NEW QUESTION # 37
A Standard Virtual Server is configured with SNAT Automap. Backend servers must see the original client IP.
What should be configured?
Answer: D
Explanation:
X-Forwarded-For inserts the original client IP into HTTP headers, preserving client identity while SNAT is enabled.
NEW QUESTION # 38
Refer to the exhibit.
A BIG-IP Administrator creates a new Virtual Server to load balance SSH traffic. Users are unable to log on to the servers.
What should the BIG-IP Administrator do to resolve the issue? (Choose one answer)
Answer: B
Explanation:
SSH is a Layer 4 TCP-based protocol that operates on TCP port 22 and does not use HTTP in any capacity. In the exhibit, the Virtual Server is configured with an HTTP Profile applied, which is inappropriate for SSH traffic and causes connection failures.
According to the BIG-IP Administration: Data Plane Configuration documentation:
An HTTP profile must only be applied to Virtual Servers handling HTTP or HTTPS traffic.
When an HTTP profile is attached, BIG-IP expects HTTP headers and attempts to parse application-layer data.
Non-HTTP protocols such as SSH, FTP (control), SMTP, and other raw TCP services will fail if an HTTP profile is enabled.
Why the other options are incorrect:
A). Set Protocol to UDPSSH uses TCP, not UDP. Changing the protocol would break SSH entirely.
B). Set Source Address to 10.1.1.2The source address setting controls client access restrictions and is unrelated to protocol parsing issues.
C). Set Destination Address/Mask to 0.0.0.0/0The destination address is already valid for a specific SSH service and does not impact protocol handling.
Correct Resolution:
The BIG-IP Administrator should remove the HTTP Profile (set it to None) so the Virtual Server functions as a pure Layer 4 TCP service, allowing SSH connections to pass through successfully.
NEW QUESTION # 39
How will the BIG-IP system distribute the traffic based on the configuration below?
pool my_pool {
lb_mode fastest
min_active_members 2
member 10.12.10.7:80 priority 3
member 10.12.10.8:80 priority 3
member 10.12.10.9:80 priority 3
member 10.12.10.4:80 priority 2
member 10.12.10.5:80 priority 2
member 10.12.10.6:80 priority 2
member 10.12.10.1:80 priority 1
member 10.12.10.2:80 priority 1
member 10.12.10.3:80 priority 1
}
(Pick the 2 correct responses below)
Answer: A,B
Explanation:
The configuration provided utilizes Priority Group Activation in conjunction with the min_active_members setting. Priority groups allow an administrator to define primary servers and "backup" servers within the same pool. The BIG-IP prioritizes traffic based on the assigned priority number, with the highest number receiving traffic first.
In this specific configuration, the priority 3 group is the primary group. Therefore, connections are first distributed to all pool members with priority 3 as long as they are available. The system will continue to use only the priority 3 group unless the number of available members in that group falls below the min_active_members value, which is set to 2.
If the priority 3 group has fewer than two active members, the BIG-IP "activates" the next available priority group (priority 2) and distributes traffic among the remaining members of priority 3 and all members of priority 2. This cascading logic continues down the list. Consequently, if both the priority 3 group and the priority 2 group have fewer than two members available, traffic is directed to the priority 1 group. This ensures that even in a multi-server failure scenario, the system has a last-resort group of servers to handle the traffic.
Option D is incorrect because if only one member of priority 3 goes down, there are still two members active (10.12.10.8 and 10.12.10.9). Since 2 is not less than the min_active_members threshold of 2, the priority 2 group will not yet be activated. Option B is incorrect because traffic flows from high priority to low priority, not the other way around.
NEW QUESTION # 40
Some users who connect to a busy Virtual Server have connections reset by the BIG-IP system. Pool member resources are NOT a factor.
What is a possible cause?
Answer: B
Explanation:
When the connection limit is reached, BIG-IP resets new connections, even if pool members are healthy.
NEW QUESTION # 41
A BIG-IP Administrator is creating a new Trunk on the BIG-IP device. What objects should be added to the new Trunk being created?
Answer: A
Explanation:
In F5 BIG-IP architecture, a Trunk is a logical aggregation of physical interfaces designed to increase bandwidth and provide link redundancy through 802.3ad Link Aggregation Control Protocol (LACP).
When creating a Trunk object within the BIG-IP configuration, the administrator must assign physical Interfaces to it - these are the underlying hardware ports (e.g., 1.1, 1.2, 1.3) that will be bundled together to form the aggregated logical link.
It is critical to understand the layered object hierarchy on the BIG-IP platform:
* Interfaces # assigned to Trunks
* Trunks (or individual Interfaces) # assigned to VLANs (as tagged or untagged members)
* VLANs # assigned Self IP addresses
* Self IPs / Routes # configured at the network layer above
VLANs are not added to a Trunk; rather, a Trunk is added as a member of a VLAN. IP addresses and network routes are configured independently at a higher abstraction layer and have no direct association with Trunk creation.
This layered design ensures proper separation of concerns across the data plane. Misunderstanding this hierarchy is a common configuration error that can result in traffic forwarding failures.
Reference: BIG-IP Administration - Data Plane Configuration, Module: Network Objects - Interfaces, Trunks, and VLANs.
