| Section | Objectives |
|---|---|
| Construction Fire Safety | |
| Inspection Duties & Documentation | - Inspection Reporting and Compliance Verification - Statement of Special Inspections |
| Structural & Connection Inspection | - Framing and Structural Elements - Connection Design and Protection |
| General & Construction Types | - Construction Classification — Type IV-A, IV-B, IV-C
|
| Mass Timber Materials | - CLT, Glulam, NLT, SCL and Engineered Wood Products |
| Fire-Resistance & Protection | - Fire-Resistance-Rated Assemblies - Noncombustible Protection & Encapsulation - Concealed Spaces Protection |
>> 93-Tall-Mass-Timber-Buildings Latest Test Cost <<
You must want to know your scores after finishing exercising our 93-Tall-Mass-Timber-Buildings study materials, which help you judge your revision. Now, our windows software and online test engine of the 93-Tall-Mass-Timber-Buildings study materials can meet your requirements. You can choose from two modules: virtual exam and practice exam. Then you are required to answer every question of the 93-Tall-Mass-Timber-Buildings Study Materials. In order to make sure you have answered all questions, we have answer list to help you check.
NEW QUESTION # 68
Refer to the exhibit by clicking on the EXHIBIT button above.
In the detail shown and according to AWC Technical Report 10, what is the time assigned in minutes to 5/8 in. Type X gypsum board for connection fire protection thermal separation requirements?
Answer: B
Explanation:
For the illustrated two-layer protection system, the 5/8-inch Type X gypsum-board layer directly adjacent to the connection is assigned 20 minutes, while the second layer is assigned 40 minutes. Therefore, option C is correct.
The standard assigned protection time for one layer of 5/8-inch Type X gypsum board is 40 minutes.
However, the thermal-separation methodology applies a 0.50 reduction factor to the final or base Type X layer located directly against the protected connection. That layer therefore contributes 20 minutes. The outer layer retains its full 40-minute assigned value, producing a combined assigned protection time of 60 minutes for the two-layer configuration.
The layers are not interchangeable for calculation purposes because the reduced contribution applies specifically to the layer adjacent to the protected connection. Options A and B incorrectly assign the same value to both layers, while option D reverses the required allocation.
During inspection, the special inspector should verify layer sequencing, board thickness and type, fastening, joint staggering, edge support, protection at corners, and continuity around the connection. Missing or incorrectly sequenced layers can invalidate the calculated thermal-separation time.
References/Topics: AWC Technical Report 10; AWC 2021 Fire Design Specification Section 3.5.2.1; assigned protection time for Type X gypsum board.
NEW QUESTION # 69
Which of the following is an acceptable alternative for protecting structural connections from fire in Type IV- A, IV-B or IV-C construction?
Answer: C
Explanation:
Option D directly reflects the engineering-analysis method authorized by 2021 IBC Section 2304.10.1. For structural connections in Type IV-A, IV-B, or IV-C construction, the analysis must demonstrate that temperatures at every relevant portion of the connection remain within prescribed limits for a period corresponding to the fire-resistance rating required of the connected structural element.
The code establishes two critical temperature-rise limits: an average rise of not more than 250°F and a maximum rise of not more than 325°F . For this purpose, the "connection" includes the connectors, fasteners, and those portions of the wood members that participate structurally in the connection.
Option A is incorrect because ASTM E136 is a test for determining whether a material is noncombustible; it is not the fire-resistance test method for a structural connection. Option B is not a code-recognized substitute for the required connection fire evaluation. Option C is insufficient because a manufacturer's generalized fire- performance representation does not establish the required code fire-resistance duration unless supported through an approved test, evaluation, or engineering analysis.
References/Topics: 2021 IBC Section 2304.10.1; engineering-analysis method for Type IV-A, IV-B, and IV- C structural connections.
NEW QUESTION # 70
Which of the following products is not included in the definition of mass timber?
Answer: D
Explanation:
Prefabricated wood I-joists are engineered wood framing products, but they are not mass timber elements because their configuration does not meet the minimum solid cross-sectional dimensions required for Type IV mass timber construction. Option B is therefore correct.
An I-joist consists of relatively thin flanges connected by a thin structural web. Its efficient open- web-like cross section is fundamentally different from a large solid, laminated, built-up or panelized timber element. I- joists are separately regulated by IBC Section 2303.1.2 and are manufactured and evaluated in accordance with ASTM D5055.
Solid-sawn lumber can qualify as mass timber when it satisfies the minimum heavy-timber dimensions.
Structural glued-laminated timber is a recognized large-section engineered timber product, while cross- laminated timber is explicitly recognized as a panelized mass timber product and is regulated by ANSI/APA PRG 320.
The critical inspection point is that the term "engineered wood" does not automatically mean "mass timber." The special inspector must verify the product category, minimum dimensions, approved construction type, applicable product standard, identification marks and installation requirements shown in the approved construction documents.
References/Topics: 2021 IBC Chapter 2 definition of "Mass Timber"; Sections 2303.1.2, 2303.1.3, 2303.1.4 and 2304.11; ASTM D5055.
NEW QUESTION # 71
The maximum allowable height for a Group I-4 building of Type IV-B construction provided with an automatic sprinkler system in accordance with Section 903.3.1.1 is _____ ft.
Answer: B
Explanation:
The applicable requirement is found in 2021 IBC Section 504.3 and Table 504.3. The table regulates building height in feet above grade plane by occupancy, construction type, and sprinkler condition. For a Group I-4 occupancy equipped throughout with a Section 903.3.1.1 sprinkler system, the applicable row is the sprinklered "S" row.
Reading across that row to Type IV-B construction gives a maximum building height of 120 feet. Therefore, option B is correct. The 180-foot value applies to Type IV-A construction for the same occupancy and sprinkler condition. The 85-foot value, which is not offered, applies to Type IV-C and Type IV-HT. The 270- foot value generally appears for certain lower-hazard occupancies-such as Groups A, B, E, F, M, S and U- when constructed as sprinklered Type IV-A, but it is not permitted for Group I-4.
This distinction reflects the additional life-safety considerations associated with custodial-care occupancies. A special inspector should verify that the approved construction documents identify both the correct occupancy classification and construction type because either classification directly changes the permitted height.
References/Topics: 2021 IBC Section 504.3; Table 504.3, Group I-4, sprinklered Type IV-B construction; Section 903.3.1.1.
NEW QUESTION # 72
According to UL Fire Resistance Directory, a "finish rating" is the time:
Answer: B
Explanation:
Option C correctly states the fundamental UL finish-rating criterion. UL defines a finish rating for assemblies containing combustible wood structural supports as the elapsed fire-exposure time at which the wood member immediately behind the protective membrane reaches the prescribed temperature-rise threshold.
More precisely, UL uses two criteria: an average temperature rise of 250°F or an individual-point temperature rise of 325°F , measured on the plane of the wood nearest the fire, typically between the gypsum membrane and the wood stud or joist. The question asks for the principal definition, which is the 250° F temperature-rise criterion; therefore, option C is correct. Option D incorrectly treats the 325°F individual- point limit as the sole definition.
Options A and B confuse a finish rating with "assigned protection time." IBC Tables 722.6 and 722.7 provide calculated contribution values for specified protective materials, but those assigned values are not themselves UL finish ratings.
This distinction matters in mass timber fire design because membrane contribution, thermal separation, structural fire resistance, and finish rating are related but not interchangeable concepts.
References/Topics: UL Fire Resistance Directory terminology; finish rating; average 250°F and individual
325°F temperature-rise criteria.
NEW QUESTION # 73
......
