As to this fateful exam that can help you or break you in some circumstances, our company made these F5CAB3 practice materials with accountability. We understand you can have more chances being accepted by other places and getting higher salary or acceptance. Our F5CAB3 Training Materials are made by our responsible company which means you can gain many other benefits as well. You can enjoy free updates of F5CAB3 practice guide for one year after you pay for our F5CAB3 training questions.
| Section | Objectives |
|---|---|
| Traffic Management and Load Balancing | - Load Balancing Methods
|
| F5 BIG-IP System Fundamentals | - Initial Configuration and System Components
|
| Advanced Traffic Control | - Monitoring and Health Checks
|
| Traffic Processing and Policies | - Profiles and Protocol Handling
|
| High Availability and Troubleshooting | - Device Service Clustering (DSC)
|
In this Desktop-based F5 F5CAB3 practice exam software, you will enjoy the opportunity to self-exam your preparation. The chance to customize the F5 F5CAB3 practice exams according to the time and types of BIG-IP Administration Data Plane Configuration (F5CAB3) practice test questions will contribute to your ease. This format operates only on Windows-based devices. But what is helpful is that it functions without an active internet connection. It copies the exact pattern and style of the real BIG-IP Administration Data Plane Configuration (F5CAB3) exam to make your preparation productive and relevant.
NEW QUESTION # 49
A web server administrator informs the BIG-IP Administrator that web servers currently load-balanced require encrypted traffic. Starting next month, the web server administrator will offload SSL. Starting next month, the BIG-IP device will terminate SSL to reduce web server load. The BIG-IP device is already using Client SSL, Client port, and iRules on HTTP traffic. What actions should the BIG-IP Administrator take to achieve the desired configuration? (Choose one answer)
Answer: B
Explanation:
To solve this requirement, we must distinguish between the two "legs" of an SSL connection in a BIG-IP environment: Client-side and Server-side.
Current State (SSL Bridging): The administrator states the servers currently require encrypted traffic. This means the BIG-IP is likely performing "SSL Bridging." In this setup, a Client SSL profile terminates encryption from the user, and a Server SSL profile re-encrypts the traffic before sending it to the back-end servers.
Target State (SSL Offloading): The requirement is to "offload SSL" to reduce web server load. This means the BIG-IP will continue to handle the encryption for the users (keeping the Client SSL profile) but will communicate with the back-end servers using unencrypted HTTP.
Why Option A is correct:
Remove the Server SSL profile: By removing this profile, the BIG-IP stops attempting to initiate an SSL/TLS handshake with the pool members.
Configure Pool Members to use HTTP: The service port for the pool members must be changed (typically from port 443 to port 80) so that the BIG-IP sends standard HTTP traffic to the servers.
Why other options are incorrect:
B & D: These suggest removing the Client SSL profile. If you remove this, the users can no longer connect via HTTPS, which violates the requirement for encrypted communication between the users and the BIG-IP.
C: Changing the Virtual Server to accept HTTP traffic would mean the user-to-BIG-IP connection is no longer encrypted, which is the opposite of SSL termination/offloading.
NEW QUESTION # 50
An organization is reporting slow performance accessing their Intranet website. All employees use a single Proxy Server with a public IP.
What should the BIG-IP Administrator do to fix this issue?
Answer: C
Explanation:
When multiple users share one source IP, source-address persistence fails. Cookie persistence uniquely identifies users at Layer 7 and ensures correct session handling.
NEW QUESTION # 51
Application administrators are reporting that nodes different from those configured in the pool are selected.
The use of an iRule is suspected.
How can the BIG-IP Administrator check if an iRule is used for this traffic? (Choose two answers)
Answer: B,C
Explanation:
In BIG-IP systems, iRules influence traffic only when they are attached to a Virtual Server. If application traffic is being sent to nodes or pool members that are not defined in the pool, this typically indicates that an iRule is overriding the default load-balancing behavior by explicitly selecting a pool or node.
According to BIG-IP Administration: Data Plane Configuration and official F5 guidance:
* iRules are associated with Virtual Servers, not directly with pools or nodes.
* To determine whether an iRule is actively affecting traffic, the administrator must inspect the Virtual Server configuration.
Explanation of the correct answers:
* B. Via the GUI at the Resources tab for the virtual serverThe Resources tab in the Configuration Utility displays all traffic-handling objects applied to the Virtual Server, including assigned iRules. This is the primary GUI location to verify whether an iRule is influencing data plane traffic.
* C. Via TMSH with the list /ltm virtual <virtual_server> commandThis TMSH command displays the full Virtual Server configuration, including any iRules listed under the rules section. It is the authoritative CLI method to confirm iRule usage.
Why the other options are incorrect:
* A. Via TMSH with the list /ltm rule <irule> commandThis command only shows the contents of an iRule and does not indicate whether the iRule is attached to or used by any Virtual Server.
* D. Via the GUI at the iRule tab for the virtual serverBIG-IP does not provide a dedicated "iRule" tab on Virtual Servers. iRules are viewed and managed under the Resources tab.
Correct Conclusion:
To verify whether an iRule is responsible for unexpected node selection, the BIG-IP Administrator must examine the Virtual Server configuration, either through the Resources tab in the GUI or by using TMSH to list the Virtual Server configuration.
NEW QUESTION # 52
Refer to the exhibit.
A BIG-IP Administrator creates a new Virtual Server to load balance SSH traffic. Users are unable to log on to the servers.
What should the BIG-IP Administrator do to resolve the issue? (Choose one answer)
Answer: A
Explanation:
SSH is a Layer 4 TCP-based protocol that operates on TCP port 22 and does not use HTTP in any capacity. In the exhibit, the Virtual Server is configured with an HTTP Profile applied, which is inappropriate for SSH traffic and causes connection failures.
According to the BIG-IP Administration: Data Plane Configuration documentation:
* An HTTP profile must only be applied to Virtual Servers handling HTTP or HTTPS traffic.
* When an HTTP profile is attached, BIG-IP expects HTTP headers and attempts to parse application- layer data.
* Non-HTTP protocols such as SSH, FTP (control), SMTP, and other raw TCP services will fail if an HTTP profile is enabled.
Why the other options are incorrect:
* A. Set Protocol to UDPSSH uses TCP, not UDP. Changing the protocol would break SSH entirely.
* B. Set Source Address to 10.1.1.2The source address setting controls client access restrictions and is unrelated to protocol parsing issues.
* C. Set Destination Address/Mask to 0.0.0.0/0The destination address is already valid for a specific SSH service and does not impact protocol handling.
Correct Resolution:
The BIG-IP Administrator should remove the HTTP Profile (set it to None) so the Virtual Server functions as a pure Layer 4 TCP service, allowing SSH connections to pass through successfully.
NEW QUESTION # 53
Local Traffic Network Map: VS_HTTP # POOL_WEB # 192.168.212.30:80 Pool Member | Parent Node
192.168.212.30 Port 80
Why is the virtual server unresponsive to incoming connections?
Answer: D
Explanation:
In the BIG-IP object hierarchy, a Pool Member is a child object of a Node . A pool member represents a specific IP:Port combination, while the parent node represents the underlying server IP address. When a node is disabled , all pool members that are children of that node are rendered unavailable - regardless of the individual pool member ' s own health or enabled state.
The Network Map depicted shows the pool member (192.168.212.30:80) with its Parent Node (192.168.212.30) disabled. This parent-child dependency means that even if the pool member itself is healthy and enabled, the disabled node cascades its unavailable state downward, causing the pool to have no available members and rendering VS_HTTP unresponsive to incoming connections.
The other options can be eliminated as follows:
* Pool member monitor failed - the monitor status is not indicated as failed in the Network Map display.
* Pool member is disabled - the pool member itself is not shown as disabled; the parent node is.
* Node monitor failed - no monitor failure is indicated; the node ' s administrative state is explicitly disabled.
Understanding the node-to-member inheritance of availability state is fundamental to accurate BIG-IP traffic troubleshooting.
Reference: BIG-IP Administration - Data Plane Configuration, Module: Pool Members, Nodes, and Availability State Inheritance.
NEW QUESTION # 54
......
