| Section | Objectives |
|---|---|
| Special Inspection Requirements | - Inspector duties and responsibilities - Special inspection procedures for tall mass timber buildings - Inspection of connections and protective materials |
| Structural Inspection | - Connections and fastening systems - Mass timber structural elements - Structural loads and related code requirements |
| Construction Fire Safety | - International Fire Code requirements - Protection of mass timber during construction - Construction-phase fire safety requirements |
| Code Compliance and Related Requirements | - Sound transmission requirements - Energy code requirements applicable to mass timber buildings - Documentation and verification of compliance |
| Fire Protection and Fire-Resistance | - Fire-resistance requirements - Noncombustible protection and protection of mass timber elements - Fire protection systems and related provisions |
| Tall Mass Timber Building Code Provisions | - International Building Code requirements for tall mass timber construction - Types IV-A, IV-B and IV-C construction - Mass timber materials and construction requirements |
>> 93-Tall-Mass-Timber-Buildings Testantworten <<
Nun ist eine Gesellschaft, die mit den fähigen Leuten überschwemmt. Aber viele Fachleute fehlen trotzdem doch. Beispielsweise fehlen in der IT-Branche Techniker. Und die International Code Council 93-Tall-Mass-Timber-Buildings Zertifizierungsprüfung sit eine Prüfung, die IT-Technik testet. ZertSoft ist eine Website, die Ihnen Kenntnise zur International Code Council 93-Tall-Mass-Timber-Buildings Zertifizierungsprüfung liefert.
10. Frage
Refer to the exhibit by clicking on the EXHIBIT button above.
In the detail shown, what is the required screw spacing in inches for the CLT to glulam connection?
Antwort: A
Begründung:
The connection detail specifies the CLT-to-glulam screws at 24 inches on center , so option D is correct. This is a construction-document interpretation question rather than a universal prescriptive screw-spacing requirement imposed by the IBC.
The approved structural detail controls the required spacing for this particular connection because the registered design professional has established the connection geometry and fastener schedule based on the applicable structural loads, CLT panel configuration, glulam member, fastener properties, and required load transfer. The 24-inch dimension must therefore be maintained in the field unless an approved revision changes the connection design.
IBC Table 1705.5.3 is directly relevant to the special inspector's responsibilities. For screws used in Type IV- A, IV-B, or IV-C mass timber connections, periodic special inspection includes verification of diameter, length, head type, spacing, installation angle, and installation depth . The special inspector is therefore expected to compare actual field installation against precisely this type of approved connection detail.
Substituting 12-, 16-, or 20-inch spacing without design authorization would constitute a deviation from the approved documents, even if the alternate spacing appeared more conservative.
References/Topics: Approved structural connection detail shown in the exhibit; 2021 IBC Section 1705.5.3 and Table 1705.5.3, inspection of screw spacing and installation.
11. Frage
Refer to the figure by clicking on the EXHIBIT button above.
In Type IV-B construction, unprotected portions of mass timber as shown in the Figure is limited to an area equal to not more than what percentage of the base floor area?
Antwort: B
Begründung:
The highlighted exposed surfaces in this figure are mass timber wall surfaces . Under 2021 IBC Section
602.4.2.2.2, Exception 1.2, unprotected portions of Type IV-B mass timber walls, including attached columns, are permitted up to an area equal to 40 percent of the floor area in the applicable dwelling unit or fire area.
Option D is therefore correct.
This should be distinguished from the corresponding ceiling limitation. Unprotected mass timber ceilings, including attached beams, are limited to 20 percent of floor area. The larger 40-percent allowance applies specifically to wall exposure.
Where only wall surfaces are exposed, the allowable wall area is calculated directly from the base floor area.
For example, a 1,000-square-foot fire area would permit up to 400 square feet of exposed wall surface under this exception. However, Section 602.4.2.2.4 additionally requires unprotected wall portions to maintain the prescribed 15-foot separation from other applicable exposed wall or ceiling portions.
Where exposed walls and exposed ceilings occur together, the individual 40- and 20-percent limits cannot simply be maximized simultaneously; the mixed-exposure equation in Section 602.4.2.2.3 governs.
References/Topics: 2021 IBC Sections 602.4.2.2.2 through 602.4.2.2.4; Type IV-B wall exposure.
12. Frage
Each of the following is true regarding the fire-resistance rating for exterior bearing walls except:
Antwort: C
Begründung:
Option A is the incorrect statement and therefore the required answer. Under 2021 IBC Table 601, an exterior bearing wall in Type IV-C construction requires a two-hour fire-resistance rating , not one hour.
The tall mass timber classifications progressively vary the degree of noncombustible protection and allowable exposure, but the structural fire-resistance requirements remain substantial. Type IV-A exterior bearing walls require three hours. Type IV-B exterior bearing walls require two hours. Type IV-C exterior bearing walls also require two hours. Thus, options B, C, and D correctly reproduce the Table 601 values.
The special inspector must also recognize that Table 601 is not necessarily the only rating criterion affecting an exterior wall. Exterior walls are additionally subject to the requirements associated with fire separation distance, particularly Table 705.5. Where another IBC provision requires a higher rating, that more restrictive condition controls.
For mass timber construction, compliance also depends on the prescribed protective system, member dimensions, connections, joints, intersections, and exterior-side protection. A wall cannot be accepted as compliant solely because the timber cross section appears substantial; it must conform to the approved rated design.
References/Topics: 2021 IBC Section 601; Table 601; Section 602.4; Table 705.5.
13. Frage
For CLT, which of the following standards is used for the determination of bond line shear test for adhesives?
Antwort: C
Begründung:
ANSI/APA PRG 320 is the governing product standard for performance-rated cross-laminated timber, including adhesive qualification, bond integrity, manufacturing quality control, and required product identification. Accordingly, option D is correct.
Bond-line performance is critical because CLT panels depend on structural adhesive to transfer shear forces between laminations and maintain composite action. PRG 320 establishes qualification and quality-assurance requirements intended to verify that adhesive bonds remain structurally reliable and resist delamination or inadequate bond development. Testing and manufacturing controls under this standard address the completed CLT product rather than treating the adhesive as an isolated material.
AITC 113 concerns dimensional tolerances and related requirements for structural glued-laminated timber rather than CLT bond-line shear qualification. ASTM C557 addresses adhesives for ceramic tile and is unrelated to structural timber manufacture. ANSI 117 is not the governing CLT manufacturing standard.
During inspection, the special inspector ordinarily does not reproduce factory bond-line tests on-site. Instead, the inspector verifies the CLT manufacturer's identification, certification marks, panel grade, layup designation, and conformance with PRG 320 and the approved construction documents.
References/Topics: 2021 IBC Section 2303.1.4; ANSI/APA PRG 320; CLT adhesive-bond qualification and manufacturing quality assurance.
14. Frage
A proprietary field-glued mass timber beam splice will require which of the following:
Antwort: A
Begründung:
A proprietary field-glued mass timber beam splice requires special inspection because the connection relies on a field-applied adhesive process that is not covered as a routine prescriptive mass timber connection in Table
1705.5.3. The controlling mechanism is IBC Section 1705.1.1, which authorizes the building official to require special inspection for unusual materials, systems, or installation procedures, particularly where compliance depends on additional manufacturer installation instructions.
The ICC code-development rationale for the tall mass timber provisions specifically identifies field-glued mass timber beam or panel splices as an example of work for which special inspection can be required.
Inspection must address the approved evaluation report and manufacturer's instructions, including substrate preparation, moisture and temperature limits, adhesive storage and expiration, mixing or proportioning, application quantity, open time, member alignment, clamping or pressure, and curing conditions.
Approval by the permit applicant has no regulatory significance. Verification by the registered design professional may supplement the inspection program but does not replace the approved special inspector. A building official may observe the work, but routine field verification by that official is not the prescribed quality-control procedure.
References/Topics: 2021 IBC Sections 1704.2, 1704.3 and 1705.1.1; special cases; proprietary field-glued mass timber splices.
15. Frage
......
