問題 #47
Examine the exhibit below.
Spoke1 and Spoke2 are part of Spoke-to-Hub-Only spoke group, the hub is advertising a default route to both the spokes.
Referring to the exhibit, which statement is true?
答案：C
解題說明：
In Versa SD-WAN, a Spoke-to-Hub-Only topology is specifically designed for deployments where spoke branches communicate only with hub resources and not with other spokes. Versa's SD-WAN design documentation states that in a spoke-to-hub-only topology, the default behavior is that only hub routes are advertised, and spoke routes are not re-advertised by the hub branch. It also explains that this topology is used when spokes do not have to communicate with each other.
Even though the hub in the exhibit advertises a default route, that does not change the topology behavior into spoke-to-spoke communication. The default route can attract unknown traffic from the spokes toward the hub, but the Spoke-to-Hub-Only policy prevents the spoke prefixes from being redistributed or imported in a way that allows spoke-to-spoke reachability. Versa documentation further shows that spoke routes are filtered using BGP communities and import policies, and that the spoke route table contains only destinations behind the hubs, not other spoke routes.
問題 #48
You have deployed a group of devices in Versa Director, and the field technicians have performed the onboarding tasks onsite. One of the devices has not finished the onboarding process and does not appear in the Appliances list in Versa Director. The onboarding VPN tunnel from the device to the Controller is up.
Which two actions would help you solve this problem? (Choose two.)
答案：C,D
解題說明：
The correct answers are A and C . If the onboarding VPN tunnel from the branch device to the Controller is up, the branch has reached at least the initial staging/control connectivity stage. Versa troubleshooting documentation explains that after a branch establishes IPsec connectivity to the Controller, the Controller sends a branch-connect notification to Versa Director. In response, Director pushes staging configuration and continues the onboarding lifecycle. If the expected later notification is not seen, the branch has not completed staging and further onboarding/debug steps are required.
The Tasks list in Versa Director is useful because device deployment and onboarding actions are executed as Director tasks. If template commit, workflow deployment, device claiming, or configuration push fails, the task output can show the error. The Unknown Devices dashboard is also relevant because a device that reaches the Controller but cannot be matched or fully associated with an expected workflow/appliance record may appear as an unknown device awaiting administrative review. The Monitor dashboard is not the best choice because the device is missing from the Appliances list and has not completed onboarding. Resource Pool is related to connector resources, not branch onboarding completion.
問題 #49
An SD-WAN branch is deployed behind a NAT device. In the VSM local-tunnel-site output, which field or flag indicates that a WAN link is behind NAT?
答案：B
解題說明：
The correct answer is A . Versa SD-WAN data-path troubleshooting documentation shows the VSM local- tunnel-site output and includes a legend in which BN means Behind NAT . In the WAN local link details, the output also displays a field named WAN lcl link behind NAT , with values such as 1 or 0, and link flags including [ BN CT PT SLA-P ] when the WAN link is behind NAT.
This information is important because NAT status affects how SD-WAN tunnel endpoints are discovered and how public and private transport addresses are represented. The same output includes both public and private WAN link addresses, making it useful for troubleshooting sites behind NAT, stale tunnel endpoints, or incorrect public-address learning.
WAN lcl vrf-id identifies the local transport routing instance ID, not NAT status. Tenant ID identifies the tenant context. Neighbour site type identifies whether the remote endpoint is a Controller, hub, or SD-WAN site. None of those fields specifically confirms whether the local WAN transport is behind NAT.
問題 #50
Examine the exhibit below.
The exhibit shows a device group created for a new group of hubs. The device template called "BMBF- TEMPLATE" has an Address object called "Server". A network administrator creates the Class of Service Template called "Ship-CoS-IT" that has an Address object with the same name. Then it tries to onboard a new device to this device group.
Which statement is true about the configuration that this device will have?
答案：C
解題說明：
The correct answer is D . In the displayed post-staging template association order, the device template BMBF- TEMPLATE is applied before the QoS service template Ship-CoS-IT . Versa documentation explains that device templates, also called post-staging templates, provide the baseline configuration for devices, while service templates are service-specific configurations that can be applied to device configurations. It also states that service templates are associated with device groups and that, in a device group, the administrator can choose the order in which service templates are applied.
Because the QoS template is later in the shown association order, the final merged device configuration uses the Address object definition from the QoS template when the same object name exists in both templates. It does not automatically create two copies of the same Address object, because the object name is the key for the configuration element. It also should not fail merely because the same object name exists in a later template; the merge behavior resolves the effective configuration according to the template order. Therefore, the onboarded hub device receives the Server Address object version from Ship-CoS-IT, the QoS template.
問題 #51
What are three roles that VOS performs? (Choose three.)
答案：B,C,E
解題說明：
The correct answers are A, B, and E . Versa Operating System, or VOS , is the software platform used for Versa SD-WAN branch and headend functions. Versa troubleshooting documentation explicitly refers to common runtime state across SD-WAN Controller, branch, and hub devices , confirming that VOS is used for Controller and branch-style SD-WAN roles. Versa monitoring documentation also lists SD-WAN branches, SD-WAN Controller nodes, SD-WAN hubs, vCPEs, and uCPEs as assets that are monitored and managed in Versa Director, which aligns with VOS being used as a branch/edge and controller platform.
VOS can also act as a uCPE platform . Versa documentation includes procedures to configure uCPE on a VOS device, showing that VOS can host or support uCPE deployment use cases.
The originally provided answer A, C, D is not correct. A Log Collector or log forwarder function belongs to the Versa Analytics architecture, not the VOS branch role; Versa's design guide states that the log forwarder is part of the Versa Analytics node or can run as a standalone log-forwarder server.
A Zookeeper arbiter is also not a standard VOS SD-WAN device role in this context.
問題 #52
......
