If you want to find the best NSE5_FSW_AD-7.6 study materials, the first thing you need to do is to find a bank of questions that suits you. Our NSE5_FSW_AD-7.6 learning material is prepared by experts in strict accordance with the exam outline of the NSE5_FSW_AD-7.6 certification exam, whose main purpose is to help students to pass the exam with the least amount of time and effort. We can claim that if you study with our NSE5_FSW_AD-7.6 Practice Engine for 20 to 30 hours, then you will be sure to pass the exam.
| Section | Objectives |
|---|---|
| Topic 1: Deployment and management | - Configure and provision FortiSwitch - Deploy and configure FortiSwitch in a multi-tenancy environment - Deploy FortiSwitch supported deployment topologies |
| Topic 2: Layer 2 control and security | - Use port security options on FortiSwitch - Use ACLs, security profiles, and VLAN security mechanisms on FortiSwitch - Use filtering and antispoofing techniques on FortiSwitch |
| Topic 3: FortiSwitch concepts | - Configure the ports required for stack deployment - Configure switching and routing on FortiSwitch - Configure STP to prevent network loops - Configure switch ports, split port, and available transceivers - Use QoS and LLDP-MED on FortiSwitch - Configure VLANs using FortiSwitch |
| Topic 4: Monitoring and troubleshooting | - Interpret system logs, monitor port statistics, and diagnose connectivity issues - Use packet capturing methods to monitor and troubleshoot traffic issues - Use tools to view and extract network information from FortiSwitch - Troubleshoot FortiLink issues |
In order to help you more DumpExam the Fortinet NSE5_FSW_AD-7.6 exam eliminate tension of the candidates on the Internet. NSE5_FSW_AD-7.6 study materials including the official Fortinet NSE5_FSW_AD-7.6 certification training courses, Fortinet NSE5_FSW_AD-7.6 self-paced training guide, NSE5_FSW_AD-7.6 exam DumpExam and practice, NSE5_FSW_AD-7.6 Online Exam NSE5_FSW_AD-7.6 study guide. NSE5_FSW_AD-7.6 simulation training package designed by DumpExam can help you effortlessly pass the exam. Do not spend too much time and money, as long as you have DumpExam learning materials you will easily pass the exam.
NEW QUESTION # 34
Refer to the exhibit.
You run the command diagnose switch physical-ports summary on FortiSwitch.
Based on exhibit, what does the output indicate to about the FortiSwitch mode? (Choose one answer)
Answer: A
Explanation:
According to the FortiSwitchOS 7.6 Administration Guide and the FortiSwitch 7.6 Study Guide , the diagnose switch physical-ports summary command provides an overview of physical interface states, VLAN memberships, duplex/speed parameters, and port encapsulation flags.
When a FortiSwitch operates in managed mode via FortiLink, two distinct characteristics appear in this command output:
* Management VLAN Assignment: The FortiLink control plane automatically establishes a dedicated management VLAN-by default, VLAN 4094 -and assigns it to the internal discovery interfaces and uplinks.
* Encapsulation Flags: Interfaces participating in the FortiLink fabric or Inter-Switch Links (ISLs) are assigned the TF (Forti Trunk) flag to indicate proprietary FortiLink management framing.
In the provided exhibit, every single interface (from port1 through port24, as well as the virtual internal interface) is assigned to default Vlan 1 . Furthermore, looking at the Flags column, port5 has QS (standard
802.1Q) and TL (standard LACP trunk), but no TF (Forti Trunk) flag is present on any interface. The absence of VLAN 4094, the complete absence of the TF flag, and the presence of the default factory VLAN 1 mapping confirm that this device is operating in standalone mode (Option C) .
Regarding the incorrect options: Option A is incorrect because port5 is bundled into a standard LACP 802.1Q trunk (QS, TL), not configured purely as an access port. Option B is incorrect because this output reflects Layer 2 switchport properties rather than Layer 3 routing interfaces. Option D is incorrect because managed mode would display FortiLink-specific VLANs and TF trunk flags.
NEW QUESTION # 35
Refer to the exhibit.
The profile shown in the exhibit is assigned to a group of managed FortiSwitch ports, and these ports are connected to endpoints which are powered by PoE.
Which configuration action can you perform on the LLDP profile to cause these endpoints to exchange PoE information and negotiate power with the managed FortiSwitch?
Answer: A
Explanation:
To cause endpoints to exchange PoE information and negotiate power with the managed FortiSwitch via LLDP, you should configure the LLDP profile to include power management in the advertised LLDP-MED TLVs. Here are the steps:
* Access the LLDP Profile Configuration:Start by entering the LLDP profile configuration mode with the command:
config switch-controller lldp-profile
edit "LLDP-PROFILE"
* Enable MED-TLVs:Ensure that MED-TLVs (Media Endpoint Discovery TLVs) are enabled. These TLVs are used for extended discovery relating to network policies, including PoE, and are essential for PoE negotiation. They include power management which is crucial for the negotiation of PoE parameters between devices. The command to ensure network policies are set might look like:
set med-tlvs network-policy
* Add Power Management TLV:Specifically add or ensure the power management TLV is part of the configuration. This will advertise the PoE capabilities and requirements, enabling dynamic power allocation between the FortiSwitch and the connected devices (like VoIP phones or wireless access points). This can typically be done within the network-policy settings:
config med-network-policy
edit <policy_index>
set poe-capability
next
end
* Save and Apply Changes:Exit the configuration blocks properly ensuring changes are saved:
End
* Verify Configuration:It's always good practice to verify that your configurations have been applied correctly. Use the appropriateshoworgetcommands to review the LLDP profile settings.
By adding the power management as part of LLDP-MED TLVs, the FortiSwitch will be able to communicate its power requirements and capabilities to the endpoints, thereby facilitating a dynamic power negotiation that is crucial for efficient PoE utilization.
References:For more detailed information and additional configurations, you can refer to the FortiSwitch Managed Switches documentation available on Fortinet's official documentation site:Fortinet Product Documentation
NEW QUESTION # 36
Which statement best describes a benefit of using MAC, IP address, or protocol-based VLAN assignments on FortiSwitch? (Choose one answer)
Answer: D
Explanation:
According to theFortiSwitchOS 7.6 Administration Guideand theFortiSwitch 7.6 Study Guide, MAC- based, IP-based, and protocol-based VLAN assignments are methods ofdynamic VLAN assignment. These features allow the switch to categorize incoming traffic and assign it to a specific VLAN based on the packet's attributes rather than just the physical port it is connected to.3 The primary benefit of these methods is that theyoffer dynamic segmentation benefits similar to 802.1X authentication (Option D). In a modern network, devices with different security requirements (such as IoT devices, printers, and workstations) often connect to the same physical switch ports. 802.1X is the "gold standard" for dynamic segmentation but requires a supplicant on the client device.4For devices that do not support 802.1X, MAC or protocol-based assignments provide a similar result: they ensure the device is automatically placed into its designated secure segment (VLAN) the moment it is identified by the switch.
* MAC-based:Assigns a VLAN based on the source MAC address.
* IP-based:Assigns a VLAN based on the source IP address or subnet.
* Protocol-based:Assigns a VLAN based on the Ethernet type (e.g., IPv4, IPv6, or AppleTalk).
Option A is incorrect because these features complement rather than "disable" 802.1X. Option B is incorrect because these specific assignment types can be configured locally on the switch without a RADIUS server.
Option C is the opposite of how these features work, as they explicitly look at the device type or traffic to make an assignment.
NEW QUESTION # 37
Refer to the exhibit.
PC1 connected to port1 has joined multicast group 225.1.2.3 on VLAN 10 with IGMP snooping enabled.
What will happen if you disable IGMP snooping on FortiSwitch? (Choose one answer)
Answer: A
Explanation:
According to theFortiSwitchOS 7.6 Administration Guideand theFortiSwitch 7.6 Study Guide, Internet Group Management Protocol (IGMP) snooping is a Layer 2 mechanism that allows a switch to " listen " to IGMP conversations between hosts and routers to maintain a map of which ports require specific multicast streams.
When IGMP snooping is enabled, the switch populates aMulticast Layer 2 Forwarding Table(as shown in the exhibit), which ensures that multicast traffic is only forwarded to ports where a receiver has explicitly requested it (e.g., PC1 on port1).
When IGMP snooping isdisabled, the switch no longer maintains this granular forwarding table. By default, a Layer 2 switch that is not performing IGMP snooping treats multicast traffic as if it werebroadcast traffic.
Consequently, instead of being intelligently forwarded only to the interested receiver (PC1), the multicast traffic for group 225.1.2.3 will beflooded to all portswithin the same VLAN (VLAN 10). This means PC2, even if it has not joined the group, will receive the multicast packets at the physical layer, leading to unnecessary bandwidth consumption and increased CPU load on unintended recipients.
The documentation explicitly states that disabling IGMP snooping reverts the switch to a " flood-all " behavior for multicast frames within the broadcast domain. Option A is incorrect because the host (PC1) remains a member of the group; only the switch ' s forwarding logic changes. Option B is incorrect as the switch may still see the messages but will not act on them to prune ports. Option D is incorrect as disabling the feature removes the prune/stop mechanism, causing traffic to flow everywhere rather than stopping.
NEW QUESTION # 38
Refer to the exhibit.
FortiSwitch 802.1X port security configuration is shown. A user connects their laptop to the port and attempts to authenticate using 802.1X, but enters the wrong credentials multiple times. What will the result to the device be? (Choose one answer)
Answer: A
Explanation:
According to theFortiSwitchOS 7.6 Administration Guideand theFortiSwitch 7.6 Study Guide, 802.1X port security allows administrators to define specific actions based on the outcome of an authentication attempt. The configuration exhibit shows a security policy named "Students" with two specialized VLAN assignments enabled: aGuest VLANand anAuthentication fail VLAN.
In FortiSwitchOS 7.6, these two settings serve distinct purposes based on the client's behavior:
* Guest VLAN (Option C):This is used when a connected device doesnothave an 802.1X supplicant (software) or does not respond to EAP (Extensible Authentication Protocol) requests within the specified "Guest authentication delay". In this scenario, the device is moved to the "onboarding" VLAN to allow for basic network access or software downloads.
* Authentication fail VLAN (Option A):This is triggered specifically when a devicedoesattempt to authenticate via 802.1X but the authentication server (RADIUS) returns anAccess-Rejectmessage, typically due toincorrect credentials.
As stated in the scenario, the userattemptsto authenticate but enters thewrong credentials. According to the policy shown in the exhibit, theAuthentication fail VLANis enabled and set to"quarantine.fortilink (quarantine)". Therefore, the FortiSwitch will logically move the port's traffic into the quarantine VLAN, isolating the user from the production network due to the failed login attempt. Option B is incorrect as there is no "shutdown" action configured, and Option D refers to a default state that is overridden by the explicit failure policy.
NEW QUESTION # 39
......
