NEW QUESTION # 18
A BIG-IP Administrator creates a new VLAN on BIG-IP Cluster Member A and attaches an interface to it.
Although the Auto Config Sync is in place, the new VLAN does NOT show up on Cluster Member B. What should the BIG-IP Administrator do to ensure the new VLAN is configured on each Cluster Member?
Answer: B
Explanation:
In a BIG-IP High Availability (HA) environment, most configuration objects (Virtual Servers, Pools, iRules) are considered "shared" and are synchronized automatically between devices. However, network-level objects-specifically VLANs and Self IPs-are unique to the hardware and are generally not synchronized by the ConfigSync process.
This is intentional because two devices in a cluster may have different physical cabling or interface assignments. For example, Cluster Member A might use interface 1.1 for a specific VLAN, while Cluster Member B might use interface 1.2. Because the BIG-IP system cannot assume that the physical network topology is identical for both appliances, the administrator must Configure the new VLAN manually on Cluster Member B.
Once the VLAN is created manually on both devices with the exact same name, it can then be used to host
"shared" floating Self IP addresses or traffic groups that will synchronize. Failing to create the VLAN on the peer device will prevent the traffic group from failing over correctly, as the peer will not have the necessary Layer 2 broadcast domain defined to take over the traffic. Resetting Device Trust (Option D) is a drastic step for fix sync communication issues but will not change the fact that VLANs are non-syncable objects.
Enabling the interface (Option B) only affects the link status of Member A and has no impact on the configuration of Member B.
NEW QUESTION # 19
DNS queries from internal DNS servers fail when sent through a BIG-IP Virtual Server.
Which Virtual Server property should be changed?
Answer: A
Explanation:
Standard DNS queries use UDP. Configuring the Virtual Server for TCP causes DNS traffic to fail.
NEW QUESTION # 20
Refer to the exhibit.
A BIG-IP Administrator configures a Virtual Server to handle HTTPS traffic. Users report that the application is NOT working. Which additional configuration is required to resolve this issue?
Answer: C
Explanation:
According to the provided exhibit, the " SSL Profile (Client) " section in the Virtual Server configuration is empty. For a BIG-IP system to process HTTPS traffic, it must act as an SSL/TLS endpoint. This process, known as SSL Termination or SSL Offload, requires the assignment of a Client SSL Profile to the Virtual Server. Without this profile, the BIG-IP does not have the necessary certificate and private key information to perform the SSL handshake with the client ' s browser. Consequently, when a user attempts to connect via HTTPS, the TCP connection may establish, but the SSL handshake will fail because the BIG-IP will not know how to decrypt the incoming encrypted packets.
A Client SSL profile defines the ciphers, certificates, and keys that the BIG-IP uses to communicate securely with the client. In a standard HTTPS deployment, the BIG-IP decrypts the traffic and can then send it to the backend pool members either as plain text (header insertion/manipulation) or re-encrypt it using a Server SSL profile. While a Server SSL profile (Option C) is needed if the backend servers themselves require HTTPS, the initial failure for a user reaching a Virtual Server is almost always the lack of a Client SSL profile to terminate the user ' s connection. Changing the Service Port to HTTP (Option D) would be incorrect because the goal is to handle HTTPS traffic (typically port 443). Assigning the " clientssl " or a custom client-side profile from the " Available " list to the " Selected " list in the GUI is the mandatory step to make the Virtual Server operational for secure web traffic.
NEW QUESTION # 21
A BIG-IP Administrator uses backend servers to host multiple services per server. There are multiple virtual servers and pools defined, referencing the same backend servers. Which load balancing algorithm is most appropriate to have an equal number of connections on each backend server?
Answer: B
Explanation:
This question addresses the critical architectural distinction between "member-based" and "node-based" load balancing in environments where servers are multi-homed or host multiple virtualized services. On a BIG-IP, a node represents the underlying IP address of a physical or virtual server, while a pool member represents a specific combination of that IP and a service port (e.g., 10.1.1.10:80).
When multiple pools reference the same IP address across different ports or Virtual Servers, using Least Connections (member) (Option D) only balances connections relative to that specific pool. For example, if Pool_A and Pool_B both use Server_X, and Pool_A has 100 connections while Pool_B has only 5, a member- based algorithm for Pool_B only sees the 5 connections and may continue to send traffic there even if Server_X is CPU-saturated by Pool_A.
The Least Connections (node) algorithm (Option B) solves this by tracking the aggregate total of all active connections directed to that specific node (IP address) across every pool on the system. By selecting the node with the absolute lowest total connection count, the BIG-IP ensures a more equitable distribution of work at the hardware resource level. Predictive methods (Options A and C) use a ranking system based on the trend of connection counts over time, but for the specific requirement of maintaining an equal number of current connections on multi-service servers, the direct Least Connections (node) calculation is the standard and most effective procedural choice.
NEW QUESTION # 22
A set of servers is used for an FTP application as well as an HTTP website via separate BIG-IP Pools. The server support team reports that some servers are receiving a lot more traffic than others. Which Load Balancing Method should the BIG-IP Administrator apply to even out the connection count?
Answer: D
Explanation:
Similar to the logic required for managing multi-service backend environments, the issue described-where servers hosting multiple protocols like FTP and HTTP are experiencing uneven distribution-stems from the BIG-IP's default behavior of treating each pool independently. If the administrator uses a member-based load balancing method, the BIG-IP distributes HTTP traffic regardless of how much FTP traffic that same physical server is currently processing.
To resolve this, the administrator must utilize the Least Connections (Node) method. By switching both the HTTP and FTP pools to this algorithm, the BIG-IP begins to make load balancing decisions based on the total combined connection count for the IP address of each server. When a new HTTP request arrives, the BIG-IP checks which server has the fewest total connections (including existing FTP sessions). This prevents a server that is already busy with long-lived FTP transfers from being overwhelmed by a sudden burst of HTTP requests.
Ratio methods (Options A and C) are static and rely on the administrator manually assigning weights to servers based on their perceived capacity; they do not adapt to real-time fluctuations in traffic volume across different pools. Least Connections (Member) (Option B) remains blind to the "cross-pool" traffic on the same hardware. Only the Node-based Least Connections approach provides the global visibility necessary to "even out" the total resource utilization across servers supporting multiple distinct applications.
NEW QUESTION # 23
......
