NEW QUESTION # 28
Refer to the exhibits.
You are reviewing a FortiSwitch configuration where port1 and port2 are connected to a switched network.
Loop guard is enabled on port1.
The CLI output shows that the port1 status is triggered due to loop guard. Which two conditions could have caused this shutdown? (Choose two.)
Answer: A,B
Explanation:
According to the FortiSwitchOS 7.6 Administration Guide and the FortiSwitch 7.6 Study Guide , the Loop Guard feature protects Layer 2 networks from switching loops and broadcast storms. Unlike standard STP loop protection mechanisms, FortiSwitch Loop Guard operates by periodically sending out proprietary Loop Guard Data Packets (LGDP) / probe frames out of ports where loop guard is enabled.
The loop-detection logic evaluates whether these probe frames return to the switch:
* Frame Received Back on the Same Port (Option B): If a loop guard broadcast frame transmitted out of port1 traverses an external unmanaged hub, switch, or looped cable and is received back on port1, the switch detects a downstream loop directly connected to that port.
* Frame Received on Another Port of the Same Switch (Option A): In multi-homed connections to a switched network (such as port1 and port2 sharing the same Layer 2 broadcast domains/VLANs), a loop guard frame sent from port1 that loops through the switched network and is received on port2 proves that an active Layer 2 loop exists between those two switch interfaces.
When a loop condition is verified by either scenario, FortiSwitch changes the status of the protected port to Triggered (as verified in the CLI output of the exhibit) and takes the port out of service to isolate the loop.
Regarding the incorrect options: Option C describes Spanning Tree loop guard behavior (loss of BPDUs on non-designated ports), not the FortiSwitch proprietary loop guard mechanism. Option D describes Storm Control or rate limiting, which acts on packet volume thresholds rather than loop-detection probe frames.
NEW QUESTION # 29
Refer to the exhibit.
Two routes in the routing monitor are marked as available but are not installed in the forwarding information base (FIB). Which statement correctly explains why the routes have this status? (Choose one answer)
Answer: B
Explanation:
According to theFortiSwitchOS 7.6 Administration Guideand theFortiSwitch 7.6 Study Guide, the Routing Monitor provides a comprehensive view of the Routing Information Base (RIB), which includes all routes learned via static configuration or dynamic protocols (OSPF, BGP, etc.). However, not every route present in the RIB is active for traffic forwarding. The switch must select the " best " path for any given destination to be installed into theForwarding Information Base (FIB).
The provided exhibit shows a routing table with multiple sources for the same destination. Specifically, there is aStaticdefault route ($0.0.0.0/0$) with an administrative distance of 220, and anOSPFdefault route ($0.0.0.0
/0$) with an administrative distance of 110. In FortiSwitchOS routing logic, when multiple routes to the exact same destination exist, the system compares theirAdministrative Distance (AD). The route with the lowest AD is considered the most " preferred " or " trustworthy " .
In this case, the OSPF route ($AD 110$) is more preferred than the Static route ($AD 220$). Consequently, the OSPF route is marked with a green checkmark in theFIBcolumn, while the Static route-despite being " Available " in the RIB-is excluded from the FIB. The same logic applies to the $10.0.100.0/30$ subnet, where theConnectedroute is preferred over the OSPF learned route for the same destination. Therefore, the status reflects standard route selection behavior where less-preferred routes remain in the RIB as backups but are not used for active forwarding.
NEW QUESTION # 30
Refer to the exhibits.
Port1 and port2 are the only ports configured with the same native VLAN 10.
What are two reasons that can trigger port1 to shut down? (Choose two.)
Answer: A,D
Explanation:
When loop guard is enabled on port1 and port2 configured with the same native VLAN (VLAN 10), there are specific scenarios under which port1 can be shut down due to loop guard operation:
A).port1 was shut down by loop guard protection.Loop guard is a specific feature used in network environments to prevent alternative or redundant loops. When loop guard is active, it can shut down a port if it stops receiving BPDU (Bridge Protocol Data Units) on a port that is expected to receive them, assuming a loop or link failure and putting the port into an inconsistent state to prevent potential loops.
B).STP triggered a loop and applied loop guard protection on port1.If the Spanning Tree Protocol (STP) detects a loop or loss of BPDU transmissions while loop guard is enabled, it will proactively shut down the port to prevent network instability or a broadcast storm. This is an essential function of loop guard within the context of STP, providing additional protection against topology changes that could introduce loops.
References:
Additional details about loop guard functionality and STP interaction can be found in the FortiSwitch administration guides, accessible viaFortinet Documentation.
NEW QUESTION # 31
Refer to the exhibits.
You are asked to ensure that managed FortiSwitch devices are reachable by other devices, such as SNMP and other management tools across your network.
Which setting must you configure to ensure traffic from other devices in the network reaches FortiSwitch?
Answer: C
NEW QUESTION # 32
You are deploying a new FortiSwitch device in a branch office and you want it to be automatically detected and managed by FortiGate. Which FortiSwitch feature enables automatic detection during deployment?
(Choose one answer)
Answer: D
Explanation:
According to theFortiOS 7.6 Study Guideand theFortiSwitch 7.6 FortiLink Guide, the automatic discovery and subsequent management of a FortiSwitch by a FortiGate controller is primarily facilitated by theLink Layer Discovery Protocol (LLDP). LLDP is an industry-standard, layer-2 protocol that allows network devices to advertise their identities and capabilities to neighbors on the same physical link.
When a factory-default FortiSwitch is connected to a FortiGate port (specifically one configured as a FortiLink interface), the switch automatically sends outLLDP advertisements. These advertisements include specificOrganizationally Specific TLVs (Type-Length-Values)that identify the device as a FortiSwitch and provide its management MAC address and current state. The FortiGate "listens" for these LLDP frames; once it receives a frame from a compatible FortiSwitch, it automatically lists the switch in theManaged FortiSwitchinventory as a "discovered" device awaiting authorization.
WhileZero-touch deployment (Option A)describes the overall goal of deploying a switch without manual CLI configuration, it is the underlyingLLDPprotocol that provides the technical mechanism for the initial detection. Once the switch is discovered via LLDP and authorized, the FortiGate uses a DHCP server on the FortiLink interface to assign an IP address to the switch and establishes a secureCAPWAP(Control and Provisioning of Wireless Access Points) tunnel for management. TheFortiLink heartbeat (Option D)is a secondary mechanism usedafterthe connection is established to monitor the health and status of the link, rather than for the initial detection of the device.
