| Section | Objectives |
|---|---|
| Fire-Resistance & Protection | - Noncombustible Protection & Encapsulation - Concealed Spaces Protection - Fire-Resistance-Rated Assemblies |
| Construction Fire Safety | |
| General & Construction Types | - Construction Classification — Type IV-A, IV-B, IV-C
|
| Inspection Duties & Documentation | - Inspection Reporting and Compliance Verification - Statement of Special Inspections |
| Mass Timber Materials | - CLT, Glulam, NLT, SCL and Engineered Wood Products |
| Structural & Connection Inspection | - Connection Design and Protection - Framing and Structural Elements |
>> 93-Tall-Mass-Timber-Buildings Schulungsunterlagen <<
Wenn Sie sorgen darum, dass die Vorbereitungszeit für International Code Council 93-Tall-Mass-Timber-Buildings nicht genug ist oder wie die autoritative Prüfungsunterlagen finden können, dann können Sie ganz beruhigt sein. Wir PrüfungFrage bieten Ihnen die neuesten Prüfungsunterlagen der International Code Council 93-Tall-Mass-Timber-Buildings, die Ihnen helfen können, innerhalb einer kurzen Zeit auf die International Code Council 93-Tall-Mass-Timber-Buildings Prüfung vorbereitet zu sein. Wir besitzen die autoritativen Prüfungsunterlagen sowie erfahrens und verantwortungsvolles Team. Das Ziel aller Bemühungen von uns ist, dass Sie die International Code Council 93-Tall-Mass-Timber-Buildings Prüfung unbelastet bestehen.
45. Frage
Are mass timber elements permitted to serve as a fire barrier to an adjacent occupancy if they are separated from the interior of the building with an approved thermal barrier consisting of a minimum of 1/2 in. gypsum board or a noncombustible equivalent?
Antwort: C
Begründung:
Yes. The allowance applies to both Type IV-B and Type IV-C construction , making option D correct.
IBC Section 508.4.4.1 regulates the construction of required separations between adjacent occupancies.
Where the required separation is formed by a fire barrier or horizontal assembly, mass timber elements are specifically permitted to serve that function in Type IV-B or Type IV-C construction provided the mass timber is separated from the building interior by an approved thermal barrier.
The prescribed thermal barrier is gypsum board not less than 1/2 inch thick , or another material that has been tested and meets both the Temperature Transmission Fire Test and Integrity Fire Test acceptance criteria of NFPA 275.
The requirement is supplemental to the actual fire-resistance rating required for the occupancy separation. In other words, simply installing 1/2-inch gypsum board does not independently create the required fire barrier; the underlying mass timber assembly must also provide the applicable rated performance.
Type IV-HT is not included in this specific Section 508.4.4.1 mass timber allowance.
References/Topics: 2021 IBC Section 508.4.4.1; Type IV-B and IV-C occupancy separations; NFPA 275 thermal barriers.
46. Frage
Fire-resistance ratings of members and assemblies can be established by all of the following except:
Antwort: A
Begründung:
ASTM E84 cannot be used to establish the hourly fire-resistance rating of a structural member or assembly.
Therefore, option B is correct.
ASTM E84 evaluates surface-burning characteristics , principally flame-spread and smoke-developed indices. Those measurements characterize how a material ' s exposed surface behaves when subjected to the standard tunnel test. They do not demonstrate that a wall, floor, roof, beam, column, or structural assembly will maintain integrity and structural performance for one, two, or three hours.
Fire-resistance ratings are instead established through the methods recognized by the IBC, including standard fire testing-principally ASTM E119 or UL 263-prescriptive rated construction provided by Section 721, and calculated fire-resistance procedures under Section 722. The code also recognizes appropriately documented approved designs and other approved methods within the Section 703 framework.
This distinction is particularly important in mass timber work because ASTM E84 may appear elsewhere in the code for flame-spread limitations on materials, but an acceptable E84 result does not establish structural fire endurance.
The special inspector must determine which approved fire-resistance methodology applies and verify that the installed assembly precisely reflects that design.
References/Topics: 2021 IBC Sections 703, 721 and 722; ASTM E119; UL 263; distinction between fire resistance and ASTM E84 surface-burning testing.
47. Frage
One code-recognized method for calculating the fire-resistance rating of exposed wood members and decking is:
Antwort: A
Begründung:
The intended answer is ANSI/AWC NDS Chapter 16. The video option uses "AWS," but the correct standards organization is the American Wood Council-AWC . Option D is therefore correct based on its intended reference.
IBC Section 722.1 expressly permits exposed wood members and wood decking to have their calculated fire resistance determined in accordance with Chapter 16 of the ANSI/AWC National Design Specification for Wood Construction. The method evaluates charring, the effective char depth, the reduced residual cross section, elevated-temperature effects, loading, and the remaining structural capacity for the required exposure period.
ACI 216.1 applies to concrete and masonry fire resistance. TMS 0216 addresses masonry assemblies. ASCE
29 Chapter 5 provides procedures for calculating the fire resistance of structural steel assemblies. Those references are code-recognized methods, but they apply to different construction materials.
For mass timber inspection, the approved calculations should identify the exposed surfaces, required rating, timber species or product, member dimensions, design loads, protective contribution, and connection treatment. Field reductions in member dimensions can invalidate the calculated fire resistance.
References/Topics: 2021 IBC Section 722.1; ANSI/AWC NDS Chapter 16; calculated fire resistance of exposed wood members and decking.
48. Frage
Refer to the figure by clicking on the EXHIBIT button above.
In Type IV-B construction, unprotected portions of mass timber as shown in the Figure is limited to an area equal to not more than what percentage of the base floor area?
Antwort: C
Begründung:
The figure depicts an unprotected portion of the mass timber ceiling . For Type IV-B construction, Section
602.4.2.2.2, Exception 1.1, limits unprotected ceiling areas-including attached mass timber beams-to 20 percent of the floor area of the applicable dwelling unit or fire area. Option B is therefore correct.
The percentage is based on floor area rather than total ceiling surface area. For example, where the associated fire area contains 1,000 square feet of floor area, the maximum ceiling exposure permitted under this particular exception would be 200 square feet, subject to the additional separation and mixed-exposure provisions.
The 40-percent value in option D applies to mass timber walls, including attached columns , rather than ceilings. The 15-percent and 30-percent values are not the prescribed Type IV-B ceiling exposure limitations in the 2021 IBC.
The inspector must additionally determine whether another exposed wall or ceiling region exists nearby.
Section 602.4.2.2.4 imposes a 15-foot separation requirement, and Section 602.4.2.2.3 controls situations where both wall and ceiling surfaces are intentionally exposed.
References/Topics: 2021 IBC Sections 602.4.2.2.2 through 602.4.2.2.4; Type IV-B ceiling exposure limitations.
49. Frage
In Type IV-C construction, a connection between two members of the primary structural frame supporting a floor is required to be protected to achieve a minimum fire-resistance rating of:
Antwort: B
Begründung:
The required minimum rating is two hours. Under 2021 IBC Table 601, the primary structural frame in Type IV-C construction must provide a two-hour fire-resistance rating. A structural connection joining members of that frame cannot be permitted to fail before the members it connects; consequently, the connection must remain functional for the same required period.
The protection requirement applies to the complete connection assembly. This includes steel plates, hangers, bolts, screws, dowels, fasteners, welds, bearing regions, and portions of the connected timber that form part of the connection. Compliance can be achieved through tested construction, calculated wood cover, Type X gypsum protection, another approved noncombustible system, or a combination documented by the registered design professional.
Option A is insufficient because it would leave a one-hour weakness in a two-hour structural load path.
Option B similarly falls short of the required Table 601 rating. Option D is the Type IV-A primary-frame rating and is not required for the stated Type IV-C condition.
The special inspector must verify protective-cover dimensions and installation before connection hardware becomes concealed, including any project-specific inspection required for calculated wood-cover protection.
References/Topics: 2021 IBC Table 601 and Section 2304.10.1; AWC Fire Design Specification, protection of structural connections.
50. Frage
......
