NEW QUESTION # 12
Examine the exhibit below.
A DoS Profile shown in the exhibit is applied to an SD-WAN branch.
Referring to the exhibit, which statement is correct?
Answer: A
Explanation:
The correct answer is B . The DoS profile in the exhibit is a Classified Profile using Source IP Only as the classification key. For TCP flood protection, the profile is enabled and shows an Alarm Rate of 5000 packets per second , an Activate Rate of 7000 packets per second , a Maximum Rate of 100000 packets per second , a Drop Period of 300 seconds , and an action of Random . This means the first threshold, 5000 pps, is used to trigger alarm behavior, while the second threshold, 7000 pps, activates the configured mitigation action. Since the selected action is Random , packets are randomly dropped when the TCP rate reaches the activate threshold.
Versa documentation shows that DoS policies can match traffic using source, destination, service, application, schedule, IP version, DSCP, and other conditions, and that a DoS policy can set either an aggregate or classified DoS profile. It also documents that DoS policies support enforcement actions and logging through LEF profiles for DoS events. Therefore, 7000 pps does not merely generate an alarm, and it does not mean complete dropping. Complete dropping is not selected in the exhibit.
NEW QUESTION # 13
Examine the exhibit below.
The exhibit shows a device group created for a new group of hubs. The device template called "BMBF- TEMPLATE" has an Address object called "Server". A network administrator creates the Class of Service Template called "Ship-CoS-IT" that has an Address object with the same name. Then it tries to onboard a new device to this device group.
Which statement is true about the configuration that this device will have?
Answer: B
Explanation:
The correct answer is D . In the displayed post-staging template association order, the device template BMBF- TEMPLATE is applied before the QoS service template Ship-CoS-IT . Versa documentation explains that device templates, also called post-staging templates, provide the baseline configuration for devices, while service templates are service-specific configurations that can be applied to device configurations. It also states that service templates are associated with device groups and that, in a device group, the administrator can choose the order in which service templates are applied.
Because the QoS template is later in the shown association order, the final merged device configuration uses the Address object definition from the QoS template when the same object name exists in both templates. It does not automatically create two copies of the same Address object, because the object name is the key for the configuration element. It also should not fail merely because the same object name exists in a later template; the merge behavior resolves the effective configuration according to the template order. Therefore, the onboarded hub device receives the Server Address object version from Ship-CoS-IT, the QoS template.
NEW QUESTION # 14
What are three roles that VOS performs? (Choose three.)
Answer: A,B,C
Explanation:
The correct answers are A, B, and E . Versa Operating System, or VOS , is the software platform used for Versa SD-WAN branch and headend functions. Versa troubleshooting documentation explicitly refers to common runtime state across SD-WAN Controller, branch, and hub devices , confirming that VOS is used for Controller and branch-style SD-WAN roles. Versa monitoring documentation also lists SD-WAN branches, SD-WAN Controller nodes, SD-WAN hubs, vCPEs, and uCPEs as assets that are monitored and managed in Versa Director, which aligns with VOS being used as a branch/edge and controller platform.
VOS can also act as a uCPE platform . Versa documentation includes procedures to configure uCPE on a VOS device, showing that VOS can host or support uCPE deployment use cases.
The originally provided answer A, C, D is not correct. A Log Collector or log forwarder function belongs to the Versa Analytics architecture, not the VOS branch role; Versa's design guide states that the log forwarder is part of the Versa Analytics node or can run as a standalone log-forwarder server.
A Zookeeper arbiter is also not a standard VOS SD-WAN device role in this context.
NEW QUESTION # 15
A CGNAT rule is configured, but traffic is not being translated. You want to confirm whether the expected source and destination prefixes are programmed in the CGNAT access list for the tenant. Which command is most appropriate?
Answer: C
Explanation:
The correct answer is A . Versa CGNAT troubleshooting documentation states that, after connecting to the vsmd daemon, administrators can view CGNAT access lists used for traffic matching with the command show cgnat acl info < tenant-id > . The sample output shows ACL handle, rule ID, category, precedence, VRF, source IP, destination IP, tenant ID, and total filters.
This is the correct command when NAT configuration appears present but translations do not occur, because it verifies whether the runtime dataplane has the correct traffic-match rules. If the source prefix, destination prefix, VRF, or precedence is wrong, the session may never match the NAT rule, and no translation will be applied.
show system status checks system services. show device clients shows active and failed sessions, CPU usage per session, and memory load for processes. show system storage shows disk usage. These commands are useful in other troubleshooting workflows, but they do not validate CGNAT ACL matching criteria for tenant traffic.
NEW QUESTION # 16
You are troubleshooting a branch that cannot form SD-WAN overlay tunnels. The branch has WAN interfaces up, but you suspect remote endpoint objects were not learned. Which VSM command should you use to verify whether remote site objects were learned from BGP or from configuration?
Answer: D
Explanation:
The correct answer is A . Versa data-path troubleshooting documentation gives a specific VSM control-plane workflow for checking SD-WAN tunnel objects. After connecting to the VSM daemon, administrators can use show vsm p2mp local-tunnel-sites 0 to inspect local site objects. To check whether remote site objects were learned from BGP or from configuration , Versa instructs administrators to issue show vsm p2mp tunnel-remote-endpoint tenant < tenant-id > on the VSM control plane.
This command is highly relevant when local WAN interfaces are operational, but overlay tunnel formation is incomplete. It shows remote endpoints such as Controllers, hubs, or branches, along with site type, site name, branch ID, tenant ID, remote WAN link information, and tunnel state-related fields.
show interfaces brief confirms interface state and IP addresses, but it does not show learned remote SD- WAN endpoint objects. CGNAT summary is unrelated to tunnel endpoint learning. System storage is useful for disk checks, but not for SD-WAN overlay endpoint troubleshooting.
NEW QUESTION # 17
......
