Nokia 4A0-D03資格認定はIT技術領域に従事する人に必要があります。我々社のNokia 4A0-D03試験練習問題はあなたに試験うま合格できるのを支援します。あなたの取得したNokia 4A0-D03資格認定は、仕事中に核心技術知識を同僚に認可されるし、あなたの技術信頼度を増強できます。
| Section | Weight | Objectives |
|---|---|---|
| Data Center Interconnect (DCI) Solutions | 25% | - Interoperability with Nokia 7750 SR - BGP route policies and route reflectors - Gateway-less EVPN DCI |
| Layer 2 EVPN Services | 25% | - Anycast Gateway and IRB - Multi-homing and Ethernet Segments - EVPN Route Types 1–4 |
| Layer 3 EVPN Services | 25% | - Symmetric and asymmetric routing - VRF integration and route targets - EVPN Route Type 5 |
| SR Linux and EVPN Fundamentals | 25% | - SR Linux architecture and CLI - EVPN control plane and MP-BGP - VXLAN encapsulation and underlay |
今後の4A0-D03学習教材について心配がある場合は、学習教材が問題の解決に役立ちます。弊社の4A0-D03学習教材の高品質をお約束するために、当社には優れた技術スタッフがおり、販売後の完璧なサービスシステムがあります。さらに重要なことは、当社の4A0-D03ガイド質問と完璧なアフターサービスが、地元および海外のお客様に認められていることです。模擬試験に合格する場合は、学習エンジンが必須の選択肢になると考えています。過去数年間、4A0-D03ガイドの質問を購入する人が増えています。
質問 # 27
Consider the exhibit.
All IP-VRFs are configured properly and are operational.
Which of the following statements is FALSE?
正解：C
解説：
Comprehensive and Detailed 150 to 250 words of Explanation From [SR Linux EVPN and Data Center Interconnect/Course Guide/topics]:
In a single-active EVPN multi-homing design, the connected PE routers perform Designated Forwarder election to determine which PE is active for the relevant service or Ethernet Segment. The DF is responsible for forwarding toward the attached segment and, in a Layer 3 multi-homing case, only the active/DF PE advertises the customer IP prefix route toward the EVPN control plane. Single-active redundancy is communicated using Ethernet Segment-related EVPN procedures, including Ethernet A-D information, so remote PEs can identify the redundancy behavior and avoid forwarding traffic to an inactive attachment. The false statement is that the elected DF uses an AD per EVI update to identify itself as primary. AD per EVI is primarily used to advertise per-service Ethernet Segment reachability and support aliasing/load-balancing behavior in multi-homed services. DF election itself is driven by Ethernet Segment route procedures, not by the DF declaring itself primary through AD per EVI. Therefore, option B misstates the role of AD per EVI in the single-active L3 multi-homing control plane. Reference: EVPN DF election, single-active multi-homing, Ethernet A-D routes.
質問 # 28
Consider the exhibit.
Which of the following statements about the proxy ARP entry for the neighbor IP 192.168.100.1 is FALSE?
正解：D
解説：
Comprehensive and Detailed 150 to 250 words of Explanation From [SR Linux EVPN and Data Center Interconnect/Course Guide/topics]:
Proxy ARP in a Layer 2 EVPN service allows the leaf to answer ARP requests locally using learned IP/MAC bindings, reducing broadcast flooding across the overlay. SR Linux can also monitor IP duplication and MAC/IP inconsistencies in the proxy ARP table. A pending state indicates that the system has detected suspicious or conflicting information and is monitoring the binding before declaring it duplicate. If the entry becomes duplicate, SR Linux can use a blackhole behavior to prevent forwarding traffic toward a conflicted endpoint, and a special discard MAC such as 00:00:00:00:DE:AD can be associated with the duplicate entry. Option D is false because it incorrectly states that all traffic destined to 192.168.100.1 will be discarded for exactly 9 minutes. The exhibit references monitoring and hold-down behavior, but the answer key rejects the fixed "9 minutes" traffic-discard statement. The key concept is that duplicate handling protects the EVPN service from unstable or conflicting IP/MAC bindings, but the specific discard duration in option D is not correct. Reference: proxy ARP, IP duplication monitoring, duplicate-state blackhole behavior.
質問 # 29
Which of the following statements describes the function or operation of the integrated gateway-based data center interconnect solution?
正解：C
解説：
Comprehensive and Detailed 150 to 250 words of Explanation From [SR Linux EVPN and Data Center Interconnect/Course Guide/topics]:
In an integrated gateway-based DCI design, the same physical or logical router performs both the data center gateway role and the WAN PE role. This is why option D is correct. The device terminates or participates in the data center-side EVPN service and also handles the WAN-side VPN transport, including route translation or re-advertisement where needed. This approach avoids exposing every data center leaf router to the WAN and avoids requiring route reflector reachability between data centers. It also avoids building VXLAN tunnels directly between all leaf routers in separate data centers. Those characteristics belong to gateway-less DCI, where the EVPN overlay stretches more directly across the WAN and the WAN must carry the underlay or overlay reachability required by the data center leaves. Integrated gateway design is more controlled: the gateway is the interworking point, which makes it suitable when the provider or operator wants a strong service boundary and centralized DCI policy enforcement. Reference: integrated gateway-based DCI, single-router gateway/WAN PE function, EVPN/VPN interworking.
質問 # 30
Consider the exhibit.
Leaf1 and Leaf2 have the Ethernet segment configured to use the default election algorithm while Leaf3 and Leaf4 are configured to use the preference-based algorithm with Leaf3 having the higher preference value. The DF candidate list is the same on all leaf routers.
Which of the following leafs is the DF for mac-vrf103?
正解：D
解説：
Comprehensive and Detailed 150 to 250 words of Explanation From [SR Linux EVPN and Data Center Interconnect/Course Guide/topics]:
Designated Forwarder election determines which PE forwards BUM traffic from the EVPN overlay toward a multi-homed Ethernet Segment for a given service. In this scenario, all leaf routers share the same DF candidate list for mac-vrf103, but the election configuration is not identical. Leaf1 and Leaf2 use the default algorithm, while Leaf3 and Leaf4 use the preference-based algorithm. Under preference-based DF election, the candidate with the highest configured preference is selected over lower-preference candidates, assuming the candidate list is valid and consistent. The question states that Leaf3 has the higher preference value compared with Leaf4. Therefore, Leaf3 becomes the DF for mac-vrf103. This is the correct outcome because the preference-based election explicitly overrides simple default behavior by assigning operator-defined priority to a PE. In production designs, this is useful when the operator wants deterministic forwarding placement, maintenance control, or service-specific primary-path selection rather than relying only on the default modulo-based DF selection process. Reference: EVPN DF election, preference-based algorithm, MAC-VRF service forwarding.
質問 # 31
Consider the exhibit.
Which of the following statements about the configuration and operation of this setup is FALSE?
正解：B
解説：
Comprehensive and Detailed 150 to 250 words of Explanation From [SR Linux EVPN and Data Center Interconnect/Course Guide/topics]:
This setup represents single-active Layer 2 EVPN multi-homing. In single-active mode, the Ethernet Segment is configured so that only one PE acts as the active forwarding node for a given service, while the other remains standby. The ports connecting to the host are associated with ES-1 so the EVPN control plane can perform Ethernet Segment discovery, DF election, and standby behavior. If Leaf1 is the active/DF node for the service, all traffic to and from the host flows through Leaf1 until a failure or DF transition occurs. Option D is false because a host LAG is not required for this single-active topology. A LAG is typically required for all-active L2 multi-homing, where the host must treat multiple physical links toward different leaf routers as one logical bundle. In single-active operation, the host can be connected through separate physical links or active/standby access behavior without requiring LACP bundling. The EVPN PEs enforce the active path selection through DF and ES state rather than relying on host-side LAG hashing. Reference: single-active EVPN multi-homing, Ethernet Segment port association, DF-controlled active forwarding.
質問 # 32
......
Nokiaの4A0-D03認定試験を受けることを決めたら、Topexamがそばにいて差し上げますよ。Topexamはあなたが自分の目標を達成することにヘルプを差し上げられます。あなたがNokiaの4A0-D03「Nokia SR Linux EVPN and Data Center Interconnect」認定試験に合格する需要を我々はよく知っていますから、あなたに高品質の問題集と科学的なテストを提供して、あなたが気楽に認定試験に受かることにヘルプを提供するのは我々の約束です。
