| Certification Vendor: | Fortinet |
|---|---|
| Exam Name: | Fortinet NSE 5 - FortiSwitch 7.6 Administrator |
| Exam Number: | NSE5_FSW_AD-7.6 |
| Exam Format: | Scenario-based, Multiple choice, Multiple select |
| Exam Price: | USD 200 (excluding taxes) |
| Passing Score: | Pass/Fail (not publicly disclosed) |
| Certificate Validity Period: | 2 years |
| Exam Duration: | 70 minutes |
| Related Certifications: | Fortinet Certified Professional Secure Networking |
| Available Languages: | English, Japanese |
| Real Exam Qty: | 35–40 |
| Recommended Training: | Fortinet Training Institute |
| Exam Registration: | Pearson VUE Registration |
| Sample Questions: | Fortinet NSE5_FSW_AD-7.6 Sample Questions |
| Exam Way: | Online proctored or onsite at Pearson VUE test centers |
| Pre Condition: | No mandatory prerequisites; recommended knowledge of networking fundamentals and Fortinet products |
| Official Syllabus URL: | https://training.fortinet.com/local/staticpage/view.php?page=fcp_secure_networking |
NSE5_FSW_AD-7.6試験に実際に参加して資料を選択する前に、このような証明書を保持することの重要性を思い出してください。このようなNSE5_FSW_AD-7.6証明書を取得することで、昇給、昇進の機会、上司や同僚からの信頼など、将来の多くの同意結果を習得できます。これらすべての快い結果は、もはやあなたにとって夢ではありません。そして、NSE5_FSW_AD-7.6試験準備により、成績を改善し、生活の状態を変え、キャリアの驚くべき変化を得ることができ、すべてが可能になります。それはすべて、NSE5_FSW_AD-7.6学習の質問から始まります。
| トピック | 出題範囲 |
|---|---|
| トピック 1 |
|
| トピック 2 |
|
| トピック 3 |
|
| トピック 4 |
|
質問 # 88
Which two statements about VLAN assignments on FortiSwitch ports are true? (Choose two.)
正解：A、D
質問 # 89
Which drop policy mode, if assigned to a congested port, will drop incoming packets until there is no congestion on the egress port?
正解：A
解説：
Tail-drop mode is a congestion management technique used in network devices, including FortiSwitches, to handle congestion on network ports:
* Tail-Drop Mode (A):
* Behavior:When a queue reaches its maximum capacity on a congested port, tail-drop mode simply drops any incoming packets that arrive after the buffer is full. This continues until the congestion is alleviated and there is space in the queue to accommodate new packets.
* Application:This is a straightforward approach used when the device's buffer allocated to the port becomes full due to sustained high traffic, preventing buffer overflow and maintaining system stability.
References:For more details on congestion management techniques and settings on FortiSwitch, you can refer to the configuration manuals available on:Fortinet Product Documentation
質問 # 90
(Full question statement start from here)
A FortiGate is connected to a pair of FortiSwitch devices.
For redundancy, FortiGate must use uplinks on both switches simultaneouslywithout depending on Spanning Tree Protocol (STP).
Which configuration is required? (Choose one answer)
正解：C
解説：
In FortiSwitchOS 7.6, achieving link-level redundancy and active-active uplink utilization acrosstwo separate FortiSwitch unitsrequires a technology that operates independently of Spanning Tree Protocol (STP). This requirement is fulfilled byMultichassis Link Aggregation Group (MCLAG).
MCLAG allows two FortiSwitch devices to operate as alogical aggregation peer, presenting themselves as a single logical switch to an upstream device such as a FortiGate. With MCLAG, FortiGate can form a single LACP-based aggregated interfacethat spans both FortiSwitches. This enablessimultaneous use of uplinks on both switches, providing full bandwidth utilization and redundancy without blocking links, which is a fundamental limitation of STP-based designs.
According to the FortiSwitchOS 7.6 Administrator Guide, MCLAG synchronizes control-plane information between the two FortiSwitch peers using inter-switch links (ISLs) and dedicated keepalive mechanisms. This ensures consistent forwarding behavior and loop-free topology while allowing all member links to remain active. If one FortiSwitch fails, traffic continues to flow through the remaining switch with minimal disruption.
The other options do not meet the stated requirement. A standard LAG (Option D) operates only within a single switchand cannot span multiple FortiSwitch units. Multi-tier topology (Option A) and full mesh HA (Option C) describe architectural layouts or FortiGate HA concepts but do not provide link-level aggregation across switches.
Therefore, the only configuration that allows FortiGate to use uplinks on both FortiSwitches simultaneously without relying on STPisMultichassis Link Aggregation Group (MCLAG), makingOption Bthe correct and fully verified answer.
質問 # 91
Refer to the exhibit.
PC1 and PC2 are connected to port1 on FortiSwitch. Which VLAN tags will FortiSwitch apply when forwarding PC1 and PC2 traffic out of port2? (Choose one answer)
正解：A
解説：
According to theFortiSwitchOS 7.6 Administration Guideand theFortiSwitch 7.6 Study Guide, the classification of untagged traffic entering a switch port is determined by the port's hierarchy of VLAN assignment rules.
For the traffic arriving atport1:
* PC1 (MAC 58:ef:68:b4:33:32):The exhibit shows an explicitMAC-based VLAN assignmentrule for this specific MAC address, placing it intoVLAN 10. In FortiSwitchOS, dynamic assignments like MAC-based or protocol-based rules take precedence over the port's static native VLAN. Therefore, PC1's traffic is internally associated with VLAN 10.
* PC2 (MAC 58:ef:68:b4:33:c3):There is no MAC-based rule for this device. As a result, the switch falls back to the default behavior and assigns the traffic to the port'sNative VLAN, which isVLAN 20.
For the traffic exiting port2:
The egress behavior depends on the VLAN tagging configuration of the outgoing interface. On port2, the Native VLAN is 4094, and VLANs 10 and 20 are listed as Allowed VLANs. According to Fortinet documentation, any traffic belonging to an allowed VLAN that does not match the native VLAN ID of the egress port must be sent as tagged 802.1Q frames. Since neither VLAN 10 nor VLAN 20 matches the native ID of 4094, the FortiSwitch will apply a VLAN 10 tag to PC1's traffic and a VLAN 20 tag to PC2's traffic as they are forwarded to the FortiGate.
質問 # 92
On supported FortiSwitch models, which access control list (ACL) stage is recommended for applying actions before the switch performs any layer 2 or layer 3 processing? (Choose one answer)
正解：D
解説：
According to theFortiSwitchOS 7.6 Administration Guideand theNSE 5 FortiSwitch 7.6 Administrator Study Guide, FortiSwitch supports a multi-stage ACL pipeline that allows for granular traffic control at different points in a packet ' s journey through the switch.1The documentation identifies three primary stages for ACL application:Prelookup,Ingress, andEgress.
* Prelookup (Option D):This is the earliest stage in the switching pipeline. The documentation explicitly states thatPrelookup ACLsare processedbefore any Layer 2 or Layer 3 lookupsare performed by the switch hardware. This stage is highly recommended for high-performance security actions, such as dropping unwanted traffic immediately upon arrival, because it prevents the switch from wasting internal resources (CPU and ASIC lookup cycles) on frames that are destined to be discarded anyway.
* Ingress (Option A):This stage occursafterthe switch has completed its Layer 2 (MAC table) and Layer 3 (routing table) lookups butbeforethe packet is queued for the egress port. While powerful, actions here occur after initial processing has already taken place.
* Egress (Option C):This stage is processed just before the frame leaves the switch through the destination port. It is typically used for final modifications or filtering based on the outgoing interface context.
Therefore, to achieve the goal of applying actionsbeforeany Layer 2 or Layer 3 processing occurs, thePrelookupstage is the technically correct and recommended choice in FortiSwitchOS 7.6.Forwarding (Option B)is a general functional stage of a switch but is not a specific ACL stage type in the FortiSwitch configuration hierarchy.
質問 # 93
......
