NEW QUESTION # 102
Refer to the exhibit.
PC1 and PC2 are connected to port1 on FortiSwitch. Which VLAN tags will FortiSwitch apply when forwarding PC1 and PC2 traffic out of port2? (Choose one answer)
Answer: D
Explanation:
According to theFortiSwitchOS 7.6 Administration Guideand theFortiSwitch 7.6 Study Guide, the classification of untagged traffic entering a switch port is determined by the port ' s hierarchy of VLAN assignment rules.
For the traffic arriving atport1:
* PC1 (MAC 58:ef:68:b4:33:32):The exhibit shows an explicitMAC-based VLAN assignmentrule for this specific MAC address, placing it intoVLAN 10. In FortiSwitchOS, dynamic assignments like MAC- based or protocol-based rules take precedence over the port ' s static native VLAN. Therefore, PC1 ' s traffic is internally associated with VLAN 10.
* PC2 (MAC 58:ef:68:b4:33:c3):There is no MAC-based rule for this device. As a result, the switch falls back to the default behavior and assigns the traffic to the port ' sNative VLAN, which isVLAN 20.
For the traffic exiting port2:
The egress behavior depends on the VLAN tagging configuration of the outgoing interface. On port2, the Native VLAN is 4094, and VLANs 10 and 20 are listed as Allowed VLANs. According to Fortinet documentation, any traffic belonging to an allowed VLAN that does not match the native VLAN ID of the egress port must be sent as tagged 802.1Q frames. Since neither VLAN 10 nor VLAN 20 matches the native ID of 4094, the FortiSwitch will apply a VLAN 10 tag to PC1 ' s traffic and a VLAN 20 tag to PC2 ' s traffic as they are forwarded to the FortiGate.
NEW QUESTION # 103
Refer to the exhibit.
You configured Switched Port Analyzer (SPAN) to monitor traffic from a source port on FortiSwitch 1, but the monitoring device is connected to FortiSwitch 2. After port mirroring configuration on FortiSwitch 1, the monitoring device is not receiving any mirrored traffic.
What is the most likely reason the mirrored traffic is not reaching the monitoring device? (Choose one answer)
Answer: A
Explanation:
Comprehensive and Detailed Explanation From Exact Extract of knowledge of FortiAnalyzer 7.6 Study guide documents:
* Standard SPAN Limitation: Switched Port Analyzer (SPAN) is a local port mirroring technology. By design, SPAN copies traffic from one or more source ports (or VLANs) to a destination port on the same physical switch.
* Traffic Forwarding: Standard SPAN traffic is not encapsulated and does not have the necessary headers to be routed or switched across a network fabric or trunk links between multiple switches.
Therefore, if the source port is on FortiSwitch 1 and the monitoring device is on FortiSwitch 2, the mirrored frames will not reach the destination.
* Alternative Solutions: To monitor traffic across multiple switches (multi-hop), technologies such as Remote SPAN (RSPAN)orEncapsulated Remote SPAN (ERSPAN)must be used. RSPAN uses a specific VLAN to carry the mirrored traffic across switches, while ERSPAN encapsulates the traffic in GRE packets so it can be routed across Layer 3 boundaries.
* Troubleshooting Conclusion: Since the scenario describes a standard SPAN configuration and the traffic is failing to traverse from FortiSwitch 1 to FortiSwitch 2, the most likely reason is that basic SPAN does not support forwarding mirrored traffic across multiple switches.
NEW QUESTION # 104
(Full question statement start from here)
How does enabling an IGMP snooping proxy on FortiSwitch help reduce the number of IGMP reports processed by the IGMP querier? (Choose one answer)
Answer: D
Explanation:
In FortiSwitchOS 7.6,IGMP snooping proxyis an enhancement to standard IGMP snooping that optimizes multicast control-plane traffic between hosts, switches, and the upstream IGMP querier. Its primary purpose is toreduce the number of IGMP membership reportsthat the querier must process, thereby improving scalability and efficiency in multicast-enabled networks.
Without an IGMP snooping proxy, every multicast receiver on a VLAN independently sends IGMP membership reports to the querier. In environments with many hosts subscribing to the same multicast groups, this behavior can generate a large volume of redundant IGMP reports, unnecessarily increasing control-plane load on both the querier and intermediate network devices.
When the IGMP snooping proxy feature is enabled, the FortiSwitch acts as anIGMP proxy agenton behalf of hosts within the VLAN. The switch tracks multicast group membership locally andsuppresses individual IGMP reports from downstream hosts. Instead, the FortiSwitch forwards an IGMP report upstreamonly when the first host joins a multicast group. Likewise, when hosts leave the group, the switch sends an IGMP leave message or reportonly when the last remaining member leaves.
This aggregation mechanism dramatically reduces IGMP signaling traffic while preserving correct multicast forwarding behavior. Importantly, the switch does not alter IGMP packet types or convert them to broadcast or unicast traffic. It simply optimizes reporting behavior based on group membership state.
Therefore, the correct explanation is that IGMP snooping proxy reduces IGMP report processingby forwarding IGMP reports only when the first member joins and the last member leaves, makingOption Dthe correct and fully verified answer according to FortiSwitchOS 7.6 documentation.
NEW QUESTION # 105
(Full question statement start from here)
Refer to the exhibit.
Which information does FortiGate use to generate the port details in the FortiSwitch Faceplates view?
(Choose one answer)
Answer: D
Explanation:
In a FortiLink-managed switching architecture, the FortiGate firewall acts as the centralized controller for downstream FortiSwitch devices. TheFortiSwitch Faceplatesview in the FortiGate GUI provides a physical- style representation of switch ports, including port numbers, operational status, link state, speed, duplex, and connected neighbor information. According to FortiOS 7.6 and FortiSwitchOS 7.6 documentation from Fortinet, this port-level intelligence is derived fromLink Layer Discovery Protocol (LLDP)advertisements received from the FortiSwitch.
LLDP is an IEEE 802.1AB standard protocol used for vendor-neutral Layer 2 neighbor discovery.
FortiSwitch periodically sends LLDP frames that include detailed port descriptors such as chassis ID, port ID, port description, system name, system capabilities, and VLAN-related attributes. When FortiGate receives these LLDP advertisements over the FortiLink interface, it correlates the information with the managed FortiSwitch inventory and renders accurate port details in the Faceplates view.
Other options are incorrect for the following reasons. The FortiSwitch model alone is insufficient to populate per-port operational details. Cisco Discovery Protocol (CDP) is a Cisco-proprietary protocol and is not used by FortiGate for Faceplates visualization. FortiLink discovery frames are used to establish and maintain the FortiLink management relationship, but they do not carry the granular per-port metadata required for the Faceplates display.
Therefore, the Faceplates view relies specifically onLLDP advertisements received from the FortiSwitch, making optionCthe correct and fully verified answer based on FortiOS 7.6 and FortiSwitchOS 7.6 behavior.
NEW QUESTION # 106
Refer to the exhibit.
You run the command diagnose switch physical-ports summary on FortiSwitch.
Based on exhibit, what does the output indicate to about the FortiSwitch mode? (Choose one answer)
Answer: C
Explanation:
According to the FortiSwitchOS 7.6 Administration Guide and the FortiSwitch 7.6 Study Guide , the diagnose switch physical-ports summary command provides an overview of physical interface states, VLAN memberships, duplex/speed parameters, and port encapsulation flags.
When a FortiSwitch operates in managed mode via FortiLink, two distinct characteristics appear in this command output:
* Management VLAN Assignment: The FortiLink control plane automatically establishes a dedicated management VLAN-by default, VLAN 4094 -and assigns it to the internal discovery interfaces and uplinks.
* Encapsulation Flags: Interfaces participating in the FortiLink fabric or Inter-Switch Links (ISLs) are assigned the TF (Forti Trunk) flag to indicate proprietary FortiLink management framing.
In the provided exhibit, every single interface (from port1 through port24, as well as the virtual internal interface) is assigned to default Vlan 1 . Furthermore, looking at the Flags column, port5 has QS (standard
802.1Q) and TL (standard LACP trunk), but no TF (Forti Trunk) flag is present on any interface. The absence of VLAN 4094, the complete absence of the TF flag, and the presence of the default factory VLAN 1 mapping confirm that this device is operating in standalone mode (Option C) .
Regarding the incorrect options: Option A is incorrect because port5 is bundled into a standard LACP 802.1Q trunk (QS, TL), not configured purely as an access port. Option B is incorrect because this output reflects Layer 2 switchport properties rather than Layer 3 routing interfaces. Option D is incorrect because managed mode would display FortiLink-specific VLANs and TF trunk flags.
