| Section | Objectives |
|---|---|
| Topic 1: Structural Inspection | - Structural loads and related code requirements - Connections and fastening systems - Mass timber structural elements |
| Topic 2: Tall Mass Timber Building Code Provisions | - International Building Code requirements for tall mass timber construction - Types IV-A, IV-B and IV-C construction - Mass timber materials and construction requirements |
| Topic 3: Code Compliance and Related Requirements | - Documentation and verification of compliance - Energy code requirements applicable to mass timber buildings - Sound transmission requirements |
| Topic 4: Fire Protection and Fire-Resistance | - Noncombustible protection and protection of mass timber elements - Fire-resistance requirements - Fire protection systems and related provisions |
| Topic 5: Special Inspection Requirements | - Inspection of connections and protective materials - Inspector duties and responsibilities - Special inspection procedures for tall mass timber buildings |
| Topic 6: Construction Fire Safety | - International Fire Code requirements - Construction-phase fire safety requirements - Protection of mass timber during construction |
>> 93-Tall-Mass-Timber-Buildingsオンライン試験 <<
時間が経つとともに、JPTestKingはより多くの受験生から大好評を博します。弊社の93-Tall-Mass-Timber-Buildings資料は99％の成功率を持っていますから、弊社のInternational Code Councilの93-Tall-Mass-Timber-Buildings練習問題を利用したら、最もよい結果を得ることができます。弊社の93-Tall-Mass-Timber-Buildings練習問題さえ使用すれば試験の成功までもっと近くなります。
質問 # 18
All of the following combustible elements may be used in mass timber buildings except:
正解：B
解説：
A conventional 2 × 6 solid-sawn stud is a light-frame member and does not satisfy the minimum cross- sectional dimensions associated with mass timber or heavy-timber construction. Therefore, option A is the exception.
The IBC defines mass timber as Type IV structural elements primarily composed of solid, built-up, panelized or engineered wood products that meet the minimum cross-sectional dimensions required for Type IV construction. A nominal 2 × 6 stud is substantially smaller than those dimensions and is ordinarily classified as conventional light-frame construction. Its use might be permitted in a particular nonstructural partition or another specifically authorized application, but it is not itself a qualifying mass timber structural element.
CLT is expressly recognized as a mass timber panel product. Parallel-strand lumber is a form of structural composite lumber and can qualify where it satisfies the applicable minimum dimensions, product-standard requirements and approved structural design. Dowel-laminated timber is a built-up panelized timber product and may likewise serve as a mass timber element when its dimensions, engineering and approval satisfy the construction documents and code.
The classification depends on the completed element's dimensions and approved structural function-not merely on the fact that it is manufactured from wood.
References/Topics: 2021 IBC Chapter 2 definitions of "Mass Timber" and "Conventional Light-Frame Construction"; Sections 602.4 and 2304.11.
質問 # 19
Refer to the exhibit by clicking on the EXHIBIT button above.
In the detail shown, if the connections between the glulam beam and CLT panels all require a fire-resistance rating of one (1) hour and the wood cover is designed per AWC Technical Report 10 to provide the entire 1 hour of protection, what is the minimum thickness and number of layers required for the locations shown in red?
正解：B
解説：
Two layers of 5/8-inch Type X gypsum wallboard are required for the condition shown, so option D is correct. The relevant AWC TR10 connection-protection methodology distinguishes between outer gypsum layers and the base layer immediately adjacent to the connection .
For 5/8-inch Type X gypsum board, an outer layer contributes 40 minutes. However, when gypsum board is being relied upon as the complete thermal-separation protection for a connection, TR10 reduces the contribution of the final/base layer to 50 percent. Therefore, the base layer contributes 20 minutes , while the second, exterior layer contributes 40 minutes . The total is:
20 minutes + 40 minutes = 60 minutes .
That satisfies the one-hour required protection period.
This is why simply looking at the normal 40-minute contribution of one 5/8-inch Type X layer would be incorrect for this connection condition. TR10 expressly uses the reduced base-layer contribution when gypsum constitutes the connection protection. The same methodology shows that four 5/8-inch Type X layers are needed for 120 minutes: 20 + 40 + 40 + 40 = 140 minutes, satisfying two hours.
References/Topics: AWC Technical Report No. 10, Sections 4.4.2 and connection-protection examples. TR10 states that outer 5/8-inch Type X layers provide 40 minutes each while the base layer provides 20 minutes.
質問 # 20
Refer to the figure by clicking on the EXHIBIT button above.
The exterior wall section shown in the Figure provides the prescribed noncombustible protection required by which Construction Type?
正解：C
解説：
The illustrated wall corresponds to Type IV-A construction , making option A correct. The key indicator is the extensive Type X gypsum protection provided on the interior face of the CLT wall. Figure 63 shows multiple layers of 5/8-inch Type X gypsum board protecting the interior mass timber, together with the required exterior-side protection.
Type IV-A is the most comprehensively protected of the three tall mass timber construction classifications.
IBC Section 602.4.1.2 requires the interior faces of all mass timber elements , including the inside face of exterior mass timber walls, to be protected with qualifying noncombustible material. Section 602.4.1.2.1 requires the protection contribution to satisfy Table 722.7.1(1) and never be less than 80 minutes. Type IV-A exterior walls also require at least 40 minutes of noncombustible protection on the outside face.
The three interior layers shown are consistent with a heavily protected Type IV-A rated wall. By contrast, Type IV-B permits limited exposed interior mass timber, while Type IV-C expressly permits mass timber interior elements to remain unprotected. Type IV-HT operates under fundamentally different heavy-timber provisions.
References/Topics: 2021 IBC Sections 602.4.1.1, 602.4.1.2 and 602.4.1.2.1; Tables 601 and 722.7.1(1)-(2).
質問 # 21
What fire-resistance rating is required for floors in Type IV-A, IV-B and IV-C construction?
正解：C
解説：
IBC Table 601 requires floor construction and associated secondary structural members in Types IV-A, IV-B, and IV-C construction to have a two-hour fire-resistance rating. Therefore, option B is correct.
This requirement applies to the complete floor assembly, not only the timber panel. The required two-hour performance may be established through the calculated fire resistance of the mass timber, the contribution of approved noncombustible protection, or a permitted combination of both. Any topping, protective membrane, connection protection, and edge condition that forms part of the approved rated design must be installed accordingly.
The ratings for other building elements should not be transferred to the floor. A three-hour rating applies to the primary structural frame and bearing walls of Type IV-A, but its floor construction remains two hours.
Type IV-B and Type IV-C floors also require two hours, even though those construction types permit different degrees of exposed mass timber.
The special inspector must verify panel dimensions, approved layup, protection layers, joints, penetrations, connections, topping thickness, and other details that influence the floor's rated performance.
References/Topics: 2021 IBC Sections 601 and 602.4; Table 601, floor construction and associated secondary structural members.
質問 # 22
Given: A special inspector notices on a mass timber building set of drawings a 8 in. x 8 in. solid sawn nominal dimension lumber element.
The design team has recommended the solid sawn member be replaced with an SCL element.
What minimum SCL size would be correct per the International Building Code?
正解：B
解説：
The IBC does not require structural composite lumber to retain the same nominal dimensions as the solid- sawn member it replaces. Instead, the minimum finished dimensions are determined from the heavy-timber dimensional equivalency provisions in Section 2304.11.
For a solid-sawn member having nominal dimensions of 8 inches by 8 inches, the corresponding minimum structural composite lumber net dimensions are 7 inches in width by 7-1/2 inches in depth. Therefore, option B is correct. The dimensional conversion recognizes that nominal solid-sawn dimensions differ from actual manufactured dimensions and that SCL products are produced to controlled net dimensions.
The 6-3/4-inch by 8-1/4-inch dimensions in option C correspond to the minimum glued-laminated timber equivalency for an 8-inch-by-8-inch nominal solid-sawn member, not the SCL equivalency. Option D incorrectly assumes that the SCL member must retain the original nominal dimensions, while option A does not match the required equivalency for either SCL or glued-laminated timber.
The substitution must also be approved by the registered design professional because dimensional compliance alone does not establish equivalent structural capacity, connection behavior, fire resistance, or load-path performance.
References/Topics: 2021 IBC Section 2304.11; heavy-timber minimum dimensions; minimum structural composite lumber net-size table.
質問 # 23
......
