The great advantage of our F5 F5CAB3 study prep is that we offer free updates for one year long. On one hand, these free updates can greatly spare your money since you have the right to free download BIG-IP Administration Data Plane Configuration real dumps as long as you need to. On the other hand, we offer this after-sales service to all our customers to ensure that they have plenty of opportunities to successfully pass their F5CAB3 Actual Exam and finally get their desired certification of F5CAB3 practice materials.
| Certification Vendor: | F5 Networks |
|---|---|
| Exam Name: | BIG-IP Administration Data Plane Configuration |
| Exam Number: | F5CAB3 |
| Passing Score: | 245 |
| Exam Price: | USD 50 (Online), USD 65 (Test Center) |
| Certificate Validity Period: | 3 years |
| Real Exam Qty: | 30 |
| Exam Duration: | 30 minutes |
| Available Languages: | English |
| Related Certifications: | BIG-IP Administration Control Plane Administration (F5CAB4) BIG-IP Administration Data Plane Concepts (F5CAB2) BIG-IP Administration Install, Initial Configuration, and Upgrade (F5CAB1) BIG-IP Administration Support and Troubleshooting (F5CAB5) |
| Exam Format: | Scenario-based, Multiple Choice |
| Recommended Training: | F5 Certified Administrator BIG-IP Blueprint Administering BIG-IP Training Course |
| Exam Registration: | F5 Education Certiverse Pearson VUE |
| Sample Questions: | F5 F5CAB3 Sample Questions |
| Exam Way: | Online proctored (Certiverse) / Test center proctored (Pearson VUE) |
| Pre Condition: | No formal prerequisites; recommended basic understanding of BIG-IP system and networking concepts |
| Official Syllabus URL: | https://education.f5.com/certification/big-ip-administration-data-plane-configuration-f5cab3 |
Our company is a professional certificate exam materials provider, we have occupied the field for years, therefore we have rich experiences. F5CAB3 training materials of us are compiled by skilled experts, and they are quite familiar with the exam center, and you can pass the exam just one time by using F5CAB3 Exam Materials of us. In addition, we offer you free update for 365 days after purchasing, and the update version for F5CAB3 training materials will be sent to your email automatically. We have online and offline chat service stuff, if you have any questions, just contact us.
| Topic | Details |
|---|---|
| Topic 1 |
|
| Topic 2 |
|
NEW QUESTION # 86
Refer to the exhibit.
A BIG-IP Administrator needs to configure health monitors for a newly configured server pool named Pool_B.
Which health monitor settings will ensure that all pool members will be accurately marked as available or unavailable? (Choose one answer)
Answer: D
Explanation:
From the exhibit, the pool contains different applications on different service ports (for example, HTTP/80, FTP/21, HTTPS/443, SSH/22). To mark pool members correctly, BIG-IP must be able to verify the actual service running on each member's port.
In BIG-IP Administration: Data Plane Configuration, monitor behavior is described as follows:
* When multiple monitors are assigned to a pool, the Availability Requirement controls how monitor results are evaluated:
* At least one = the pool member is marked up if any one of the assigned monitors succeeds.
* All = the pool member is marked up only if every assigned monitor succeeds.
* For pools containing members with different services/ports, using All can incorrectly mark members down because monitors intended for other services will fail on the wrong port.
Why C is correct:
* Assigning HTTPS, HTTP, FTP, and SSH covers the actual services shown in the pool.
* Setting the Availability Requirement to at least one ensures that each pool member is considered available when its appropriate service monitor succeeds, without being forced to pass unrelated service monitors.
Why the other options are incorrect:
* A / D (Availability Requirement = all): would cause members to be marked down when unrelated monitors fail (e.g., SSH monitor against an HTTP member).
* B (includes ICMP): ICMP can indicate the host is reachable even if the application service is down, which does not "accurately" reflect service availability.
Therefore, the best choice is HTTPS, HTTP, FTP, and SSH with Availability Requirement of at least one health monitor.
NEW QUESTION # 87
Refer to the exhibit.
A BIG-IP Administrator creates a new Virtual Server to load balance SSH traffic. Users are unable to log on to the servers.
What should the BIG-IP Administrator do to resolve the issue? (Choose one answer)
Answer: A
Explanation:
SSH is a Layer 4 TCP-based protocol that operates on TCP port 22 and does not use HTTP in any capacity. In the exhibit, the Virtual Server is configured with an HTTP Profile applied, which is inappropriate for SSH traffic and causes connection failures.
According to the BIG-IP Administration: Data Plane Configuration documentation:
An HTTP profile must only be applied to Virtual Servers handling HTTP or HTTPS traffic.
When an HTTP profile is attached, BIG-IP expects HTTP headers and attempts to parse application-layer data.
Non-HTTP protocols such as SSH, FTP (control), SMTP, and other raw TCP services will fail if an HTTP profile is enabled.
Why the other options are incorrect:
A). Set Protocol to UDPSSH uses TCP, not UDP. Changing the protocol would break SSH entirely.
B). Set Source Address to 10.1.1.2The source address setting controls client access restrictions and is unrelated to protocol parsing issues.
C). Set Destination Address/Mask to 0.0.0.0/0The destination address is already valid for a specific SSH service and does not impact protocol handling.
Correct Resolution:
The BIG-IP Administrator should remove the HTTP Profile (set it to None) so the Virtual Server functions as a pure Layer 4 TCP service, allowing SSH connections to pass through successfully.
NEW QUESTION # 88
A Standard Virtual Server for a web application is configured with Automap for the Source Address Translation option. The original source address of the client must be known by the backend servers. What should the BIG-IP Administrator configure to meet this requirement?
Answer: A
Explanation:
SNAT Automap is a common configuration that replaces the client's original source IP address with one of the BIG-IP's self IP addresses. This ensures that the backend servers send return traffic back through the BIG- IP, which is necessary for the ADC to process the traffic correctly. However, a side effect of SNAT is that the backend servers only see the BIG-IP's IP in their logs, losing visibility into the true identity of the client.
To resolve this while still using SNAT for routing purposes, the administrator must configure the BIG-IP to
"pass" the client's IP address at the application layer. This is achieved by using an HTTP Profile with the Insert X-Forwarded-For setting enabled. When this profile is applied to the Virtual Server, the BIG-IP intercepts the HTTP request, adds a header (X-Forwarded-For) containing the client's original IP, and then forwards the modified request to the server. The backend web server can then be configured to read this header and log the original client IP instead of the BIG-IP's SNAT address.
Other options are incorrect for this requirement. Performance (HTTP) (Option A) is a virtual server type optimized for speed but often lacks the full Layer 7 header manipulation capabilities of a Standard Virtual Server. SNAT Pool with the client IP (Option C) is technically impossible as SNAT pools use static, pre- defined IPs. There is no such thing as an HTTP Transparent profile (Option D) in standard BIG-IP administration for this purpose. The X-Forwarded-For header insertion within the HTTP profile is the standard procedural method for maintaining client visibility in SNAT-enabled environments.
NEW QUESTION # 89
A BIG-IP Administrator finds the following log entry after a report of user issues connecting to a virtual server:
01010201: Intercept exhaustion on 10.70.110.112 to 192.28.123.250:80 (proto 6) How should the BIG-IP Administrator modify the SNAT pool that is associated with the virtual server? (Choose one answer)
Answer: A
Explanation:
The log message "Intercept exhaustion" indicates that the BIG-IP system has exhausted the available source port translations for one or more SNAT addresses. This occurs when too many concurrent client connections are being translated through a limited number of SNAT IP addresses, and all ephemeral source ports (typically ~64,000 per SNAT IP) are in use.
According to the BIG-IP Administration: Data Plane Configuration documentation:
Each SNAT IP address provides a finite number of available source ports.
When the number of concurrent connections exceeds the available port space, the BIG-IP logs an Intercept exhaustion error and new connections fail.
The recommended resolution is to increase the available SNAT resources by adding additional IP addresses to the SNAT pool.
Why the other options are incorrect:
A . Increase the timeout of the SNAT addresses
Increasing timeouts may actually worsen the problem by keeping ports allocated longer, accelerating port exhaustion.
B . Remove the SNAT pool and apply SNAT Automap
SNAT Automap uses the Self IP addresses on the egress VLAN, which may not provide additional capacity and can introduce routing or design issues. This is not a direct or recommended fix for SNAT exhaustion.
C . Remove an IP address from the SNAT pool
This would reduce the number of available source ports and further exacerbate the intercept exhaustion condition.
Correct Resolution:
By adding an IP address to the SNAT pool, the BIG-IP increases the total number of available source ports, alleviating intercept exhaustion and restoring successful client connections.
NEW QUESTION # 90
An LTM device has a virtual server mapped to www.f5.com with a pool assigned. The objects are defined as follows: Virtual server: Destination 192.168.245.100:443 netmask 255.255.255.0. Persistence: Source address persistence netmask 255.0.0.0. SNAT: Automap. Profiles: HTTP/TCP. How should the BIG-IP Administrator modify the persistence profile so that each unique IP address creates a persistence record?
Answer: D
Explanation:
Source Address Affinity (Persistence) works by tracking the source IP address of incoming packets to ensure a client stays connected to the same backend server. The " netmask " setting within the persistence profile determines the " granularity " of this tracking. A netmask tells the BIG-IP how many bits of the source IP address to ignore when creating the persistence record. For example, the current setting of 255.0.0.0 (a /8 mask) means the BIG-IP only looks at the first octet of the IP; this results in all users from the same large Class A network (e.g., everyone from 10.0.0.0 to 10.255.255.255) being persisted to the exact same server, which can lead to severe load imbalance.
To ensure that each unique IP address creates its own individual persistence record, the administrator must set the netmask to 255.255.255.255 (for IPv4). This is a " host mask " or /32, which instructs the BIG-IP to evaluate all 32 bits of the client ' s source IP address. With this setting, 10.1.1.1 and 10.1.1.2 will be treated as distinct entities and can be load balanced to different servers, each maintaining their own " stickiness " .
While Option A (255.255.255.0) would group users by their local subnet, only the full 255.255.255.255 mask satisfies the requirement for true unique-IP persistence. This configuration is standard for internet-facing applications where users arrive from diverse locations and the administrator wants to maintain the most granular and balanced distribution of traffic possible.
NEW QUESTION # 91
......
