질문 # 104
Which interfaces on FortiSwitch send out FortiLink discovery frames by default in order to detect a FortiGate with an enabled FortiLink interface?
정답：B
설명：
* Fortinet FortiLink Protocol:The FortiLink protocol is Fortinet ' s proprietary mechanism for managing FortiSwitch units from a FortiGate firewall. It simplifies configuration and security policy enforcement across the connected network devices.
* Auto-Discovery:FortiLink ' s auto-discovery feature means that by default, all ports on a FortiSwitch will actively send out discovery frames. This allows them to locate a FortiGate device that has a FortiLink interface enabled, streamlining the device management process.
* No Configuration Needed:You don ' t have to manually configure individual ports for FortiLink discovery on FortiSwitch devices.
References
* FortiSwitchOS FortiLink Guide (FortiSwitch Devices Managed by FortiOS 7.6):Refer to pages 13 and
14 for details on zero-touch management and FortiLink configuration. [https://fortinetweb.s3.
amazonaws.com/docs.fortinet.com/v2/attachments/27f63c72-b083-11ec-9fd1-fa163e15d75b
/FortiSwitchOS-7.6.0-FortiLink_Guide%E2%80%94FortiSwitch_Devices_Managed_by_FortiOS_7.6.
pdf]
질문 # 105
Exhibit.
port24 is the only uplink port connected to the network where access to FortiSwitch management services is possible. However, FortiSwitch is still not accessible on the management interface. Which two actions should you take to fix the issue and access FortiSwitch? (Choose two.)
정답：A,B
설명：
To enable access to the FortiSwitch management interface from the network, certain configuration adjustments need to be made, particularly considering the VLAN settings displayed in the exhibit:
* Adding port24 native VLAN to the allowed VLANs on internal (Option A): The management VLAN (VLAN 4094 in this case, as it is set as the native VLAN on the 'internal' interface of the FortiSwitch) must be included in the allowed VLANs on the interface that provides management connectivity. Since port24 is set with a different native VLAN (VLAN 100), VLAN 4094 (the management VLAN) should be allowed through to ensure connectivity.
* Allow VLAN ID 4094 on port24 if management traffic is tagged (Option C): Management traffic is tagged on VLAN 4094. Since port24 is connected to the network and serves as an uplink, allowing VLAN 4094 ensures that management traffic can reach the management interface of the FortiSwitch through this port.
The changes align with Fortinet's best practices for setting up management VLANs and ensuring they are permitted on the relevant switch ports for proper management traffic flow.
References:
FortiGate Infrastructure and Security 7.2 Study Guides
Best practices for VLAN configurations in Fortinet's technical documentation
질문 # 106
Refer to the exhibit.
The command diagnose switch physical-ports summary is executed on FortiSwitch.
Based on the VLAN assignments shown in the output, what is the most likely management configuration of this FortiSwitch? (Choose one answer)
정답：D
설명：
The output of the diagnose switch physical-ports summary command provides critical insight into how a FortiSwitch is being managed by examiningVLAN assignments,tag protocol identifiers (TPID), andinternal port behavior. In the provided exhibit, several ports-includingport1,port5, and theinternalport-are assigned toVLAN 4094.
According to the FortiSwitchOS 7.6 Administrator Guide,VLAN 4094 is reserved for FortiLink management trafficwhen a FortiSwitch is managed by a FortiGate. FortiLink uses this dedicated VLAN to carry control- plane traffic such as configuration synchronization, monitoring data, LLDP-based discovery, and keepalive messages between the FortiGate and FortiSwitch. The presence of VLAN 4094 on physical interfaces is a strong and explicit indicator ofFortiGate-managed mode.
In standalone or local management mode, FortiSwitch ports typically default toVLAN 1or administrator- defined VLANs, andVLAN 4094 is not automatically assigned. Similarly, FortiSwitch Cloud-managed devices do not use VLAN 4094 in this manner, as cloud management relies on IP connectivity to FortiEdge Cloud rather than FortiLink encapsulation.
Additionally, the internal port showing VLAN 4094 further confirms FortiLink operation, as this internal interface is used by the switch ASIC to communicate with the FortiGate over the FortiLink tunnel. This behavior is documented in FortiOS 7.6 and FortiSwitchOS 7.6 design guides as characteristic of FortiGate- managed FortiSwitch deployments.
Therefore, based on the VLAN assignments shown-specifically the use ofVLAN 4094-the most accurate and fully verified conclusion is thatthe FortiSwitch is managed by FortiGate, makingOption Bthe correct answer.
질문 # 107
What is the role of a device that is simultaneously functioning as both the distribution and core in the hierarchy network model?
정답：B
설명：
In a hierarchical network model, the role of a device functioning simultaneously as both the distribution and core is most accurately described as "FortiGate managing FortiSwitch (B)." In this setup, FortiGate acts as the central unit managing multiple FortiSwitch units, thereby functioning both as a distribution layer-handling traffic between network segments-and as a core layer-managing traffic within the network on a broader scale. This setup is typical in medium-sized networks where a single device is capable enough to handle both roles effectively.
질문 # 108
You are configuring FortiSwitch to perform layer 3 inter-VLAN routing while managed by FortiGate over FortiLink. On supported hardware models, FortiSwitch can offload routing decisions for better performance.
1How does FortiSwitch perform routing between VLANs? (Choose one answer)
정답：B
설명：
According to theFortiSwitchOS 7.6 FortiLink Guideand theFortiSwitch 7.6 Study Guide, managed FortiSwitch units support a feature calledInter-VLAN Routing Offload. Traditionally, in a FortiLink deployment, traffic between VLANs is " hair-pinned " back to the FortiGate for routing and security inspection. However, to increase performance and reduce latency, the FortiGate can program the managed FortiSwitch to handle Layer 3 routing of trusted traffic locally.
The technical mechanism behind this performance gain is the use of theForwarding Information Base (FIB) programmed directly into the switch ' sASIC (Application-Specific Integrated Circuit). When routing offload is enabled (specifically using the set switch-controller-offload enable command on the VLAN interface), the FortiGate pushes the necessary routing table and gateway information to the switch hardware. This allows the FortiSwitch to perform packet lookups and forwarding decisions at wire speed within the silicon, bypassing the general-purpose CPU and the FortiLink control plane for that specific traffic flow.
The documentation notes that this feature requires anAdvanced Features Licenseon the tier-1 FortiSwitch and is typically applied to the switch closest to the FortiGate.2While dynamic routing (Option B) is supported on FortiSwitch, it is not theonlything offloaded; static routes and inter-VLAN gateway traffic are the primary use cases for this offload mechanism. Therefore, the correct architectural description is that the switch utilizes its hardware-based FIB to accelerate inter-VLAN communication.
