ZertFragen ist eine professionelle Website, die jedem Kandidaten guten Service vor und nach dem Kauf bietet. Wenn Sie die Prüfungsfragen und Antworten zur International Code Council 93-Tall-Mass-Timber-Buildings Zertifizierungsprüfung von ZertFragen benötigen, können Sie im Internet die Demo herunterladen, um sicherzustellen, ob es Ihnen passt. So können Sie persönlich die Qualität unserer Produkte testen und dann kaufen. Fallen Sie in der International Code Council 93-Tall-Mass-Timber-Buildings Prüfung durch, zahlen wir Ihnen die gesammte Summe zurück. Und außerdem bieten wir Ihnen einen einjährigen kostenlosen Update-Service, bis Sie die International Code Council 93-Tall-Mass-Timber-Buildings Prüfung bestehen.
| Section | Objectives |
|---|---|
| Construction Fire Safety | |
| Inspection Duties & Documentation | - Inspection Reporting and Compliance Verification - Statement of Special Inspections |
| Structural & Connection Inspection | - Connection Design and Protection - Framing and Structural Elements |
| General & Construction Types | - Construction Classification — Type IV-A, IV-B, IV-C
|
| Mass Timber Materials | - CLT, Glulam, NLT, SCL and Engineered Wood Products |
| Fire-Resistance & Protection | - Noncombustible Protection & Encapsulation - Fire-Resistance-Rated Assemblies - Concealed Spaces Protection |
>> 93-Tall-Mass-Timber-Buildings Deutsch <<
Die Testaufgaben von International Code Council 93-Tall-Mass-Timber-Buildings Zertifizierungsprüfung aus ZertFragen sind durch die Praxis getestet, daher sind sie zur Zeit das gründlichste, das genauste und das neueste Produkt auf dem Markt. Unser ZertFragen bietet Ihnen präzise Lehrbücher und Erfahrungen, die auf umfangreichern Erfahungen und der realen Welt basieren, was Ihnen verspricht, dass Sie in kürzester Zeit die Zertifizierungsprüfung von International Code Council 93-Tall-Mass-Timber-Buildings bestehen können. Nach dem Kauf unserer Produkte werden Sie einjährige Aktualisierung genießen.
54. Frage
Materials acceptable for use in fire-protecting connections in Type IV-A construction includes each of the following except:
Antwort: A
Begründung:
Steel plates are not themselves a fire-protective material for the connection; therefore, option A is the exception. Steel plates frequently form part of mass timber structural connections, but because steel is highly thermally conductive, exposed steel can rapidly transmit heat into fasteners and adjacent wood. Consequently, the steel connection components are normally the items that require protection , not the material relied upon to provide that protection.
AWC guidance recognizes wood cover, fire-rated gypsum board, and other approved protection materials as valid means of shielding structural connections. TR10 specifically provides calculation procedures and worked examples using sacrificial wood cover and Type X gypsum wallboard. An approved protective coating can also be used where its documented fire-performance characteristics establish the required endurance under the approved design.
The distinction is important for inspection. A concealed steel plate does not automatically mean a protected connection. The special inspector must verify whether sufficient wood cover, gypsum protection, approved coating, or another engineered protection system surrounds the steel for the required duration. Hardware geometry, exposed edges, gaps, and penetrations can all materially affect thermal performance.
References/Topics: AWC Technical Report No. 10, protection of structural connections; 2021 IBC Section
2304.10.1; AWC guidance that connection protection can be provided by wood cover, gypsum board, or other approved material.
55. Frage
When Type X gypsum board is used as noncombustible protection over mass timber on the building ' s exterior walls, which of the following fasteners are permitted?
Antwort: A
Begründung:
Option A reproduces one of the two permitted exterior gypsum-board fastening methods in 2021 IBC Section
722.7.2.2. Type X gypsum board used as noncombustible protection on the exterior side of mass timber walls may be attached using galvanized nails of minimum 12 gage with a 7/16-inch head and sufficient length to penetrate the mass timber at least 1 inch .
The code also permits ASTM C1002 Type S, W, or G screws, but those screws must likewise penetrate the mass timber a minimum of 1 inch . Options C and D are therefore incorrect because they specify only 3/4- inch and 7/8-inch penetration, respectively. Option B is incorrect because it substitutes 16-gage nails for the minimum 12-gage requirement.
Section 722.7.2.2 additionally requires exterior Type X gypsum-board layers to be fastened 12 inches on center each way and 6 inches on center at joints or ends. Panel-edge fasteners must be located at least 1 inch and not more than 2 inches from the edge.
These fastening details are part of the conditions necessary to claim the protection contribution in Table
722.7.1(2).
References/Topics: 2021 IBC Sections 722.7.1 and 722.7.2.2; exterior Type X gypsum-board protection.
56. Frage
Which of the following is true regarding fire-resistance rating protection provided by noncombustible covering material?
Antwort: C
Begründung:
IBC Table 722.7.1(2) assigns a 40-minute protection contribution to 5/8-inch Type X gypsum board .
Therefore, option D is correct.
The same table assigns 25 minutes to 1/2-inch Type X gypsum board. Consequently, option B overstates the protection contribution of the thinner Type X panel. Ordinary gypsum board values appearing elsewhere in Section 722 cannot simply be substituted for the specific mass timber noncombustible protection values in Table 722.7.1(2). Options A and C therefore do not state the protection contribution recognized by the mass timber table.
These assigned values are particularly important when multiple layers are required. For example, a two-hour building element requires at least 80 minutes of noncombustible protection under Table 722.7.1(1), which can be satisfied prescriptively with two properly installed layers of 5/8-inch Type X gypsum board, each contributing 40 minutes.
The contribution is valid only when the gypsum board is installed and fastened in accordance with Section
722.7.2.
References/Topics: 2021 IBC Tables 722.7.1(1) and 722.7.1(2); Section 722.7.2; Type X gypsum noncombustible protection.
57. Frage
A proprietary field-glued mass timber beam splice will require which of the following:
Antwort: C
Begründung:
A proprietary field-glued mass timber beam splice requires special inspection because the connection relies on a field-applied adhesive process that is not covered as a routine prescriptive mass timber connection in Table
1705.5.3. The controlling mechanism is IBC Section 1705.1.1, which authorizes the building official to require special inspection for unusual materials, systems, or installation procedures, particularly where compliance depends on additional manufacturer installation instructions.
The ICC code-development rationale for the tall mass timber provisions specifically identifies field-glued mass timber beam or panel splices as an example of work for which special inspection can be required.
Inspection must address the approved evaluation report and manufacturer's instructions, including substrate preparation, moisture and temperature limits, adhesive storage and expiration, mixing or proportioning, application quantity, open time, member alignment, clamping or pressure, and curing conditions.
Approval by the permit applicant has no regulatory significance. Verification by the registered design professional may supplement the inspection program but does not replace the approved special inspector. A building official may observe the work, but routine field verification by that official is not the prescribed quality-control procedure.
References/Topics: 2021 IBC Sections 1704.2, 1704.3 and 1705.1.1; special cases; proprietary field-glued mass timber splices.
58. Frage
Refer to the figure by clicking on the EXHIBIT button above.
In Type IV-B construction, unprotected portions of mass timber as shown in the Figure are required to be separated by _____ feet.
Antwort: A
Begründung:
The required separation is 15 feet , making option B correct. Section 602.4.2.2.4 of the 2021 IBC specifically regulates the separation distance between unprotected mass timber elements in Type IV-B construction.
Within each dwelling unit or fire area, unprotected portions of mass timber walls and ceilings must be separated from other unprotected wall and ceiling portions by not less than 15 feet . For ceiling-related surfaces, the separation is measured horizontally along the ceiling. For wall-to-wall exposure, the applicable separation is measured horizontally along the floor.
This requirement operates in addition to the maximum exposed-area restrictions. A designer therefore cannot merely demonstrate that the exposed ceiling is below 20 percent or that exposed walls are below 40 percent of floor area; the exposed regions must also satisfy the required spatial separation.
The purpose is to prevent multiple exposed mass timber regions from acting as closely spaced fuel packages during a compartment fire. During inspection, dimensions should be checked against the approved documents before required gypsum or other noncombustible protection is completed.
References/Topics: 2021 IBC Section 602.4.2.2.4; separation distance between unprotected Type IV-B mass timber elements.
59. Frage
......
Wenn Sie sich zur International Code Council 93-Tall-Mass-Timber-Buildings Zertifizierungsprüfung anmelden, sollen Sie sofort gute Lernmaterialien oder Prüfungsunterlagen wählen, um sich gut auf die Prüfung vorzubereiten. Denn die International Code Council 93-Tall-Mass-Timber-Buildings Zertifizierungsprüfung ist eine schwierige Prüfung und Sie müssen dafür ausreichende Vorbereitungen haben.
