In order to help customers solve the problem, our BIG-IP Administration Data Plane Configuration test torrent support the printing of page. We will provide you with three different versions, the PDF version allow you to switch our F5CAB3 study torrent on paper. You just need to download the PDF version of our F5CAB3 Exam Prep, and then you will have the right to switch study materials on paper. We believe it will be more convenient for you to make notes. Our website is very secure and regular platform, you can be assured to download the version of our F5CAB3 study torrent.
| Certification Vendor: | F5 Networks |
|---|---|
| Exam Name: | BIG-IP Administration Data Plane Configuration |
| Exam Number: | F5CAB3 |
| Available Languages: | English |
| Exam Format: | Scenario-based, Multiple Choice |
| Exam Price: | USD 50 (Online), USD 65 (Test Center) |
| Related Certifications: | BIG-IP Administration Control Plane Administration (F5CAB4) BIG-IP Administration Install, Initial Configuration, and Upgrade (F5CAB1) BIG-IP Administration Data Plane Concepts (F5CAB2) BIG-IP Administration Support and Troubleshooting (F5CAB5) |
| Passing Score: | 245 |
| Exam Duration: | 30 minutes |
| Real Exam Qty: | 30 |
| Certificate Validity Period: | 3 years |
| Recommended Training: | Administering BIG-IP Training Course F5 Certified Administrator BIG-IP Blueprint |
| Exam Registration: | F5 Education Certiverse Pearson VUE |
| Sample Questions: | F5 F5CAB3 Sample Questions |
| Exam Way: | Online proctored (Certiverse) / Test center proctored (Pearson VUE) |
| Pre Condition: | No formal prerequisites; recommended basic understanding of BIG-IP system and networking concepts |
| Official Syllabus URL: | https://education.f5.com/certification/big-ip-administration-data-plane-configuration-f5cab3 |
>> Valid F5CAB3 Study Notes <<
Whereas the F5CAB3 PDF file is concerned this file is the collection of real, valid, and updated F5 F5CAB3 exam questions. You can use the F5 F5CAB3 PDF format on your desktop computer, laptop, tabs, or even on your smartphone and start BIG-IP Administration Data Plane Configuration (F5CAB3) exam questions preparation anytime and anywhere.
| Topic | Details |
|---|---|
| Topic 1 |
|
| Topic 2 |
|
NEW QUESTION # 17
A virtual server is configured to offload SSL from a pool of backend servers. When users connect to the virtual server, they successfully establish an SSL connection but no content is displayed. A packet trace performed on the server shows that the server receives and responds to the request. What should a BIG-IP Administrator do to resolve the problem?
Answer: B
Explanation:
This scenario describes a classic routing issue often encountered during SSL offload deployments. The fact that an SSL connection is established indicates the Client SSL profile is working correctly. The packet trace showing the server "receives and responds" to the request is the most critical diagnostic clue.
When a BIG-IP receives traffic, it typically passes the client's original source IP address to the backend server. If the backend server's default gateway is not the BIG-IP (a common "one-arm" network topology), the server will attempt to send its response directly back to the client's IP via its own default router. The client's browser will reject this response because it expects traffic to come from the Virtual Server's IP, not the backend server's IP.
To resolve this, the administrator must enable SNAT (Source Address Translation), typically using SNAT Automap. When SNAT is enabled, the BIG-IP replaces the client's original source IP with one of its own Self IPs before forwarding the request to the server. Because the source of the packet is now the BIG-IP, the backend server is forced to send its response back to the BIG-IP. The BIG-IP then receives the response, translates it back, and delivers the content to the user. Option A is unnecessary if the servers are expecting plain-text traffic after the BIG-IP performs offload. Option D would only worsen the existing routing discrepancy.
NEW QUESTION # 18
Refer to the exhibit.
A BIG-IP Administrator creates a new Virtual Server to load balance SSH traffic. Users are unable to log on to the servers.
What should the BIG-IP Administrator do to resolve the issue? (Choose one answer)
Answer: D
Explanation:
SSH is a Layer 4 TCP-based protocol that operates on TCP port 22 and does not use HTTP in any capacity. In the exhibit, the Virtual Server is configured with an HTTP Profile applied, which is inappropriate for SSH traffic and causes connection failures.
According to the BIG-IP Administration: Data Plane Configuration documentation:
An HTTP profile must only be applied to Virtual Servers handling HTTP or HTTPS traffic.
When an HTTP profile is attached, BIG-IP expects HTTP headers and attempts to parse application-layer data.
Non-HTTP protocols such as SSH, FTP (control), SMTP, and other raw TCP services will fail if an HTTP profile is enabled.
Why the other options are incorrect:
A). Set Protocol to UDPSSH uses TCP, not UDP. Changing the protocol would break SSH entirely.
B). Set Source Address to 10.1.1.2The source address setting controls client access restrictions and is unrelated to protocol parsing issues.
C). Set Destination Address/Mask to 0.0.0.0/0The destination address is already valid for a specific SSH service and does not impact protocol handling.
Correct Resolution:
The BIG-IP Administrator should remove the HTTP Profile (set it to None) so the Virtual Server functions as a pure Layer 4 TCP service, allowing SSH connections to pass through successfully.
NEW QUESTION # 19
All pool members are online. All other virtual server settings are at default.
What might alter the load balancing behavior? (Choose one answer)
Answer: A
Explanation:
By default, BIG-IP load balancing algorithms (such as Round Robin) distribute connections evenly across all available pool members. However, persistence profiles override normal load balancing decisions by forcing subsequent connections from a client to be sent to the same pool member.
According to the BIG-IP Administration: Data Plane Configuration documentation:
Persistence creates a client-to-server mapping that is honored before load balancing algorithms are applied.
When persistence is enabled, BIG-IP may repeatedly select the same pool member even if others are available.
This directly alters load balancing behavior.
Why the other options are incorrect:
A . Adding a OneConnect profile
OneConnect optimizes server-side TCP connections but does not change which pool member is selected.
B . Enabling SNAT automap
SNAT affects source address translation, not pool member selection.
C . Enabling a fallback host in the HTTP profile
A fallback host is only used when no pool members are available.
Correct Resolution:
Adding a persistence profile alters load balancing behavior by maintaining client affinity to a specific pool member.
NEW QUESTION # 20
A BIG-IP Administrator configures a node with a standard icmp Health Monitor. The Node shows as DOWN although the Backend Server is configured to answer ICMP requests. Which step should the administrator take next to find the root cause of this issue?
Answer: A
Explanation:
In the F5 BIG-IP ecosystem, a standard ICMP health monitor functions by sending an ICMP echo request to a target node and expecting an ICMP echo reply within a specified timeout period. When a node is marked
"DOWN" despite the backend server being configured to respond to ICMP, the issue typically lies in the network path or the specific packet exchange between the BIG-IP's self IP and the node's IP. Running a tcpdump is the most effective next step because it provides a real-time packet capture of the actual monitor traffic leaving the BIG-IP and any return traffic coming back from the server. This allows the administrator to verify if the BIG-IP is actually sending the echo request, if the request is reaching the server, and if the server is indeed replying or if the reply is being dropped by an intermediate firewall or a security policy.
While other tools have their place, they are inappropriate for this specific layer 3/4 connectivity issue. A qkview is a comprehensive diagnostic file used primarily for F5 Support to analyze the entire system's state but is overkill for initial connectivity troubleshooting. An ssldump is used for inspecting SSL/TLS handshakes and encrypted payloads, which is irrelevant for a non-encrypted ICMP monitor. A curl command is a tool for testing HTTP/HTTPS application-level responses; it cannot be used to troubleshoot ICMP (ping) connectivity directly. By using tcpdump -ni <vlan_name> host <node_ip>, the administrator can see the ICMP "type 8" (request) and "type 0" (reply) packets, immediately identifying if the monitor failure is due to a "Destination Unreachable" message or a simple lack of response, thereby pinpointing the root cause in the data plane.
NEW QUESTION # 21
All pool members are online and all other settings are default.
What might alter the load balancing behavior?
Answer: C
Explanation:
Persistence overrides load balancing decisions by maintaining client-to-server affinity.
NEW QUESTION # 22
......
