| Section | Weight | Objectives |
|---|---|---|
| Topic 1: Corporate standards and documentation | 16% | - Develop BIM Execution Plan (BEP) templates
|
| Topic 2: Project needs assessment | 28% | - Analyze project requirements
|
| Topic 3: Data management | 20% | - Manage model creation according to project standards
|
| Topic 4: Collaboration process | 36% | - Coordinate and maintain geolocation
|
Experts at Exam4PDF have also prepared Autodesk BIM_MGT_101 practice exam software for your self-assessment. This is especially handy for preparation and revision. You will be provided with an examination environment and you will be presented with actual BIM_MGT_101 Exam Questions. This sort of preparation method enhances your knowledge which is crucial to excelling in the actual Autodesk BIM_MGT_101 certification exam.
NEW QUESTION # 15
Refer to the exhibits.
The firm's technical group would like to show demolished elements as dashed red in all future projects. The BIM manager is updating the Revit template to meet this new standard.
Which Phase Graphic Override will accomplish this?
Answer: D
Explanation:
Exhibit 1 correctly assigns a red dashed line pattern to the Demolished phase status for both Projection/Surface Lines and Cut Lines. This is required because demolished elements may appear either in projection or in section, depending on the view orientation and whether the element is intersected by the view's cut plane.
Configuring only Projection/Surface Lines would leave demolished elements displayed differently when cut. Conversely, changing only Cut Lines would not produce the required standard in elevations, plans, or other views where the elements are viewed in projection. The phase graphic override must therefore consistently define the colour and line pattern in both graphical conditions.
This setting belongs in the firm's Revit project template so that future projects inherit the standard. The corresponding phase filters must also be configured to apply the Demolished override in relevant demolition and construction views. A graphic override does not operate independently; the active phase and phase filter determine whether an element is classified and displayed as existing, demolished, new, or temporary.
Reference topics: Revit phasing; Phase Graphic Overrides; demolished-element standards; phase filters; projection and cut graphics; corporate project templates.
NEW QUESTION # 16
The BIM manager on a large mixed-use development is leading the development of the project's information-delivery strategy. The client has strict handover requirements for both asset data and spatial coordination. The design schedule includes overlapping packages, and some task teams are unfamiliar with structured data exchanges.
What is the most appropriate approach to establish the project's information-delivery plans?
Answer: C
Explanation:
The project requires a structured delivery plan that assigns responsibility and timing for each information exchange. The plan must define what information is required, which task team produces it, who verifies and authorizes it, the required format, the delivery milestone, and the receiving party. This is particularly important where design packages overlap and asset-data requirements must develop alongside spatial coordination rather than being added retrospectively.
A task information-delivery plan provides detailed commitments at the team level, while the consolidated information-delivery plan coordinates those commitments across the project. Together they align model production, structured data, coordination submissions, review periods, and final handover requirements.
Allowing each discipline to determine its own formats independently would produce inconsistent data structures and make late consolidation expensive and unreliable. Naming conventions are necessary but represent only one small component of information management. Postponing asset information until construction creates a high risk of missing parameters, unassigned responsibilities, incomplete records, and extensive rework.
The delivery strategy must therefore be established early and integrated with the design programme, BIM Execution Plan, client information requirements, and quality-assurance process.
Reference topics: Task Information Delivery Plans; Master Information Delivery Planning; information-exchange requirements; asset-data handover; structured data; responsibility matrices; delivery milestones.
NEW QUESTION # 17
A designer needs to add Area Lines in an Area Plan, but upon adding them, they receive a message stating that none of the created elements are visible.
Where can they check to resolve the issue?
Answer: A
Explanation:
The designer should inspect the view's Visibility/Graphics settings. Area Lines, also referred to as Area Boundary Lines, are view-specific elements whose visibility can be controlled by the active view, an applied view template, or category-level visibility settings. If the applicable line category is disabled, Revit can create the boundaries successfully while warning that the newly created elements are not visible in the current Area Plan.
The review should include the Model Categories and Annotation Categories tabs, any active view filters, temporary hide/isolate status, and the view template controlling the Area Plan. Where a template governs visibility, the correction should normally be made in the template rather than as an isolated view override, particularly when the same standard must apply to multiple Area Plans.
A Plan Region changes the local view range and does not govern Area Boundary Line visibility. Detail Level affects how certain model geometry is represented but does not normally suppress Area Lines. The Area Scheme determines the type and organizational purpose of an Area Plan, such as Gross Building or Rentable Area, but it is not the direct location for correcting hidden linework.
Reference topics: Area Plans; Area Boundary Lines; Visibility/Graphics; view templates; view-specific elements; graphical troubleshooting.
NEW QUESTION # 18
During early coordination on a hospital project, the BIM manager runs a general clash detection between all models and generates over 3,000 clash results. Many are low-priority issues, such as wall-grid overlaps and minor duct-ceiling intersections. The project's clash matrix outlines only high-impact clashes between structural, MEP, and architecture in specific zones.
For the BIM manager, what is the most appropriate next step to align clash reporting with the project's coordination strategy?
Answer: A
Explanation:
The clash matrix is the project's approved framework for determining which model combinations, object categories, zones, and tolerances require coordination. The BIM manager should configure clash tests to reflect that matrix rather than distribute an unfiltered list of every geometric intersection generated by the software.
Low-value results should be removed through controlled rule selection, object-category filtering, zone-based scoping, and technically justified tolerance settings. Reports can then be organized according to each discipline's responsibility and focused on clashes that materially affect constructability, design intent, access, maintenance clearances, or code compliance.
Sending all 3,000 results to project teams transfers the BIM manager's triage responsibility to designers and creates substantial coordination noise. Manual spreadsheet sorting separates the results from model context and is inefficient for repeated review cycles. Arbitrarily relaxing clash rules merely to reduce totals is also unacceptable; tolerances must correspond to documented project requirements rather than a desired numerical result.
Applying the clash matrix creates a repeatable, auditable process and ensures that coordination meetings address consequential issues instead of irrelevant geometric contacts.
Reference topics: Clash matrices; clash-test configuration; tolerance management; discipline-based reporting; coordination prioritization; Model Coordination.
NEW QUESTION # 19
Refer to the exhibit.
Upon opening a model, the following warnings saying "Room Tag is outside of its Room" appear.
What action should the BIM manager ask the design team to take in order to identify any Room Tags that need a leader because the tag may be too big to fit within the room?
Answer: D
Explanation:
The Show function is the appropriate diagnostic action because it locates and highlights the elements associated with the selected warning in the active graphical view. The design team can then inspect each affected Room Tag, confirm the relationship between the tag and its room boundary, and determine whether the tag should be repositioned inside the room or displayed outside the room with a leader.
The warning does not necessarily indicate invalid room data. It identifies an annotation condition in which the Room Tag's insertion point is outside the room it references. This commonly occurs where the room is narrow, irregularly shaped, crowded with documentation, or too small to contain the complete tag symbol. Each occurrence must therefore be visually assessed rather than handled through a blanket deletion or suppression process.
Export produces an external warning report for review; it does not move warnings out of the model or identify the affected annotation graphically. Close exits the dialog without investigating the condition. Delete Checked risks deleting associated model elements and is not an appropriate method for correcting annotation placement.
Using Show supports controlled warning resolution, preserves the room and tag data, and allows the team to apply a leader only where required.
Reference topics: Revit model-health review; warning management; annotation quality control; Room Tags; graphical element identification; model auditing procedures.
NEW QUESTION # 20
......
