, administrators can create QKView files, upload them directly to F5 iHealth, or download them locally for later analysis or submission to F5 Support.
The other options are incorrect:
System > Configuration (Option A) is used for system-wide settings such as device name, NTP, and DNS.
System > Archive (Option B) is used to create UCS backups, not diagnostic QKViews.
System > Logs (Option D) is used to view and manage log files, not to generate support bundles.
This workflow is clearly documented in BIG-IP Administration and Support guides and is considered a best practice for efficient troubleshooting and support engagement.
NEW QUESTION # 72
Refer to the exhibit.
A BIG-IP Administrator configured a virtual server with a pool of 3 members and selected the Round Robin load balancing method to evenly distribute traffic across the pool members. During initial testing, traffic was not evenly distributed and the pool member 172.16.20.3 received more traffic than the other pool members.
Refer to the exhibit and the virtual server configuration provided below:
Plaintext
ltm virtual http.vs {
destination 10.10.1.100:http
ip-protocol tcp
mask 255.255.255.255
persist {
source_addr { default yes }
}
pool http.pool
profiles {
tcp{}
}
serverssl-use-sni disabled
source 0.0.0.0/0
source-address-translation {
type automap
}
translate-address enabled
}
What is the most likely cause of this behavior?
Answer: D
Explanation:
The primary reason for the uneven traffic distribution is the presence of a Persistence Profile in the virtual server configuration.
Load Balancing vs. Persistence: While the Round Robin method is designed to distribute new connections sequentially among pool members, Persistence overrides this logic for existing clients.
Source Address Persistence: The configuration shows source_addr persistence is enabled. This ensures that once a client (identified by their source IP) is mapped to a pool member, all subsequent connections from that same IP will be sent to the same member for the duration of the persistence record.
Uneven Distribution Logic: If one source IP address generates significantly more connections or longer-lived sessions than others--or if many clients appear behind a single NAT/Proxy IP--that specific pool member (in this case, 172.16.20.3) will receive a disproportionate amount of traffic compared to the others.
