why you need the H12-811_V2.0 exam questions to help you pass the exam more smoothly and easily? There are a lot of the benefits of the H12-811_V2.0 study guide. Firstly, a little practice can perfect you to answer all H12-811_V2.0 new questions in the real exam scenario. Secondly, another amazing benefit of doing the H12-811_V2.0 Practice Tests is that you can easily come to know the real exam format and develop your skills to answer all questions without any confusion. Hence, you can develop your pass percentage.
| Certification Vendor: | Huawei |
|---|---|
| Exam Name: | HCIA-Datacom V2.0 |
| Exam Number: | H12-811_V2.0-ENU |
| Certificate Validity Period: | 3 years |
| Exam Format: | Drag-and-drop, Simulation, Multiple-response, Multiple-choice |
| Related Certifications: | HCIA-Datacom |
| Passing Score: | 600/1000 |
| Exam Duration: | 90 minutes |
| Exam Price: | $200 USD |
| Real Exam Qty: | 60 |
| Available Languages: | English, Chinese |
| Sample Questions: | Huawei H12-811_V2.0 Sample Questions |
| Exam Way: | Available at Pearson VUE test centers (offline) or online proctored exam. |
| Pre Condition: | No prerequisites required; candidates can register directly. |
| Official Syllabus URL: | https://e.huawei.com/en/talent/cert/#/cert/Details/68381b0d8e534a6a9339761047279030 |
>> H12-811_V2.0 Reliable Exam Sims <<
Discount is being provided to the customer for the entire Huawei H12-811_V2.0 preparation suite. These H12-811_V2.0 learning materials include the H12-811_V2.0 preparation software & PDF files containing sample Interconnecting Huawei H12-811_V2.0 and answers along with the free 90 days updates and support services. We are facilitating the customers for the Huawei H12-811_V2.0 preparation with the advanced preparatory tools.
| Topic | Details |
|---|---|
| Topic 1 |
|
| Topic 2 |
|
| Topic 3 |
|
| Topic 4 |
|
NEW QUESTION # 72
The figure shows the simplified topology of an enterprise campus network. On this network, the aging time of dynamic MAC address entries on switches is 300 seconds. Employee A uses PC1 to connect to the GE1/0/1 port of the switch and continuously communicates with PC3 for 10 minutes. After that, the employee disconnects the network cable and leaves the workstation. Subsequently, PC4 continues to communicate with PC3. After 30 minutes, employee B connects PC2 to GE1/0/1 of SW1, and PC2 ' s ARP cache table is empty.
At this point, when SW1 receives an ARP request from PC2, it will search the MAC address table and forward the request packet only through GE1/0/3.
Answer: B
Explanation:
An ARP Request is carried in an Ethernet broadcast frame whose destination MAC address is FF-FF-FF-FF- FF-FF. When SW1 receives the ARP Request from PC2, it does not look up a single destination MAC entry and send the frame only toward PC3. Instead, the switch floods the broadcast frame through all other eligible ports in the same VLAN, excluding the ingress port. The 300-second MAC aging time reinforces why the earlier PC1 entry is not relevant after 30 minutes: a dynamic entry that is not refreshed will age out long before PC2 is connected. PC4 ' s continued communication with PC3 may refresh MAC entries associated with that traffic, but it does not transform PC2 ' s ARP Request into a known unicast frame. ARP relies on broadcast precisely because the sender does not yet know the target ' s Layer 2 address. Therefore, the claim that SW1 forwards the request only through GE1/0/3 is incorrect. The verified answer is FALSE, option B.
NEW QUESTION # 73
The traditional Fat AP networking usually applies to WLANs of small and micro stores. For a large-scale WLAN, the WAC + Fit AP networking is typically used. Which of the following statements are true about the WAC + Fit AP networking architecture? (Select all that apply)
Answer: A,C
Explanation:
In a WAC + Fit AP architecture, the WAC (Wireless Access Controller) centrally manages and controls the Fit APs, so option A is correct. Service configurations such as SSIDs, security policies, radio parameters, and access control are generally delivered from the WAC to the APs. The Fit AP mainly forwards wireless user traffic and executes the configuration issued by the controller.
Option D is also correct because a Fit AP provides 802.11 wireless access for stations (STAs) and serves as a bridge between the wireless side and the wired network. This is one of its basic roles in enterprise WLAN deployment. Option B is incorrect because users or administrators do not normally need to log in to each Fit AP individually to configure wireless services; centralized management by the WAC is the whole advantage of this architecture. Option C is incorrect because CAPWAP communication between the WAC and AP does not require Layer 2 adjacency ; the WAC and AP can communicate over Layer 3 as long as IP connectivity exists. HCIA-Datacom emphasizes centralized configuration, simplified operations, and scalable deployment as key benefits of WAC + Fit AP networking.
NEW QUESTION # 74
Which of the following is not a type of OSPF packets?
Answer: B
Explanation:
OSPF defines five protocol packet types: Hello, Database Description (DD), Link State Request (LSR), Link State Update (LSU), and Link State Acknowledgment (LSAck). A Link State Advertisement, or LSA, is not itself an OSPF packet type. LSAs are data structures that describe topology or routing information and are carried inside OSPF packets, especially LSU packets. For example, an LSU packet may transport one or more LSAs to a neighbor, and an LSAck packet acknowledges receipt of LSAs. Hello packets discover and maintain neighbor relationships, DD packets summarize LSDB contents during synchronization, and LSR packets request specific missing LSAs. The distinction between an LSA and an LSU is important in Huawei Datacom study material because they operate at different conceptual levels: an LSA is routing information, whereas an LSU is the OSPF protocol packet that transports that information. Therefore, among the choices, LSA is the item that is not one of the five OSPF packet types. The correct answer is B.
NEW QUESTION # 75
What is the broadcast address of the network that contains a host with IP address 192.168.1.147/28?
Answer: B
Explanation:
A /28 subnet mask corresponds to 255.255.255.240, which means each subnet contains 16 IP addresses . The subnet boundaries in the last octet increase in steps of 16: 0, 16, 32, 48, 64, 80, 96, 112, 128, 144, 160, and so on. The host address 192.168.1.147 falls within the subnet range 192.168.1.144 to 192.168.1.159 .
In that subnet, the network address is 192.168.1.144, the usable host range is 192.168.1.145 through
192.168.1.158, and the broadcast address is 192.168.1.159. Therefore, option C is correct. Option D is the first usable host address, not the broadcast address. Option A is just another usable host address. Option B would be the broadcast address only for a /24 network, not for a /28. HCIA-Datacom requires learners to master subnetting because it is essential for IP planning, gateway deployment, route summarization, and troubleshooting Layer 3 communication issues in campus and enterprise networks.
NEW QUESTION # 76
The undo command can be used in the CLI of a Huawei device to restore default settings, disable functions, or delete configurations. Which of the following are correct undo commands? (Select all that apply)
Answer: A,B,C
Explanation:
On Huawei devices, the undo command is used to remove a previously applied configuration, disable a function, or restore a parameter to its default state. In option B, undo ip address is a valid interface-view command that removes the IP address configured on the interface. In option C, undo portswitch is also a valid interface command on switch interfaces that converts a Layer 2 interface into a Layer 3 interface when supported by the device. In option D, undo sysname restores the device name to the default hostname, which is valid in system view.
NEW QUESTION # 77
......
