As long as you enter the learning interface of our soft test engine of SD-WAN-Engineer quiz guide and start practicing on our Windows software, you will find that there are many small buttons that are designed to better assist you in your learning. When you want to correct the answer after you finish learning, the correct answer for our SD-WAN-Engineer Test Prep is below each question, and you can correct it based on the answer. In addition, we design small buttons, which can also show or hide the SD-WAN-Engineer exam torrent, and you can flexibly and freely choose these two modes according to your habit.
| Topic | Details |
|---|---|
| Topic 1 |
|
| Topic 2 |
|
| Topic 3 |
|
| Topic 4 |
|
| Topic 5 |
|
>> Test SD-WAN-Engineer Question <<
After cracking the Palo Alto Networks SD-WAN Engineer (SD-WAN-Engineer) exam you will receive the credential badge. It will pave your way toward well-paying jobs or promotions in any reputed tech company. At TestPassKing have customizable Palo Alto Networks SD-WAN-Engineer practice exams for the students to review and improve their preparation. The Palo Alto Networks SD-WAN-Engineer Practice Test material product of TestPassKing are created by experts with the dedication to help customers crack the Palo Alto Networks SD-WAN-Engineer exam on the first attempt.
NEW QUESTION # 14
Which condition, when configured within a performance policy, is a trigger for generating an incident related to application performance or path degradation?
Answer: C
Explanation:
In Prisma SD-WAN, Performance Policies are the primary mechanism used to define the expected quality of experience for specific applications. Unlike traditional monitoring that relies solely on "up/down" interface states, Prisma SD-WAN focuses on the actual health of the application path. An incident is triggered when the system detects a violation of defined service-level agreement (SLA) thresholds, such as excessive latency, jitter, or packet loss, even if the physical link remains active.
When an administrator configures a performance policy, they set specific bounds for these metrics. For example, a VoIP application might have an SLA requiring latency below 150ms and packet loss below 1%. If the ION device detects that the current path (e.g., a broadband circuit) exceeds these limits, it generates a performance incident. This incident serves two purposes: first, it alerts the administrator to the degradation; second, it triggers the Path Selection engine to proactively steer the application traffic to a more suitable
"Backup" or "Available" path that currently meets the SLA requirements.
Options B, C, and D represent system-level or network-level events that generate different types of alerts or incidents (System or Network incidents), but they are not the triggers defined within a Performance Policy.
Performance policies are specifically concerned with the application's perceived performance across the fabric. By focusing on SLA violations rather than just physical link status, Prisma SD-WAN ensures that business-critical applications remain functional even during "brownout" conditions where a circuit is technically "up" but performing poorly.
NEW QUESTION # 15
An administrator is configuring a BGP peer on a Data Center ION to learn routes from the core switch. The goal is to have the ION learn these prefixes and then advertise them to all remote branch sites across the SD- WAN overlay.
Which setting must be configured on the BGP Peer to ensure these learned routes are redistributed into the SD-WAN fabric?
Answer: D
Explanation:
Comprehensive and Detailed Explanation
In Prisma SD-WAN routing configuration, the Scope setting on a BGP Peer (or a Static Route) controls the redistribution logic for the prefixes learned from that source.
* Local Scope: If a BGP peer is configured with "Local" scope, the ION device will install the learned routes into its local routing table for its own reachability, but it will not advertise (redistribute) these routes to other ION devices via the Secure Fabric. They remain local to the site.
* Global Scope: To advertise reachability to the rest of the network, the BGP peer must be configured with "Global" scope. This tells the ION that any prefixes learned from this specific neighbor (e.g., the DC Core Switch) should be propagated across the SD-WAN overlay to remote branches. This is the critical setting for enabling branch-to-DC communication for applications hosted behind that BGP peer.
Without "Global" scope, the branches would never learn the routes to the data center subnets.
NEW QUESTION # 16
Which statement is valid when integrating Prisma SD-WAN with Prisma Access remote networks?
Answer: C
Explanation:
Comprehensive and Detailed Explanation
When deploying Prisma Access for Remote Networks (connecting branch offices), the licensing and throughput model is based on aggregate bandwidth allocated to specific compute locations (regions).
Bandwidth Allocation (Option D): Administrators must purchase and allocate a specific amount of bandwidth (e.g., 500 Mbps, 1 Gbps) to a Prisma Access "Compute Location" (e.g., US West, Europe Central). This allocated bandwidth is then shared as a pool among all the branch sites (Remote Networks) that onboard and terminate their IPSec tunnels at that specific location. The system does not allocate bandwidth on a strict per-site basis but rather enforces the limit on the aggregate throughput of the compute node itself.
Policy Enforcement (Option A): Security policies for Prisma Access are enforced in the cloud (at the Prisma Access Service Processing Node), not pushed down to the branch ION devices for local enforcement. The ION device handles local segmentation (ZBFW) and traffic steering, but the "Remote Network" security stack resides in the cloud.
Path Usage (Option C): Prisma SD-WAN is designed to utilize Active/Active paths. When a branch has multiple internet circuits connected to Prisma Access, the CloudBlade and ION automatically build tunnels on all compatible paths and can load-balance traffic across them based on application performance (SLA), rather than defaulting to a strict Active/Standby model for internet traffic.
NEW QUESTION # 17
A network engineer is able to ping and traceroute from SD-WAN branch IP 192.168.1.123 to servers in primary data center - DC1, but is unable to ping or traceroute to a server 10.2.2.22 in the newly configured secondary data center, DC2.
The DC2 ION device is advertising the branch IP subnet 192.168.1.0/24 to the DC2 core via eBGP Core Peer. The DC2 data center site has site prefix 10.2.2.0/23 configured.
Which configuration will resolve the issue in this scenario?
Answer: A
Explanation:
Comprehensive and Detailed Explanation at least 150 to 250 words each from Palo Alto Networks SD-WAN Engineer documents:
In a Prisma SD-WAN deployment, the routing of traffic between branches and Data Centers (DCs) relies on the proper synchronization between the AppFabric (the overlay) and the local routing protocols (the underlay/LAN side). In this scenario, the branch can successfully reach DC1, indicating the branch ION is correctly participating in the fabric. However, traffic to DC2 (10.2.2.22) is failing.
The DC2 site has the site prefix 10.2.2.0/23 configured. In Prisma SD-WAN, defining a site prefix informs the Controller that this specific subnet "belongs" to that site, causing the Controller to advertise reachability for this prefix to all other ION devices in the fabric. Consequently, when the branch ION (192.168.1.123) attempts to reach 10.2.2.22, it correctly identifies DC2 as the destination and encapsulates the traffic toward the DC2 ION.
The bottleneck occurs once the packet arrives at the DC2 ION. While the ION is advertising the branch subnet (192.168.1.0/24) to the DC Core (ensuring the return path), the ION itself must know how to forward the incoming traffic from the branch to the internal DC network. If the DC2 ION does not have a specific route in its local routing table for the 10.2.2.0/23 subnet pointing to the DC Core's internal interface, the packet will be dropped.
According to Palo Alto Networks best practices for Data Center ION deployment, a static default route (0.0.0.0/0) should be configured on the ION device pointing toward the DC Core's next-hop IP address. This ensures that any traffic received from the AppFabric destined for internal DC resources-which are not directly connected to the ION-is successfully handed off to the core switching fabric for final delivery. Adding this default route (Option A) resolves the reachability issue by providing the "last-hop" routing instruction within the DC.
NEW QUESTION # 18
When an ION device has been claimed, the cloud-based controller generates and communicates with the device by which method?
Answer: D
Explanation:
In the Prisma SD-WAN (formerly CloudGenix) architecture, the security and authenticity of device-to- controller communication are paramount. When a new ION (Instant-On Network) device is powered on and connected to the internet, it initiates a secure "phone home" process to the Prisma SD-WAN Cloud Controller.
To ensure that the controller is communicating with a genuine Palo Alto Networks hardware or software instance, the system utilizes a Manufacturer Installed Certificate (MIC).
The MIC is a unique digital certificate burned into the hardware's Trusted Platform Module (TPM) or secure storage during the manufacturing process. This certificate acts as the device's foundational identity. When a customer "claims" a device in the Prisma SD-WAN portal using its serial number, the controller maps that serial number to the specific MIC associated with that unit.
Once the device is claimed and attempts to connect, a mutual TLS (mTLS) handshake occurs. The ION device presents its MIC to the controller to prove its identity, and the controller validates this against its records. This method eliminates the need for manual staging, pre-configuration, or the complexity of managing a Customer Installed Certificate (CIC) or a private Public Key Infrastructure (PKI) during the initial deployment phase. By leveraging the MIC, Prisma SD-WAN achieves true Zero Touch Provisioning (ZTP), ensuring that only authorized, authentic devices can join the fabric and receive configuration policies, thereby maintaining a secure and automated onboarding workflow.
NEW QUESTION # 19
......
