질문 # 12
Refer to the exhibit.
During a planned upgrade to a BIG-IP HA pair running Active/Standby, an outage to application traffic is reported shortly after the Active unit is forced to Standby. Reverting the failover resolves the outage. What should the BIG-IP Administrator modify to avoid an outage during the next failover event? (Choose one answer)
정답：C
설명：
In an Active/Standby BIG-IP design, application availability during failover depends on both units having equivalent data-plane connectivity for the networks that carry application traffic. Specifically:
VLANs are bound to specific interfaces (and optionally VLAN tags).
Floating self IPs / traffic groups move to the new Active device during failover.
For traffic to continue flowing after failover, the new Active device must have the same VLANs available on the correct interfaces that connect to the upstream/downstream networks.
What the symptom tells you:
Traffic works when Device A is Active
Traffic fails when Device B becomes Active
Failback immediately restores traffic
This pattern strongly indicates the Standby unit does not have the VLAN connected the same way (wrong physical interface assignment), so when it becomes Active, it owns the floating addresses but cannot actually pass traffic on the correct network segment.
Why Interface mismatch is the best match:
If the Active unit is already working, its interface mapping is correct.
The fix is to make the Standby unit's VLAN/interface assignment match the Active unit.
That corresponds to changing the Standby device interface to 1.1.
Why the Tag options are less likely here (given the choices and the exhibit intent):
Tag issues can also break failover traffic, but the question/options are clearly driving toward the classic HA requirement: consistent VLAN-to-interface mapping on both devices so the data plane remains functional after the traffic group moves.
Conclusion: To avoid an outage on the next failover, the BIG-IP Administrator must ensure the Standby device uses the same interface (1.1) for the relevant VLAN(s) that carry the application traffic, so when it becomes Active it can forward/receive traffic normally.
질문 # 13
A BIG-IP is configured with a pool member located on a different subnet that is not local to the BIG-IP. To ensure that the return traffic from the pool member is sent to the client through the BIG-IP, a Source NAT (SNAT) is used and configured for SNAT Automap. The BIG-IP has a default gateway on the external VLAN, a floating and non-floating self-IP address on each VLAN, and a management address. Which IP address will the BIG-IP use as the source address for the traffic to the pool member when client traffic is sent through the virtual server?
정답：B
설명：
SNAT Automapis a feature that automatically selects a self-IP address to use as the source address for translated packets. The selection logic follows a strict hierarchy to ensure that traffic is routable back to the BIG-IP:
* Egress VLAN Priority:The BIG-IP first looks at the VLAN through which the traffic is exiting toward the pool member (the egress VLAN).
* Floating Self-IP Preference:If the egress VLAN has afloating self-IP address, the BIG-IP will always prefer it for SNAT Automap. This is critical for High Availability (HA) because, during a failover, the floating IP moves to the new active device, allowing existing connections to be maintained or correctly timed out.
* Non-Floating Fallback:If no floating self-IP is available on the egress VLAN, the system will use a floating self-IP from a different VLAN. If no floating IPs exist at all, it will then fall back to the non- floating self-IP.
Key Data Plane Concept:
The management IP is never used for data plane traffic. In this scenario, since the administrator has configured a floating self-IP, that specific address becomes the source for all SNAT Automap traffic leaving that VLAN to ensure symmetric routing during HA events.
질문 # 14
The network architecture for a BIG-IP consists of an external VLAN and an internal VLAN with two interfaces connected to the upstream switch. The design requires fault tolerance in the case that one of the interfaces is down. Which deployment architecture meets these requirements? (Choose one answer)
정답：D
설명：
Comprehensive and Detailed Explanation From BIG-IP Administration Data Plane Concepts documents:
To meet the requirement of fault tolerance when one interface goes down, BIG-IP must use link aggregation so that loss of a single physical link does not isolate the VLAN(s).
How the objects relate (data plane view)
Interfaces = physical links.
Trunk (LACP) = bundles multiple interfaces into one logical link that provides redundancy (and possibly bandwidth aggregation).
VLANs are assigned to interfaces or trunks. If you need multiple VLANs on the same trunk, they must use 802.1Q tagging (because you can only have one untagged VLAN per interface/trunk).
Self IPs are then placed on the VLANs to provide BIG-IP presence and routing/ARP functions, but self IPs are not what provides link resiliency-the trunk does.
Why Option D is correct
You have two physical interfaces and you want resiliency if one fails → put both interfaces into one trunk with LACP enabled.
You need both external and internal VLANs on those same two links → both VLANs should be configured as tagged on that trunk, so they can coexist on the same aggregated link.
If either physical interface fails, the trunk remains up via the remaining interface, keeping both VLANs operational.
Why the other options are incorrect
A: Two VLANs cannot both be untagged on the same trunk/interface. Only one untagged VLAN is possible; additional VLANs must be tagged.
B: Two trunks "each with one VLAN" would typically mean splitting VLANs across separate trunks. With only two interfaces total, that becomes one interface per trunk-if one interface goes down, the VLAN on that interface is down (no redundancy for that VLAN).
C: Same redundancy problem as B, and disabling LACP removes the negotiated aggregation behavior expected when the switch engineer specifically requested LACP.
질문 # 15
Which statement is true concerning the default communication between a redundant pair of BIG-IP devices?
정답：B
질문 # 16
What type of virtual server should be used to load balance UDP traffic without considering previous connections?
정답：C
설명：
When handling high-volume UDP traffic where the BIG-IP does not need to maintain any session history or relationship between packets, aStatelessvirtual server is the appropriate choice.
* No Connection Tracking:A stateless virtual server does not create or maintain entries in the BIG-IP connection table. This means the system processes each packet as an individual event, without
"considering previous connections" or packets from the same source.
* High Performance:Because the system bypasses the overhead of state management, stateless virtual servers provide the highest possible throughput for UDP and ICMP traffic.
* Use Cases:This is ideal for services like DNS (stateless queries) or some types of syslog traffic where each packet is independent and doesn't require the persistence or protocol inspection typically provided by a full-proxy.
Why other options are incorrect:
* Forwarding:While a Forwarding (IP) virtual server can handle UDP, it still maintains a state entry in the connection table to ensure return traffic is handled correctly.
* Standard:This is a full-proxy virtual server. It is inherently stateful and requires a connection table entry for every flow it manages.
* Reject:This is a special virtual server type that simply drops incoming traffic and, in the case of TCP, sends a reset (RST) or, for UDP, sends an ICMP unreachable message. It is not a load balancing type.
질문 # 17
......
