質問 # 203
On the OSPFv3 network shown in the figure:
* OSPFv3 is enabled on the interfaces connecting R1, R2, and R3.
* The router ID of each router is 10.0.X.X, where X is the number of the router.
* If you check detailed information about an LSA on R3, the command output shows that the LSA is generated by R2 and describes the IPv6 prefix address associated with the Router-LSA.
Is this statement TRUE or FALSE?
正解：B
解説：
Comprehensive and Detailed In-Depth Explanation:
Understanding the LSA Table in the Figure
The LSA Type displayed in the LSDB of R3 is an Intra-Area-Prefix-LSA (Type 9), with the following attributes:
* LS Type: Intra-Area-Prefix-LSA (Type 9)
* Link State ID: 0.0.0.1
* Originating Router: 10.0.2.2 (R2)
* Referenced LSA Type: 0x2001 (Router-LSA, Type 1)
* Referenced Link State ID: 0.0.0.0
* Referenced Originating Router: 10.0.2.2 (R2)
* Prefix: 2000:2::/128
Analysis of the Statement
* What is an Intra-Area-Prefix-LSA (Type 9)?
* Used in OSPFv3 to advertise IPv6 prefixes associated with a Router-LSA (Type 1) or Network- LSA (Type 2).
* Each router generates its own Router-LSA (Type 1) and references it in an Intra-Area-Prefix- LSA (Type 9).
* How does this apply to R3 ' s LSDB?
* The LSA is generated by R2 (10.0.2.2), meaning R2 originated the prefix advertisement.
* The referenced LSA is a Router-LSA, indicating that the IPv6 prefix is associated with R2 ' s router advertisement.
* Since R3 sees this LSA in its LSDB, it means R2 has advertised its IPv6 prefix (2000:2::/128) into the OSPFv3 domain.
# Since the LSA describes an IPv6 prefix associated with R2's Router-LSA, the statement is TRUE.
Final Conclusion:
# The LSA is generated by R2 and describes the IPv6 prefix associated with the Router-LSA.
# Thus, the correct answer is: A. TRUE.
Reference:
HCIP-Datacom-Advanced Routing & Switching Technology V1.0 - OSPFv3 LSA Types and IPv6 Prefix Advertisement Huawei Official HCIP-Datacom Study Guide - OSPFv3 Intra-Area-Prefix-LSA and Router-LSA Relationship Huawei Documentation on OSPFv3 LSAs and Neighbor Advertisement
質問 # 204
On the network shown in the figure, EBGP peer relationships are established between neighboring routers through directly connected interfaces.
* The router ID of each router is 10.0.X.X, and the AS number is 6500X, where X is the number of the router.
* Both R1 and R4 have static routes to 192.168.1.0/24, which are imported to BGP through the import- route command.
* R1 adds a community attribute (1:1) to the route before advertising it to its peers.
* All routers are configured to propagate community attributes.
* R3 is configured with a routing policy that rejects routes with the community attribute 1:1.
In this case, which of the following is the path for traffic from R3 to 192.168.1.0/24?
正解：A
解説：
Comprehensive and Detailed In-Depth Explanation:
Understanding the BGP Network Topology in the Question:
* BGP Peering & Route Distribution
* Each router forms EBGP peer relationships with directly connected neighbors.
* R1 and R4 import the static route 192.168.1.0/24 into BGP and advertise it to their peers.
* Community attributes are attached to routes to influence routing policies.
* Effect of Community Attribute 1:1
* R1 marks 192.168.1.0/24 with community 1:1 before advertising it.
* R3 has a policy that rejects any routes with community attribute 1:1.
* Since R1's advertisement contains 1:1, R3 will not accept 192.168.1.0/24 from R2.
Route Selection and Traffic Flow Analysis:
* R1 advertises 192.168.1.0/24 with community 1:1 to R2.
* R3 rejects this route from R2 because of the configured routing policy.
* R4 also advertises 192.168.1.0/24 to its EBGP neighbors without community 1:1.
* R5 learns the route from R4 and advertises it to R3.
* Since R5's advertisement does not include community 1:1, R3 accepts the route from R5.
* Thus, the best available path for R3 to reach 192.168.1.0/24 is R3 # R5 # R1.
# Correct Path: R3 # R5 # R1
Checking Each Option:
# Option A: R3 # R2 # R4 (Incorrect)
* R3 does not learn the route from R2 because it rejects community 1:1.
* Since R1 added 1:1, and R2 propagated the same community, R3 will not accept this path.
# Option B: R3 does not have a route to 192.168.1.0/24 (Incorrect)
* R3 does have a route, but it learns it from R5 instead of R2.
# Option C: R3 # R2 # R1 (Incorrect)
* R1 marked the route with 1:1, and R2 advertised it with the same community.
* Since R3 rejects 1:1 routes, it will not use this path.
# Option D: R3 # R5 # R1 (Correct)
* R5 learns the route from R4, which does not have community 1:1, and advertises it to R3.
* R3 accepts this route and forwards traffic to R5, which sends it to R1.
Final Conclusion:
# D. The correct path for traffic from R3 to 192.168.1.0/24 is R3 # R5 # R1.
Thus, the correct answer is: D.
Reference:
HCIP-Datacom-Advanced Routing & Switching Technology V1.0 - BGP Route Filtering and Community Attribute Configuration Huawei Official HCIP-Datacom Study Guide - BGP Best Path Selection and Community-Based Routing Policies Huawei Documentation on BGP Community Attributes and Route Filtering
質問 # 205
Regarding multi-instance CE (Mlulti-VPN-Instance CE, MCE), which of the following descriptions is wrong?
正解：B
質問 # 206
Regarding BGP/MPLS IPVPN data forwarding, which of the following descriptions is wrong?
正解：A
質問 # 207
On a BGP/MPLS IP VPN network, PEs can use BGP-4 to advertise VPNv4 routes to each other.
正解：A
解説：
Traditional BGP-4 was designed primarily to advertise IPv4 unicast routing information between autonomous systems.
However, BGP/MPLS IP VPN networks require additional capabilities to transport VPN-specific route information, including Route Distinguishers, Route Targets, and VPN labels.
Multiprotocol BGP (MP-BGP) provides these capabilities by extending BGP through attributes such as MP_REACH_NLRI and MP_UNREACH_NLRI.
MP-BGP supports VPNv4 address families, enabling Provider Edge routers to exchange customer VPN routes while preserving routing separation between VPN instances.
The VPNv4 address family combines a 64-bit RD with a 32-bit IPv4 address, forming a 96-bit VPNv4 address.
Therefore, ordinary BGP-4 IPv4 unicast route advertisements are insufficient for exchanging VPNv4 routing information.
The statement is FALSE because VPNv4 route exchange requires MP-BGP capabilities rather than conventional BGP-4 IPv4 unicast advertisement.
質問 # 208
......
