| Section | Objectives |
|---|---|
| Topic 1: Construction Fire Safety | |
| Topic 2: Mass Timber Materials | - CLT, Glulam, NLT, SCL and Engineered Wood Products |
| Topic 3: General & Construction Types | - Construction Classification — Type IV-A, IV-B, IV-C
|
| Topic 4: Fire-Resistance & Protection | - Noncombustible Protection & Encapsulation - Concealed Spaces Protection - Fire-Resistance-Rated Assemblies |
| Topic 5: Inspection Duties & Documentation | - Inspection Reporting and Compliance Verification - Statement of Special Inspections |
| Topic 6: Structural & Connection Inspection | - Framing and Structural Elements - Connection Design and Protection |
>> 93-Tall-Mass-Timber-Buildings Deutsch Prüfungsfragen <<
Wir ITZert bietet Ihnen die Prüfungsfragen und Antworten zur International Code Council 93-Tall-Mass-Timber-Buildings von höchster Qualität, damit Sie viel näher von Ihrem Erfolg sind. Wenn Sie noch ein paar Sorgen haben, können Sie die 93-Tall-Mass-Timber-Buildings Demo durch die Webseite ITZert herunterladen. Hier versprechen wir Ihnen, dass wir Ihnen noch einjähriger Aktualisierung kostenlos anbieten werden, nachdem Sie die Prüfungsfragen und Antworten zur International Code Council 93-Tall-Mass-Timber-Buildings gekauft haben.
44. Frage
Proprietary nails can be used by referencing which ICC-ES Evaluation Report?
Antwort: A
Begründung:
ICC-ES ESR-1539 is the applicable evaluation report, making option C correct. ESR-1539 addresses nails and staples manufactured by participating companies and evaluates their use in engineered and nonengineered structural connections.
An ICC-ES Evaluation Report provides evidence that a proprietary product or system complies with specified building-code requirements where the product does not rely solely on the generic prescriptive provisions of the IBC. For proprietary nails, the report provides the technical basis needed to establish characteristics such as dimensions, materials, recognized structural applications, allowable design values, installation limitations, and conditions of use.
The current ICC-ES document is published as ESR-1539P, reflecting subsequent administrative updates to the report, but the identifying evaluation-report number remains 1539 , matching option C and the examination question.
For special inspection, merely recognizing the ESR number is not enough. The inspector should verify that the installed proprietary fastener is actually included in the report, that its diameter and length correspond to the approved construction documents, and that installation spacing, penetration, orientation, substrate, and other report conditions are satisfied.
References/Topics: ICC-ES ESR-1539, structural nails and staples; proprietary fastener evaluation and installation requirements. ICC-ES states that the nails and staples covered by ESR-1539 are used in engineered and prescriptive structural connections.
45. Frage
Refer to the exhibit by clicking on the EXHIBIT button above.
In the detail shown and according to AWC Technical Report 10, what is the time assigned in minutes to 5/8 in. Type X gypsum board for connection fire protection thermal separation requirements?
Antwort: C
Begründung:
For the illustrated two-layer protection system, the 5/8-inch Type X gypsum-board layer directly adjacent to the connection is assigned 20 minutes, while the second layer is assigned 40 minutes. Therefore, option C is correct.
The standard assigned protection time for one layer of 5/8-inch Type X gypsum board is 40 minutes.
However, the thermal-separation methodology applies a 0.50 reduction factor to the final or base Type X layer located directly against the protected connection. That layer therefore contributes 20 minutes. The outer layer retains its full 40-minute assigned value, producing a combined assigned protection time of 60 minutes for the two-layer configuration.
The layers are not interchangeable for calculation purposes because the reduced contribution applies specifically to the layer adjacent to the protected connection. Options A and B incorrectly assign the same value to both layers, while option D reverses the required allocation.
During inspection, the special inspector should verify layer sequencing, board thickness and type, fastening, joint staggering, edge support, protection at corners, and continuity around the connection. Missing or incorrectly sequenced layers can invalidate the calculated thermal-separation time.
References/Topics: AWC Technical Report 10; AWC 2021 Fire Design Specification Section 3.5.2.1; assigned protection time for Type X gypsum board.
46. Frage
Materials acceptable for use in fire-protecting connections in Type IV-A construction includes each of the following except:
Antwort: C
Begründung:
Steel plates are not themselves a fire-protective material for the connection; therefore, option A is the exception. Steel plates frequently form part of mass timber structural connections, but because steel is highly thermally conductive, exposed steel can rapidly transmit heat into fasteners and adjacent wood. Consequently, the steel connection components are normally the items that require protection , not the material relied upon to provide that protection.
AWC guidance recognizes wood cover, fire-rated gypsum board, and other approved protection materials as valid means of shielding structural connections. TR10 specifically provides calculation procedures and worked examples using sacrificial wood cover and Type X gypsum wallboard. An approved protective coating can also be used where its documented fire-performance characteristics establish the required endurance under the approved design.
The distinction is important for inspection. A concealed steel plate does not automatically mean a protected connection. The special inspector must verify whether sufficient wood cover, gypsum protection, approved coating, or another engineered protection system surrounds the steel for the required duration. Hardware geometry, exposed edges, gaps, and penetrations can all materially affect thermal performance.
References/Topics: AWC Technical Report No. 10, protection of structural connections; 2021 IBC Section
2304.10.1; AWC guidance that connection protection can be provided by wood cover, gypsum board, or other approved material.
47. Frage
Based on the definition of cross-laminated timber (CLT), panels are manufactured as follows:
Antwort: C
Begründung:
The 2021 IBC definition of cross-laminated timber describes a prefabricated engineered wood product consisting of not less than three layers of solid-sawn lumber or structural composite lumber. The adjacent layers are cross oriented and bonded with structural adhesive to form a solid wood element. Accordingly, option C is correct.
Cross orientation means that the principal grain direction of one layer is arranged approximately perpendicular to that of the adjoining layer. This configuration distinguishes CLT from products in which all laminations run parallel, such as conventional glued-laminated timber. The cross-oriented layup provides two- way panel behavior, dimensional stability, and structural capacity in both principal directions.
Option A is incorrect because CLT must contain at least three layers. Option B describes a mechanically laminated product rather than structural glued CLT; nail-laminated timber uses mechanical fasteners, whereas code-compliant CLT uses structural adhesives and must conform to the applicable manufacturing standard.
Option D eliminates the defining cross-lamination characteristic and would instead describe a parallel- laminated product.
During inspection, the product label and certification documentation should be checked to confirm the panel was manufactured under the required quality-assurance program.
References/Topics: 2021 IBC Chapter 2 definition of "Cross-Laminated Timber"; Sections 602.4 and
2303.1.4; ANSI/APA PRG 320.
48. Frage
A proprietary field-glued mass timber beam splice will require which of the following:
Antwort: D
Begründung:
A proprietary field-glued mass timber beam splice requires special inspection because the connection relies on a field-applied adhesive process that is not covered as a routine prescriptive mass timber connection in Table
1705.5.3. The controlling mechanism is IBC Section 1705.1.1, which authorizes the building official to require special inspection for unusual materials, systems, or installation procedures, particularly where compliance depends on additional manufacturer installation instructions.
The ICC code-development rationale for the tall mass timber provisions specifically identifies field-glued mass timber beam or panel splices as an example of work for which special inspection can be required.
Inspection must address the approved evaluation report and manufacturer's instructions, including substrate preparation, moisture and temperature limits, adhesive storage and expiration, mixing or proportioning, application quantity, open time, member alignment, clamping or pressure, and curing conditions.
Approval by the permit applicant has no regulatory significance. Verification by the registered design professional may supplement the inspection program but does not replace the approved special inspector. A building official may observe the work, but routine field verification by that official is not the prescribed quality-control procedure.
References/Topics: 2021 IBC Sections 1704.2, 1704.3 and 1705.1.1; special cases; proprietary field-glued mass timber splices.
49. Frage
......
