| Section | Weight | Objectives |
|---|---|---|
| Topic 1: Health Monitors and Persistence | 20-25% | - OneConnect and connection multiplexing - Fallback host and persistence TTL - Monitor assignment and interval settings - Persistence profiles (Cookie, Source Address, Universal) - Monitor types and configurations |
| Topic 2: LTM Fundamentals | 15-20% | - Configuration architecture and files - Licensing types - License and provisioning modules - Objects and their relationships - Traffic Management Shell (tmsh) CLI |
| Topic 3: Traffic Management Features | 15-20% | - iRules basics and events - Compression and caching profiles - HTTP profile settings - Connection limits and rate shaping - OneConnect - NAT and SNAT concepts |
| Topic 4: SSL/TLS Configuration | 15-20% | - SSL termination and re-encryption - SSL profiles (Client and Server) - Cipher groups and compatibility - Certificate validation settings - Certificate and key management |
| Topic 5: Virtual Servers and Pools | 25-30% | - Priority group activation - Load balancing algorithms - Node and pool management - Address translation and port translation - Pool configuration and members - Virtual server types (Standard, Forwarding, Performance L4, Regex) - Virtual server configuration options |
トレントのF5CAB3ガイドは、これらすべての質問を解決してF5CAB3試験に合格するのに役立ちます。 弊社Pass4TestのF5CAB3学習資料は、暦年の試験概要と業界動向に従って、長年にわたって多くの専門家によって簡素化され、まとめられています。 したがって、F5CAB3学習教材は理解しやすく、把握しやすいです。 人生には、自分の業界を変えたい人もたくさんいます。 彼らはしばしば、業界に参入するための足がかりとして専門的なF5CAB3資格試験を受けます。 あなたがこれらの人々の1人である場合、F5のF5CAB3試験エンジンが最良の選択となります。
質問 # 78
A BIG-IP Administrator adds new pool members into a highly utilized pool. Users report application failures.
Which pool-level setting should be checked?
正解：D
解説：
Slow Ramp Time prevents new pool members from receiving full traffic immediately, avoiding overload.
質問 # 79
In a pool there are 2 pool members out of the 5 members that are older servers. The number of connections these can handle is less than the other 3 pool members. Which load balancing method would allow more traffic to be directed to the newer servers? (Choose one answer)
正解：D
解説：
When a pool contains servers with heterogeneous hardware capabilities (differing CPU, RAM, or connection limits), a static load balancing method like Round Robin is ineffective because it distributes requests equally, regardless of the server's capacity. To optimize traffic distribution for newer, more powerful servers, a dynamic or weighted method is required.
Weighted Least Connections (member): This is the ideal method for this scenario. It combines two factors:
Least Connections: It first checks the current active connection count to ensure traffic goes to the least busy server.
Weight (Ratio): It allows the administrator to assign a "Ratio" value to each pool member. Newer servers can be assigned a higher ratio (e.g., 3) while older servers are assigned a lower ratio (e.g., 1). The BIG-IP system uses these weights to disproportionately favor the newer servers even when connection counts are similar.
Why other options are incorrect:
Global Availability: This is primarily a GSLB (Global Server Load Balancing) or specific LTM priority group concept where traffic is sent to the first available member in a list until it fails, then moves to the next. It does not load balance based on capacity.
Round Robin: This passes each new connection request to the next server in line, treating the old and new servers exactly the same.
Least Connections (member): While this sends traffic to the server with the fewest active connections, it assumes all servers are equal. If an old server and a new server both have 10 connections, they are treated as equally capable of taking the 11th, which is not true in this scenario.
質問 # 80
Refer to the exhibit.
DNS queries from two internal DNS servers are being load-balanced to external DNS servers via a virtual server on a BIG-IP device. The DNS queries originate from:
192.168.10.100
192.168.10.200
and target:
192.168.2.150
All DNS queries destined for the external DNS servers fail.
Which property change should the BIG-IP Administrator make in the Virtual Server to resolve this issue?
(Choose one answer)
正解：A
解説：
DNS traffic is primarily transported using UDP port 53. In the exhibit, the Virtual Server is configured with the Protocol set to TCP, which prevents standard DNS queries from being processed correctly. BIG-IP Virtual Servers must be configured with the correct Layer 4 protocol to match the application traffic they are handling.
According to the BIG-IP Administration: Data Plane Configuration documentation:
The Protocol setting on a Virtual Server defines whether traffic is processed as TCP, UDP, or another supported transport protocol.
Standard DNS queries and responses use UDP, while TCP is only required for DNS zone transfers (AXFR) or exceptionally large responses.
When a DNS Virtual Server is incorrectly configured with TCP, UDP-based DNS queries are dropped, causing all requests to fail.
Why the other options are incorrect:
A). Protocol profile (Client) to DNS_OPTIMIZEDA DNS profile enhances DNS functionality but does not correct an incorrect transport protocol configuration.
B). Type to Performance (HTTP)Performance (HTTP) Virtual Servers are designed for HTTP traffic and are not suitable for DNS services.
C). Source Address to 192.168.10.0/24The existing source IPs already fall within the allowed range, so this setting does not address the failure.
Correct Resolution:
Changing the Protocol to UDP aligns the Virtual Server with standard DNS transport requirements, allowing DNS queries to be successfully processed and load-balanced.
質問 # 81
A BIG-IP Administrator creates a new Virtual Server to load balance SSH traffic. Users are unable to log on to the servers.
What should the BIG-IP Administrator do to resolve the issue?
正解：D
解説：
SSH is a TCP Layer 4 protocol. Applying an HTTP profile causes BIG-IP to expect HTTP headers, breaking SSH sessions. Removing the HTTP profile allows raw TCP forwarding.
質問 # 82
A BIG-IP Administrator configures a node with a standard icmp Health Monitor. The Node shows as DOWN although the Backend Server is configured to answer ICMP requests. Which step should the administrator take next to find the root cause of this issue?
正解：D
解説：
In the F5 BIG-IP ecosystem, a standard ICMP health monitor functions by sending an ICMP echo request to a target node and expecting an ICMP echo reply within a specified timeout period. When a node is marked " DOWN " despite the backend server being configured to respond to ICMP, the issue typically lies in the network path or the specific packet exchange between the BIG-IP ' s self IP and the node ' s IP. Running a tcpdump is the most effective next step because it provides a real-time packet capture of the actual monitor traffic leaving the BIG-IP and any return traffic coming back from the server. This allows the administrator to verify if the BIG-IP is actually sending the echo request, if the request is reaching the server, and if the server is indeed replying or if the reply is being dropped by an intermediate firewall or a security policy.
While other tools have their place, they are inappropriate for this specific layer 3/4 connectivity issue. A qkview is a comprehensive diagnostic file used primarily for F5 Support to analyze the entire system ' s state but is overkill for initial connectivity troubleshooting. An ssldump is used for inspecting SSL/TLS handshakes and encrypted payloads, which is irrelevant for a non-encrypted ICMP monitor. A curl command is a tool for testing HTTP/HTTPS application-level responses; it cannot be used to troubleshoot ICMP (ping) connectivity directly. By using tcpdump -ni < vlan_name > host < node_ip > , the administrator can see the ICMP " type 8 " (request) and " type 0 " (reply) packets, immediately identifying if the monitor failure is due to a " Destination Unreachable " message or a simple lack of response, thereby pinpointing the root cause in the data plane.
質問 # 83
......
