NEW QUESTION # 58
The BIG-IP Administrator is investigating disk utilization on the BIG-IP device. (Exhibit shows
/dev/md4 mounted on / at 100% utilization). What should the BIG-IP Administrator check next?
Answer: D
Explanation:
Monitoring resource utilization is essential for maintaining system stability. If the root (/) file system reaches 100% capacity, the BIG-IP may become unresponsive, fail to save configuration changes, or experience daemon crashes. When the / partition is full, the immediate troubleshooting step is to identify large or unnecessary files--such as old log files, core dumps, or temporary installer files--located specifically within that file system. In the provided exhibit,
/dev/md4 is explicitly listed at 100% usage for the / mount point. Checking other partitions like
/usr (which is at 82% in the exhibit) would not resolve the immediate "Full" status of the root directory. Administrators often use the du (disk usage) command via the CLI to find the problematic files. Managing disk space is a proactive task; however, when utilization hits 100%, it becomes a reactive troubleshooting emergency that must be resolved to restore the management plane's functionality.
NEW QUESTION # 59
A set of servers is used for an FTP application as well as an HTTP website via separate BIG-IP Pools. The server support team reports that some servers are receiving a lot more traffic than others. Which Load Balancing Method should the BIG-IP Administrator apply to even out the connection count?
Answer: B
Explanation:
When load balancing is not working as expected across hardware hosting multiple services, the administrator must distinguish between "member" and "node" level algorithms. A "member" is a specific IP and port (e.g., 10.1.1.1:80), while a "node" is the physical server's IP (10.1.1.1) regardless of the port. If servers host both FTP and HTTP services in separate pools, using
"Least Connections (Member)" only balances connections within each individual pool. This can lead to a skewed distribution where one server is selected for a new HTTP connection because it has the fewest HTTP connections, even if it is currently overloaded with hundreds of FTP connections. By applying "Least Connections (Node)," the BIG-IP tracks the total number of connections to the physical hardware across all ports and pools. This ensures that the administrator can maintain an even distribution of the total workload across the server fleet, resolving the reports of uneven traffic distribution reported by the server support team.
NEW QUESTION # 60
Refer to the exhibit. A BIG-IP Administrator creates a new Virtual Server to load balance SSH traffic. Users are unable to log on to the servers. What should the BIG-IP Administrator do to resolve the issue? (Exhibit shows a Standard Virtual Server with an HTTP profile applied).
Answer: B
Explanation:
When troubleshooting a Virtual Server that is not working as expected, it is critical to ensure that the applied profiles match the type of traffic being processed. SSH (Secure Shell) is a non-HTTP protocol that operates over TCP. The exhibit indicates that an HTTP profile is applied to the Virtual Server. An HTTP profile instructs the BIG-IP system to parse traffic as HTTP; however, since SSH traffic does not follow HTTP specifications, the BIG-IP's parser will fail to understand the data stream, typically resulting in dropped packets or reset connections. To fix this, the administrator must set the HTTP profile to "None". This allows the Virtual Server to act as a
"Standard" or "FastL4" listener that passes the encrypted SSH data transparently to the backend pool members without attempting application-layer inspection. This highlights a common troubleshooting step: verifying that L7 profiles are not inadvertently applied to L4 traffic, which disrupts the expected traffic flow between the client and the server.
NEW QUESTION # 61
Refer to the exhibit.
A user with IP address 192.168.162.70 is unable to connect to an HTTP application. What is a possible cause within the Virtual Server configuration?
Answer: A
Explanation:
The failure to connect is caused by a restrictive Source Address filter configured on the Virtual Server.
Source Address Filtering: In the BIG-IP system, the Source Address field on a Virtual Server acts as an implicit Access Control List (ACL). Only traffic originating from a client IP address that matches the specified network range will be accepted and processed by the Virtual Server.
Analyzing the Exhibit: The provided configuration for vs_http shows the Source Address is set to 10.128.10.0/24. This means the Virtual Server will only accept connections from the subnet ranging from 10.128.10.1 to 10.128.10.254.
Identifying the Conflict: The user trying to connect has the IP address 192.168.162.70. Since 192.168.162.70 does not fall within the allowed 10.128.10.0/24 range, the BIG-IP system will not match this traffic to the Virtual Server, effectively blocking the connection attempt.
Evaluation of Other Options:
All Ports (Option A): Configuring a Virtual Server for "All Ports" (port 0) allows it to handle traffic for any destination port, which would not block a standard HTTP application.
Destination Address (Option B): The destination address 192.168.162.80 is the Virtual IP (VIP) users should be connecting to; this is a standard configuration and not the cause of the failure for a user reaching out to it.
Standard Type (Option C): A "Standard" Virtual Server is the most common type used for HTTP applications as it allows for Layer 7 profiles and full proxy capabilities.
NEW QUESTION # 62
A pool member is exhibiting frequent up-and-down state changes, leading the BIG-IP Administrator to suspect a health monitor issue. Which specific log file should the BIG-IP Administrator review to diagnose the problem?
Answer: D
Explanation:
The Local Traffic Manager (LTM) log file is the primary repository for all events related to load balancing objects, including virtual servers, pools, and nodes.
* Monitor Logging: When a health monitor marks a pool member as "UP" or "DOWN," the system generates a log entry in /var/log/ltm.
* Diagnosing Flaps: To troubleshoot "flapping" (frequent state changes), an administrator would look for messages like 01010028:3: Pool /Common/http_pool member /Common/10.10.1.1:80 monitor status down followed quickly by an "up" status. This log provides the timestamp and the specific monitor that triggered the state change.
NEW QUESTION # 63
......
