| Section | Objectives |
|---|---|
| Topic 1: Construction Fire Safety | - Construction-phase fire safety requirements - International Fire Code requirements - Protection of mass timber during construction |
| Topic 2: Tall Mass Timber Building Code Provisions | - Mass timber materials and construction requirements - Types IV-A, IV-B and IV-C construction - International Building Code requirements for tall mass timber construction |
| Topic 3: Structural Inspection | - Connections and fastening systems - Structural loads and related code requirements - Mass timber structural elements |
| Topic 4: Code Compliance and Related Requirements | - Documentation and verification of compliance - Energy code requirements applicable to mass timber buildings - Sound transmission requirements |
| Topic 5: Special Inspection Requirements | - Inspector duties and responsibilities - Special inspection procedures for tall mass timber buildings - Inspection of connections and protective materials |
| Topic 6: Fire Protection and Fire-Resistance | - Fire protection systems and related provisions - Noncombustible protection and protection of mass timber elements - Fire-resistance requirements |
>> 93-Tall-Mass-Timber-Buildings Test Question <<
The latest 93-Tall-Mass-Timber-Buildings dumps collection covers everything you need to overcome the difficulty of real questions and certification exam. Accurate 93-Tall-Mass-Timber-Buildings test answers are tested and verified by our professional experts with the high technical knowledge and rich experience. You may get answers from other vendors, but our 93-Tall-Mass-Timber-Buildings briandumps pdf are the most reliable training materials for your exam preparation.
NEW QUESTION # 53
Given: A building of Type IV-B construction is designed to be greater than six stories above grade plane.
At least one layer of required noncombustible protection shall be installed on all of the following building elements except _____ on all floor levels more than four levels below active mass timber construction before erecting additional floor levels during construction.
Answer: C
Explanation:
The intended code exception is shafts and vertical exit enclosures , making option B correct. The governing construction-phase provision is 2021 IFC Section 3303.5, which applies to buildings of Types IV-A, IV-B, and IV-C designed to exceed six stories above grade plane.
Where Section 602.4 of the IBC requires noncombustible protection, at least one layer must be installed on building elements located on floor levels-including mezzanines-more than four levels below active mass timber construction before additional floor levels can be erected. The provision is intended to prevent a tall mass timber project from accumulating an excessive number of substantially unprotected combustible stories during erection.
Section 3303.5 expressly states that shafts and vertical exit enclosures are not considered part of the active mass timber construction for application of this construction-progress requirement. Therefore, B is the examination answer.
Mezzanines are expressly included in the protected-level requirement. Required protection for floors, walls, and ceilings under IBC Section 602.4 progresses with construction subject to the IFC provision. The same section also requires standpipes, an approved water supply for fire department operations, and timely installation of required exterior wall coverings.
References/Topics: 2021 IFC Section 3303.5; 2021 IBC Section 602.4; fire safety during construction of tall mass timber buildings.
NEW QUESTION # 54
In Type IV-C construction, a connection between two members of the primary structural frame supporting a floor is required to be protected to achieve a minimum fire-resistance rating of:
Answer: C
Explanation:
The required minimum fire-resistance rating is two hours , making option C correct. Table 601 assigns a two- hour fire-resistance rating to the primary structural frame in Type IV-C construction. The structural connection between members of that rated frame cannot become a premature failure point in the load path.
IBC Section 2304.10.1 specifically addresses structural connections in Types IV-A, IV-B, and IV-C mass timber construction. Connection protection must provide the fire-resistance performance required for the connected building element. This can be accomplished through protected connection configurations, approved fire testing, or engineering analysis satisfying the applicable code criteria.
The connection includes more than the visible steel plate or bolt. Fasteners, connectors, concealed steel, bearing zones, and portions of the timber participating structurally in the connection must collectively maintain the required performance. A one-hour or 1½-hour connection would undermine a structural frame required to remain functional for two hours. Three hours is the primary-frame rating associated with Type IV- A, not the Type IV-C condition specified here.
The inspector should verify protection thickness, wood cover, gypsum layers, hardware embedment, edge conditions, and approved connection geometry before concealment.
References/Topics: 2021 IBC Table 601; Section 2304.10.1; fire-resistant structural connections in Types IV- A, IV-B, and IV-C.
NEW QUESTION # 55
Refer to the exhibit by clicking on the EXHIBIT button above.
In the detail shown and according to AWC Technical Report 10, what is the time assigned in minutes to 5/8 in. Type X gypsum board for connection fire protection thermal separation requirements?
Answer: D
Explanation:
For the illustrated two-layer protection system, the 5/8-inch Type X gypsum-board layer directly adjacent to the connection is assigned 20 minutes, while the second layer is assigned 40 minutes. Therefore, option C is correct.
The standard assigned protection time for one layer of 5/8-inch Type X gypsum board is 40 minutes.
However, the thermal-separation methodology applies a 0.50 reduction factor to the final or base Type X layer located directly against the protected connection. That layer therefore contributes 20 minutes. The outer layer retains its full 40-minute assigned value, producing a combined assigned protection time of 60 minutes for the two-layer configuration.
The layers are not interchangeable for calculation purposes because the reduced contribution applies specifically to the layer adjacent to the protected connection. Options A and B incorrectly assign the same value to both layers, while option D reverses the required allocation.
During inspection, the special inspector should verify layer sequencing, board thickness and type, fastening, joint staggering, edge support, protection at corners, and continuity around the connection. Missing or incorrectly sequenced layers can invalidate the calculated thermal-separation time.
References/Topics: AWC Technical Report 10; AWC 2021 Fire Design Specification Section 3.5.2.1; assigned protection time for Type X gypsum board.
NEW QUESTION # 56
Materials acceptable for use in fire-protecting connections in Type IV-A construction includes each of the following except:
Answer: B
Explanation:
Steel plates are not themselves a fire-protective material for the connection; therefore, option A is the exception. Steel plates frequently form part of mass timber structural connections, but because steel is highly thermally conductive, exposed steel can rapidly transmit heat into fasteners and adjacent wood. Consequently, the steel connection components are normally the items that require protection , not the material relied upon to provide that protection.
AWC guidance recognizes wood cover, fire-rated gypsum board, and other approved protection materials as valid means of shielding structural connections. TR10 specifically provides calculation procedures and worked examples using sacrificial wood cover and Type X gypsum wallboard. An approved protective coating can also be used where its documented fire-performance characteristics establish the required endurance under the approved design.
The distinction is important for inspection. A concealed steel plate does not automatically mean a protected connection. The special inspector must verify whether sufficient wood cover, gypsum protection, approved coating, or another engineered protection system surrounds the steel for the required duration. Hardware geometry, exposed edges, gaps, and penetrations can all materially affect thermal performance.
References/Topics: AWC Technical Report No. 10, protection of structural connections; 2021 IBC Section
2304.10.1; AWC guidance that connection protection can be provided by wood cover, gypsum board, or other approved material.
NEW QUESTION # 57
Regarding water supply for the protection of buildings under construction, when combustible building materials of the building under construction are delivered to a site, the minimum fire flow provided shall be
_____ gpm.
Answer: C
Explanation:
The minimum required fire flow is 500 gallons per minute. Therefore, option C is correct.
Under 2021 IFC Section 3313.2, an approved water supply must be available when combustible building materials for the building under construction are delivered to the project site. The hydrant supplying the required flow must be located within the prescribed distance of the combustible materials as measured along an approved fire apparatus access route. Where one hydrant cannot provide coverage to all combustible material locations, additional hydrants are required.
The 500-gpm requirement is the initial minimum associated with the delivery of combustible building materials. It should not be confused with the potentially greater fire-flow requirements applicable after vertical construction of a Type III, IV, or V building begins. Depending on fire separation distance and the building's calculated final fire-flow demand, a larger supply may be required under subsequent provisions.
Options A and B provide inadequate suppression capacity. Option D is not the baseline amount prescribed for the condition stated in the question. Inspectors and site safety personnel should verify that the water source is operational and accessible before substantial quantities of mass timber arrive on-site.
References/Topics: 2021 IFC Sections 3313.1 and 3313.2; construction-site water supply and combustible building materials.
