VNX301試験に出席するための勉強は、メソッドに注意を払います。良い方法は、多くの場合、半分の労力で結果をもたらすことができます。したがって、私たちは試験の時間であり、また受験スキルを知っている必要があります。 VNX301クイズガイドは過去数年間の要約に基づいており、回答には特定のルールがあり、主観的または客観的な質問のいずれかが見つかります。共通する類似の対応モジュールで見つけることができます。このため、VNX301試験のダンプでは、VNX301試験に合格するのに役立つ資格試験のいくつかのタイプの質問をまとめています。
| トピック | 出題範囲 |
|---|---|
| トピック 1 |
|
| トピック 2 |
|
| トピック 3 |
|
| トピック 4 |
|
| トピック 5 |
|
Versa Networks VNX301資格認定はバッジのような存在で、あなたの所有する専業技術と能力を上司に直ちに知られさせます。次のジョブプロモーション、プロジェクタとチャンスを申し込むとき、Versa Networks VNX301資格認定はライバルに先立つのを助け、あなたの大業を成し遂げられます。
質問 # 37
Examine the exhibit below.
You are configuring an IPsec tunnel towards a non-SD-WAN site over the INETTransport-VR. The site IP address is 10.1.1.1. This tunnel is for traffic between the 192.168.100.0/24 and the 192.168.200.0/24 LAN networks. The tunnel does not establish.
Referring to the exhibit, which statement is correct?
正解：D
解説：
The correct answer is A . The exhibit shows that the IPsec VPN is being configured with Tunnel Routing Instance: XIAN-Control-VR . However, the question states that the tunnel is toward a non-SD-WAN site over the INET-Transport-VR . For a site-to-site IPsec tunnel, the tunnel routing instance must match the routing instance used to reach the peer public IP address. In this case, the remote non-SD-WAN peer is
10.1.1.1 , and the intended underlay transport is INET-Transport-VR , not the Control VR.
Versa troubleshooting documentation explains that routing instances are used to define where traffic is sourced and forwarded. For example, configuration examples select routing instances when enabling services or initiating tests, and traffic must use the correct WAN or transport routing instance to reach the remote endpoint. Versa branch troubleshooting also emphasizes that after transport connectivity is available, the branch establishes IKE-based IPsec connectivity; if that connectivity fails, the IPsec-related interface remains down.
Changing the routing instance to global would not be correct because the intended path is specifically INET-Transport-VR. A higher precedence value is not required to establish the tunnel. The policy selector shown already defines local-to-remote interesting traffic, and the key failure is the incorrect tunnel routing instance.
質問 # 38
Examine the exhibit below.
You are onboarding the SOLDEU-R2 branch device using the staging script. You cannot get a Versa- Provider-Controller-VR IP address assigned, indicating that the IPsec tunnel to the corrector has not come up.
You verified that the cables have been connected to the correct ports.
What has caused this issue?
正解：C
解説：
The issue is caused by specifying the incorrect WAN port in the staging script. In the exhibit, the SOLDEU- R2 branch is physically connected to the Internet cloud through vni-0/0 , while vni-0/1 is shown as the inter- device link toward SOLDEU-R1. However, the show interfaces brief output shows that the WAN IP address
192.168.122.121/24 has been assigned to vni-0/1.0 , not to the Internet-facing interface. Since the cables are confirmed to be connected correctly, the mismatch must be in the staging script interface selection, not in the cabling.
Versa documentation states that during SD-WAN staging, the branch establishes an IKE session with the Controller, and after that the Controller assigns an IP address to the branch device. Versa troubleshooting guidance also states that after transport connectivity to the Controller is established, the branch forms IKE-based IPsec connectivity, and if this succeeds, the ptvi interface toward the Controller comes up. If IKE/IPsec fails, the ptvi interface remains down. Because the staged WAN IP is placed on the wrong VNI interface, the branch cannot reach the Controller over the intended Internet transport, so the Controller tunnel does not come up.
質問 # 39
A customer reports inconsistent application performance between two branches. You find that traffic is transmitted over the Internet circuit but returns over the MPLS circuit. Which CLI output field pair is most useful to confirm this asymmetry?
正解：C
解説：
The correct answer is B . Versa documentation describes checking for asymmetrical SD-WAN paths when troubleshooting bandwidth and throughput issues. It gives the example of traffic being transmitted on one transport network and returning on another transport network that has different bandwidth. To check whether traffic is traversing an asymmetrical SD-WAN path, Versa recommends using show orgs org organization- name sessions sdwan brief.
In that output, the key fields are RX WAN CKT and TX WAN CKT . If the SD-WAN paths are symmetrical, the circuits shown in the RX and TX WAN circuit fields must be the same on the local and remote sites. If traffic goes out over Internet and returns over MPLS, throughput may differ depending on the bandwidth and quality of each circuit.
Source and destination zones are security-policy concepts, while BGP local preference and MED are routing attributes. Tenant ID and VSN ID identify context, but they do not directly prove directional WAN-circuit asymmetry.
質問 # 40
During branch onboarding, you need to verify whether the Controller has sent branch-connect and branch- disconnect notifications to Versa Director. Which CLI command should be used?
正解：C
解説：
The correct answer is A . Versa troubleshooting documentation states that after a branch device successfully establishes an IPsec connection to the Controller node, the Controller sends a notification to the Director node. To display the details of this notification, the documentation instructs administrators to issue the show alarms CLI command. It also provides examples using show alarms | match branchd | match br101 to view branch-connect and branch-disconnect events.
These alarm entries are valuable during onboarding because they show whether the branch reached the Controller, whether staging progressed, and whether the branch later disconnected. For example, branch lifecycle notifications include factory-default connection, staged connection, Stage 3 connection with WAN IP addresses, and branch disconnect events.
show system storage is useful for disk usage, show interfaces detail helps with link state, speed, duplex, and interface counters, and show cgnat acl info is used for CGNAT matching. None of those commands directly confirms branch lifecycle notifications between Controller and Director.
質問 # 41
You configured Direct Internet Access on your Versa branches using the workflow template. Which statement is true in this scenario?
正解：A
解説：
The correct answer is C . In Versa Secure SD-WAN, Direct Internet Access, or DIA, provides local internet breakout from the branch rather than backhauling internet-bound traffic through a hub. Versa design documentation explains that the DIA architecture creates an internal connection between the tenant VRF and the WAN transport VR and uses CGNAT to translate internet-bound LAN traffic to the public IP address associated with the WAN transport interface. It specifically states that the main DIA components include the CGNAT function for translating internet-bound traffic and that DIA is configured using Director Workflows when configuring tunnels.
When the workflow template is used and the DIA option is selected for the internet breakout tunnel, Director automatically builds the required DIA infrastructure, including the NAPT/CGNAT configuration associated with the internet-facing transport network. This is why manual creation of the CGNAT pool and rule is not required in the workflow-based method. Option A describes a manual configuration approach, not the workflow-generated behavior. Option B is incorrect because NAT must be associated with the internet-facing breakout path, not simply the LAN interface. Option D is incorrect because DIA normally requires address translation for LAN users accessing the public internet.
質問 # 42
......
異なる電子機器でVNX301試験問題を練習する場合。 APPバージョンのVNX301トレーニングブレインダンプは非常に便利です。さらに、VNX301トレーニング資料のオンライン版はオフライン状態でも機能します。 VNX301学習ガイドを購入すると、オフライン状態のときに試験を準備するためにVNX301学習教材を使用できます。 VNX301試験問題のオンライン版が気に入っていただけると思います。
