NEW QUESTION # 68
In a pool there are 2 pool members out of the 5 members that are older servers. The number of connections these can handle is less than the other 3 pool members. Which load balancing method would allow more traffic to be directed to the newer servers? (Choose one answer)
Answer: C
Explanation:
When a pool contains servers with heterogeneous hardware capabilities (differing CPU, RAM, or connection limits), a static load balancing method like Round Robin is ineffective because it distributes requests equally, regardless of the server's capacity. To optimize traffic distribution for newer, more powerful servers, a dynamic or weighted method is required.
* Weighted Least Connections (member): This is the ideal method for this scenario. It combines two factors:
* Least Connections: It first checks the current active connection count to ensure traffic goes to the least busy server.
* Weight (Ratio): It allows the administrator to assign a "Ratio" value to each pool member. Newer servers can be assigned a higher ratio (e.g., 3) while older servers are assigned a lower ratio (e.g.,
1). The BIG-IP system uses these weights to disproportionately favor the newer servers even when connection counts are similar.
* Why other options are incorrect:
* Global Availability: This is primarily a GSLB (Global Server Load Balancing) or specific LTM priority group concept where traffic is sent to the first available member in a list until it fails, then moves to the next. It does not load balance based on capacity.
* Round Robin: This passes each new connection request to the next server in line, treating the old and new servers exactly the same.
* Least Connections (member): While this sends traffic to the server with the fewest active connections, it assumes all servers are equal. If an old server and a new server both have 10 connections, they are treated as equally capable of taking the 11th, which is not true in this scenario.
NEW QUESTION # 69
Refer to the exhibit.
A BIG-IP Administrator configures a Virtual Server to handle HTTPS traffic. Users report that the application is NOT working. Which additional configuration is required to resolve this issue?
Answer: B
Explanation:
According to the provided exhibit, the "SSL Profile (Client)" section in the Virtual Server configuration is empty. For a BIG-IP system to process HTTPS traffic, it must act as an SSL/TLS endpoint. This process, known as SSL Termination or SSL Offload, requires the assignment of a Client SSL Profile to the Virtual Server. Without this profile, the BIG-IP does not have the necessary certificate and private key information to perform the SSL handshake with the client's browser. Consequently, when a user attempts to connect via HTTPS, the TCP connection may establish, but the SSL handshake will fail because the BIG-IP will not know how to decrypt the incoming encrypted packets.
A Client SSL profile defines the ciphers, certificates, and keys that the BIG-IP uses to communicate securely with the client. In a standard HTTPS deployment, the BIG-IP decrypts the traffic and can then send it to the backend pool members either as plain text (header insertion/manipulation) or re-encrypt it using a Server SSL profile. While a Server SSL profile (Option C) is needed if the backend servers themselves require HTTPS, the initial failure for a user reaching a Virtual Server is almost always the lack of a Client SSL profile to terminate the user's connection. Changing the Service Port to HTTP (Option D) would be incorrect because the goal is to handle HTTPS traffic (typically port 443). Assigning the "clientssl" or a custom client-side profile from the "Available" list to the "Selected" list in the GUI is the mandatory step to make the Virtual Server operational for secure web traffic.
NEW QUESTION # 70
The BIG-IP Administrator has configured an HTTP health monitor applied to a Pool of HTTP web servers hosting www.f5.com, but all Pool Members show a DOWN status. The web server is returning a response of '
400 Bad Request ' . What would be the correct monitor Send string?
Answer: A
Explanation:
A 400 Bad Request response from an HTTP/1.1 web server is a definitive indicator that the HTTP request sent by the health monitor is missing a required Host header . In HTTP/1.1, the Host header is mandatory per RFC 7230. Web servers - particularly those hosting named virtual hosts such as www.f5.com - will reject any HTTP/1.1 request that omits the Host header, returning a 400 error, which the BIG-IP monitor interprets as a failed health check, marking all members DOWN.
The correct Send string must include:
* The GET request line with HTTP/1.1 protocol declaration
* A \r\n (carriage return + line feed) after the request line
* The Host: www.f5.com header to satisfy HTTP/1.1 requirements
* A \r\n after the Host header
* Connection: Close header to instruct the server to close the connection after responding
* A final \r\n\r\n to properly terminate the HTTP request headers
Only option C satisfies all these requirements with the correct syntax and Host header inclusion.
Option D (the current configured string) omits the Host header entirely - the root cause of the 400 error.
Options A and B are structurally incomplete or syntactically malformed.
Reference: BIG-IP Administration - Data Plane Configuration, Module: Health Monitors - HTTP Monitor Send String Configuration and HTTP/1.1 Host Header Requirements.
NEW QUESTION # 71
The BIG-IP Administrator has to provide encrypted communication between users and the virtual server they access. Multiple hostnames are configured in DNS with the same IP address.
Which profile type and setting in the profile should be used? (Choose one answer)
Answer: A
Explanation:
When multiple hostnames resolve to the same IP address and encrypted communication is required, the BIG- IP must be able to present the correct SSL certificate based on the hostname requested by the client. This is accomplished using Server Name Indication (SNI).
According to BIG-IP Administration: Data Plane Configuration documentation:
* SNI is a client-side TLS extension, where the client includes the requested hostname during the SSL handshake.
* BIG-IP evaluates this hostname using the Client SSL profile, not the Server SSL profile.
* The "Server Name" setting in the Client SSL profile enables BIG-IP to select the appropriate SSL certificate for the requested hostname.
Why option C is correct:
* Client SSL profile handles inbound (client-side) encryption.
* Server Name enables SNI-based certificate selection when multiple DNS names share the same virtual server IP.
Why the other options are incorrect:
* A. Client SSL, Client NameThere is no Client SSL setting called Client Name for SNI certificate selection.
* B. Server SSL, Server NameServer SSL is used for encryption between BIG-IP and backend servers, not for client-side hostname identification.
* D. Server SSL, Client NameServer SSL does not process client-requested hostnames during TLS negotiation.
Correct Resolution:
Configure a Client SSL profile and enable the Server Name (SNI) setting to support multiple encrypted hostnames on the same virtual server IP.
NEW QUESTION # 72
The BIG-IP Administrator needs to load balance a pool of web servers. Load balancing should consider the number of connections that are active on that pool member.
Which load balancing method meets this requirement? (Choose one answer)
Answer: B
Explanation:
The requirement states that load balancing decisions must be based on the number of active connections on each pool member. This directly maps to the Least Connections (member) load balancing method.
According to the BIG-IP Administration: Data Plane Configuration documentation:
* Least Connections (member) selects the pool member with the fewest active connections at the time of the request.
* This method dynamically adapts to real-time traffic patterns and ensures that more heavily loaded pool members receive fewer new connections.
* It is especially effective for web servers where connection duration may vary and equal distribution of active sessions is desired.
Why the other options are incorrect:
* B. Round RobinDistributes connections sequentially without considering current load or active connections.
* C. Ratio (member)Distributes traffic based on static ratios, not real-time connection counts.
* D. Ratio (node)Uses predefined ratios at the node level and does not account for active connection counts.
Correct Resolution:
Using Least Connections (member) ensures that new connections are directed to the pool member currently handling the fewest active connections, meeting the stated requirement.
