質問 # 40
Refer to the exhibits.
Two SD-WAN event logs, the member status, the SD-WAN rule configuration, and the health-check configuration for a FortiGate device are shown. Immediately after the log messages are displayed, how will the FortiGate steer the traffic based on the information shown in the exhibits? (Choose one answer)
正解：B
解説：
According to the SD-WAN 7.6 Core Administrator curriculum and the provided exhibits, the traffic steering decision is determined by the interaction between the Lowest Cost (SLA) strategy and the link health status reported in the event logs.
Rule Strategy (Lowest Cost SLA): The SD-WAN rule configuration for ID 1 (named Critical-DIA) is set to mode sla. In this mode, the FortiGate will only steer traffic through member interfaces that satisfy the assigned Performance SLA targets.
Member Preference: The rule defines priority-members 1 2. This means that under normal conditions (where both links are healthy), Member 1 (port1) is the preferred interface because it is listed first.
Event Log Analysis:
The first log message explicitly states: " Member status changed. Member out-of-sla. " for Member 1. This indicates that port1 has exceeded one of the thresholds (latency, jitter, or packet loss) defined in the Corp_HC health check.
The second log confirms: " Number of pass member changed. New Value: 1, Old Value: 2 " . This verifies that while there were previously two links passing the SLA, now only one link (Member 2/port2) remains in a passing state.
Steering Decision: Because the rule strategy is mode sla and the primary preferred member (port1) is now out- of-sla, the FortiGate immediately disqualifies Member 1 from the selection pool for this specific rule. It then moves to the next available member in the priority list that does satisfy the SLA, which is Member 2 (port2).
Why other options are incorrect:
Option A: FortiGate will not load balance or choose between both links because port1 is currently ineligible due to the SLA failure.
Option B: Steering to port1 would violate the " Lowest Cost (SLA) " rule logic, as that link is no longer meeting the required health standards.
Option D: FortiGate does not " skip " the rule unless no members meet the SLA and there is no fallback configured; in this scenario, port2 is still passing and available.
質問 # 41
Which two statements correctly describe what happens when traffic matches the implicit SD-WAN rule?
(Choose two answers)
正解：B、D
解説：
According to theSD-WAN 7.6 Core Administratorstudy guide andFortiOS 7.6 Administration Guide, the
"implicit rule" is the default rule at the bottom of the SD-WAN rule list (ID 0). It is only evaluated if traffic does not match any manually configured SD-WAN rules.
* Policy Route Table Context (Option B): SD-WAN rules are technically a specialized form of policy- based routing. For a packet to match theimplicit rule, it must first pass through the routing hierarchy. If traffic matches the implicit rule, it indicates that it did not match any higher-priority user-defined SD- WAN rules or any specific entries in the manualpolicy route tablethat would have intercepted the traffic earlier.
* Session Information (Option E): When you use the CLI to inspect an active session (e.g., diagnose sys session list), the output contains a field for theSD-WAN Service ID. If traffic is steered by a user- defined rule, it displays the ID of that rule (e.g., service_id=1). However, when traffic falls through to theimplicit rule, the session information displaysno SD-WAN service ID(it often shows as 0 or is omitted), because the implicit rule does not function as a "service" in the same way user-defined rules do.
* Routing Behavior: The implicit rule follows the standard routing table (RIB/FIB) logic. It uses the priorityanddistanceof the static routes to determine the path. If multiple paths have the same distance and priority, it uses the algorithm set by v4-ecmp-mode, but this is a function of the routing engine, not the SD-WAN engine itself.
Why other options are incorrect:
* Option A: While v4-ecmp-mode (e.g., source-ip-based) is used for ECMP routing, this is part of the general FortiOS routing behavior for equal-cost paths in the FIB, whereas the implicit rule simply
"hands over" the decision to that routing table.
* Option C: When traffic matches the implicit rule, the session is actually flagged with vwl_id=0 and potentially dirty if a route change occurs, but vwl_default is not the standard flag name used in this specific context in the curriculum.
* Option D: This is incorrect because the implicit ruledoes respect weight, distance, and priorityas defined in the static routes within the routing table; it does not distribute traffic "regardless" of these values.
質問 # 42
You have configured the performance SLA with the probe mode as Prefer Passive.
What are two observable impacts of this configuration? (Choose two.)
正解：A、E
解説：
When "Prefer Passive" is set, FortiGate attempts to passively monitor the health of SD-WAN members using real application traffic like TCP sessions, collecting statistics such as latency, jitter, and packet loss from actual observed flows.
Passive monitoring does not generate probe packets; it relies entirely on existing traffic. If there is no matching traffic, health check data is unavailable, meaning dead members may go undetected when only passive monitoring is active.
質問 # 43
Refer to the exhibit.
The SD-WAN rule status and configuration is shown. Based on the exhibit, which change in the measured latency will first make HUB1-VPN3 the new preferred member?
正解：D
解説：
According to the SD-WAN 7.6 Core Administrator study guide and the FortiOS 7.6 Administration Guide
, the selection of a preferred member in a Best Quality (priority) rule is determined by the measured quality metric (latency, in this case) and the link-cost-threshold .
* Rule Logic (Best Quality) : In the exhibit, the SD-WAN rule is configured with set mode priority, which corresponds to the Best Quality strategy. This strategy ranks members based on the link-cost- factor, which is set to latency .
* The Link-Cost-Threshold : The exhibit shows link-cost-threshold(10), which is the default 10% value.
This threshold is designed to prevent " link flapping " . To replace the current preferred member, a new member must not only have a better latency but must be better by more than 10% .
* The Calculation :
* The current preferred member is HUB1-VPN1 with a real latency of 96.349 ms .
* To calculate the " target " latency a lower-priority member must achieve to take over, we use the formula: $Target = \frac{Current\_Latency}{(1 + \frac{Threshold}{100})}$.
* $\frac{96.349}{1.1} = \mathbf{87.59\text{ ms}}$.
* Evaluating Options :
* Option A (80 ms) : Since 80 ms is lower than the required 87.59 ms target, HUB1-VPN3 successfully overcomes the 10% advantage of HUB1-VPN1 and becomes the new preferred member.
* Option D (90 ms) : While 90 ms is lower than 96.349 ms, it is not lower than 87.59 ms.
Therefore, the 10% threshold prevents a member switch, and HUB1-VPN1 remains preferred.
* Option B : Incorrect because having a " lower " latency is not enough due to the 10% threshold.
* Option C : If HUB1-VPN1 moved to 200 ms, HUB1-VPN2 (at 141.278 ms) would likely become the new preferred member before HUB1-VPN3 (at 190.984 ms).
質問 # 44
Which three reports are valid report types in FortiSASE? (Choose three.)
正解：C、D、E
質問 # 45
......
