| Section | Objectives |
|---|---|
| Topic 1: Structural Inspection | - Connections and fastening systems - Mass timber structural elements - Structural loads and related code requirements |
| Topic 2: Fire Protection and Fire-Resistance | - Noncombustible protection and protection of mass timber elements - Fire-resistance requirements - Fire protection systems and related provisions |
| Topic 3: Construction Fire Safety | - Construction-phase fire safety requirements - International Fire Code requirements - Protection of mass timber during construction |
| Topic 4: Tall Mass Timber Building Code Provisions | - International Building Code requirements for tall mass timber construction - Types IV-A, IV-B and IV-C construction - Mass timber materials and construction requirements |
| Topic 5: Special Inspection Requirements | - Special inspection procedures for tall mass timber buildings - Inspection of connections and protective materials - Inspector duties and responsibilities |
| Topic 6: Code Compliance and Related Requirements | - Documentation and verification of compliance - Sound transmission requirements - Energy code requirements applicable to mass timber buildings |
>> 93-Tall-Mass-Timber-Buildings Exam Topics Pdf <<
Pass4cram field is leaping up day by day and more people are pursuing it as a career than ever. Due to these reasons, candidates find it difficult to land their dream job and often face difficulty in finding the right career opportunities. But to overcome this issue, the 93-Tall-Mass-Timber-Buildings Exam is introduced by International Code Council that provides candidates with a sustainable platform to examine their true capabilities and surf through their desired opportunities.
NEW QUESTION # 21
The International Building Code requires cross-laminated timber (CLT) to be manufactured and identified in accordance with which standard?
Answer: A
Explanation:
The governing standard is ANSI/APA PRG 320, Standard for Performance-Rated Cross-Laminated Timber.
Therefore, option A is correct. The 2021 IBC requires structural glued cross-laminated timber to be manufactured and identified in accordance with PRG 320, and Type IV provisions require CLT to bear a label demonstrating conformity with that standard.
PRG 320 addresses essential manufacturing and qualification requirements, including panel construction, layup, structural performance, adhesive qualification, dimensional tolerances, product marking and quality assurance. Product identification is particularly important to the special inspector because visual similarity alone does not establish that a panel is code compliant.
DOC PS 2 applies primarily to wood structural panels such as plywood and oriented strand board and is not the manufacturing standard for CLT. ANSI/AITC or ANSI/APA A190.1 applies to structural glued-laminated timber, commonly called glulam. ASTM D5055 covers the establishment and monitoring of structural capacities for prefabricated wood I-joists.
The inspector should verify that CLT panels retain legible identification and that the manufacturer, grade, layup and panel designation correspond to the approved construction documents.
References/Topics: 2021 IBC Sections 602.4 and 2303.1.4; Chapter 35; ANSI/APA PRG 320-2019.
NEW QUESTION # 22
For a sprinklered Business Occupancy (Group B) in a 15-story building of Type IV-A construction, the maximum allowable building area is:
Answer: A
Explanation:
The calculation begins with 2021 IBC Table 506.2. Because the building is a Group B occupancy, has more than one story, and is protected throughout by an automatic sprinkler system complying with Section
903.3.1.1, the applicable tabular classification is "SM"-a multistory, fully sprinklered building.
For Group B and Type IV-A construction, Table 506.2 assigns an SM allowable area factor of 324,000 square feet. However, this is not the final total allowable building area. Section 506.2.1 requires a single-occupancy building with more than three stories above grade plane to use Equation 5-2. Where no frontage increase is stated, the calculation is:
324,000 square feet ร 3 = 972,000 square feet.
The story-area multiplier is limited to three even though the building contains 15 stories. The code does not permit multiplying 324,000 square feet by all 15 stories. Additionally, the actual area of an individual story cannot exceed its calculated allowable area. Option A represents a different construction-type area factor, while option B does not result from the required IBC multistory calculation. The building is not automatically unlimited merely because it is Type IV-A and sprinklered.
References/Topics: 2021 IBC Sections 506.2 and 506.2.1; Equation 5-2; Table 506.2, Group B, Type IV-A, SM area factor.
NEW QUESTION # 23
Which of the following is true regarding fire-resistance rating protection provided by noncombustible covering material?
Answer: A
Explanation:
IBC Table 722.7.1(2) assigns a 40-minute protection contribution to 5/8-inch Type X gypsum board .
Therefore, option D is correct.
The same table assigns 25 minutes to 1/2-inch Type X gypsum board. Consequently, option B overstates the protection contribution of the thinner Type X panel. Ordinary gypsum board values appearing elsewhere in Section 722 cannot simply be substituted for the specific mass timber noncombustible protection values in Table 722.7.1(2). Options A and C therefore do not state the protection contribution recognized by the mass timber table.
These assigned values are particularly important when multiple layers are required. For example, a two-hour building element requires at least 80 minutes of noncombustible protection under Table 722.7.1(1), which can be satisfied prescriptively with two properly installed layers of 5/8-inch Type X gypsum board, each contributing 40 minutes.
The contribution is valid only when the gypsum board is installed and fastened in accordance with Section
722.7.2.
References/Topics: 2021 IBC Tables 722.7.1(1) and 722.7.1(2); Section 722.7.2; Type X gypsum noncombustible protection.
NEW QUESTION # 24
The time, in minutes, contributed to the fire resistance rating by the noncombustible protection of mass timber building elements, components, or assemblies, shall be established through a comparison of assemblies tested using procedures set forth in ASTM Standard:
Answer: B
Explanation:
The applicable standard is ASTM E119 , making option B correct. IBC Section 703.6 establishes a performance method for determining the number of minutes contributed by noncombustible protection applied to mass timber.
The methodology requires two otherwise identical assemblies to be evaluated using the procedures of ASTM E119 or UL 263 . Test Assembly 1 is tested without the protective covering. Test Assembly 2 incorporates the representative noncombustible protection, including its actual configuration, attachment details, joint treatment, accessories, and other relevant installation conditions. The protection contribution is then calculated by subtracting the fire-resistance time of the unprotected assembly from that of the protected assembly.
ASTM E119 is specifically designed to evaluate fire endurance of building construction and structural assemblies under standardized fire exposure. ASTM D3498, by contrast, is an adhesive specification referenced by the IBC for sealing certain mass timber interfaces. The other standards listed are not the prescribed comparative fire-resistance test for this determination.
References/Topics: 2021 IBC Sections 703.6 and 722.7.1; ASTM E119; UL 263; determination of noncombustible protection time contribution.
NEW QUESTION # 25
Refer to the figure by clicking on the EXHIBIT button above.
In Type IV-B construction, unprotected portions of mass timber as shown in the Figure is limited to an area equal to not more than what percentage of the base floor area?
Answer: D
Explanation:
The highlighted exposed surfaces in this figure are mass timber wall surfaces . Under 2021 IBC Section
602.4.2.2.2, Exception 1.2, unprotected portions of Type IV-B mass timber walls, including attached columns, are permitted up to an area equal to 40 percent of the floor area in the applicable dwelling unit or fire area.
Option D is therefore correct.
This should be distinguished from the corresponding ceiling limitation. Unprotected mass timber ceilings, including attached beams, are limited to 20 percent of floor area. The larger 40-percent allowance applies specifically to wall exposure.
Where only wall surfaces are exposed, the allowable wall area is calculated directly from the base floor area.
For example, a 1,000-square-foot fire area would permit up to 400 square feet of exposed wall surface under this exception. However, Section 602.4.2.2.4 additionally requires unprotected wall portions to maintain the prescribed 15-foot separation from other applicable exposed wall or ceiling portions.
Where exposed walls and exposed ceilings occur together, the individual 40- and 20-percent limits cannot simply be maximized simultaneously; the mixed-exposure equation in Section 602.4.2.2.3 governs.
References/Topics: 2021 IBC Sections 602.4.2.2.2 through 602.4.2.2.4; Type IV-B wall exposure.
NEW QUESTION # 26
......
