NEW QUESTION # 11
For Type IV-A construction, noncombustible protection shall provide what fraction of the required fire- resistance rating for building elements?
Answer: D
Explanation:
The prescribed proportion is two-thirds , making option C correct. The relationship is demonstrated directly by IBC Table 722.7.1(1). A building element requiring a one-hour fire-resistance rating must receive 40 minutes of noncombustible protection; a two-hour element requires 80 minutes; and a three-hour-or-greater element requires 120 minutes. Each of those prescribed values represents two-thirds of the corresponding one-
, two-, or three-hour rating.
For Type IV-A specifically, Section 602.4.1.2 requires protection of the interior faces of all mass timber elements. Section 602.4.1.2.1 further states that the protection must contribute at least the time assigned in Table 722.7.1(1) and not less than 80 minutes .
The remaining portion of the required fire resistance is provided by the mass timber element itself. Thus, for a three-hour Type IV-A primary structural element, 120 minutes are provided through noncombustible protection and the timber must supply the remaining required endurance.
This two-component approach is fundamental to the Type IV-A fire-design methodology.
References/Topics: 2021 IBC Sections 602.4.1.2 and 602.4.1.2.1; Tables 601 and 722.7.1(1); protected Type IV-A mass timber.
NEW QUESTION # 12
Materials acceptable for use in fire-protecting connections in Type IV-A construction includes each of the following except:
Answer: C
Explanation:
Steel plates are not themselves a fire-protective material for the connection; therefore, option A is the exception. Steel plates frequently form part of mass timber structural connections, but because steel is highly thermally conductive, exposed steel can rapidly transmit heat into fasteners and adjacent wood. Consequently, the steel connection components are normally the items that require protection , not the material relied upon to provide that protection.
AWC guidance recognizes wood cover, fire-rated gypsum board, and other approved protection materials as valid means of shielding structural connections. TR10 specifically provides calculation procedures and worked examples using sacrificial wood cover and Type X gypsum wallboard. An approved protective coating can also be used where its documented fire-performance characteristics establish the required endurance under the approved design.
The distinction is important for inspection. A concealed steel plate does not automatically mean a protected connection. The special inspector must verify whether sufficient wood cover, gypsum protection, approved coating, or another engineered protection system surrounds the steel for the required duration. Hardware geometry, exposed edges, gaps, and penetrations can all materially affect thermal performance.
References/Topics: AWC Technical Report No. 10, protection of structural connections; 2021 IBC Section
2304.10.1; AWC guidance that connection protection can be provided by wood cover, gypsum board, or other approved material.
NEW QUESTION # 13
Fire-resistance ratings of members and assemblies can be established by all of the following except:
Answer: A
Explanation:
ASTM E84 is not a test for establishing the fire-resistance rating of a structural member or building assembly.
Therefore, option B is the exception.
The 2021 IBC establishes fire-resistance ratings primarily through testing conducted in accordance with ASTM E119 or UL 263. Those tests evaluate whether an element or assembly can maintain structural performance, limit flame passage, and control temperature rise for a specified duration under standardized fire exposure. ASTM E84 instead evaluates surface-burning characteristics, principally flame-spread and smoke- developed indices. An E84 classification cannot establish that a wall, floor, beam, column, or connection possesses a one-, two-, or three-hour fire-resistance rating.
The IBC also recognizes approved prescriptive designs under Section 721, calculated fire resistance under Section 722, and designs documented in approved sources or supported by permitted analytical methods.
Those are valid methods represented by options A, C, and D.
For inspection purposes, the approved construction documents must identify the method used to establish the rating. The inspector must then verify that the installed materials, dimensions, loading assumptions, protective layers, fasteners, joints, and connection details match the tested, calculated, or prescriptive design.
References/Topics: 2021 IBC Sections 703.2, 703.2.1, 721 and 722; ASTM E119 and UL 263 fire-resistance testing.
NEW QUESTION # 14
Refer to the exhibit by clicking on the EXHIBIT button above.
If the glulam beam and CLT panels all require a fire-resistance rating of 2 hours, what is the required fire- resistance rating in hours for the structural connections between the glulam and CLT?
Answer: D
Explanation:
The structural connections must maintain a fire-resistance rating corresponding to the required rating of the structural elements they connect. Because both the glulam beam and CLT panels require a two-hour fire- resistance rating, their connections must also provide two hours of fire resistance. Therefore, option C is correct.
Concealing steel hardware inside a timber member does not eliminate the fire-resistance requirement. Steel rapidly conducts heat and can lose strength, while timber surrounding a concealed connector can char, split, or withdraw from fasteners. The connection must consequently be protected through sufficient wood cover, noncombustible protection, tested assemblies, or an approved engineering analysis demonstrating acceptable connection temperatures and capacity for the entire required duration.
A three-hour rating is not required merely as a generalized safety factor; the code requires correspondence with the connected elements unless the approved design establishes another condition. A one-hour connection would create a premature weak point in the load path, and a zero-hour rating would be unacceptable simply because the hardware is hidden.
References/Topics: 2021 IBC Section 2304.10.1; fire-resistance rating of mass timber connections; protected concealed steel hardware.
NEW QUESTION # 15
Refer to the exhibit by clicking on the EXHIBIT button above.
In the detail shown, what is the required tolerance in inches between the steel beam web and CLT?
Answer: D
Explanation:
The construction detail identifies a 1/2-inch tolerance between the steel beam web and the adjacent CLT panel. Therefore, option B is correct.
This is principally a construction-document interpretation question rather than a generic prescriptive IBC dimension. The 2021 IBC does not establish one universal steel-web-to-CLT clearance applicable to every mass timber connection. The required clearance is project specific and is established by the registered design professional through the approved structural drawings and connection details.
The tolerance provides erection clearance for placement of the prefabricated CLT around the steel member while accounting for fabrication and installation variation. It must not be arbitrarily reduced or increased because the gap can affect panel fit, bearing conditions, fastener alignment, fire-protection continuity, acoustic treatment and any specified joint-filling material.
Under the special-inspection framework, the inspector must compare the installed connection directly with the approved construction documents. Any condition that does not maintain the specified 1/2-inch clearance-or any undocumented field modification to the CLT or steel connection-must be reported and resolved through the registered design professional rather than accepted solely on the contractor's direction.
References/Topics: Approved structural details; 2021 IBC Sections 1704.2 and 1705.5; inspection of mass timber erection, anchorage and connections.
NEW QUESTION # 16
......
