質問 # 31
Refer to the exhibit.
DNS queries from two internal DNS servers are being load-balanced to external DNS servers via a virtual server on a BIG-IP device. The DNS queries originate from:
192.168.10.100
192.168.10.200
and target:
192.168.2.150
All DNS queries destined for the external DNS servers fail.
Which property change should the BIG-IP Administrator make in the Virtual Server to resolve this issue?
(Choose one answer)
正解：D
解説：
DNS traffic is primarily transported using UDP port 53. In the exhibit, the Virtual Server is configured with the Protocol set to TCP, which prevents standard DNS queries from being processed correctly. BIG-IP Virtual Servers must be configured with the correct Layer 4 protocol to match the application traffic they are handling.
According to the BIG-IP Administration: Data Plane Configuration documentation:
* The Protocol setting on a Virtual Server defines whether traffic is processed as TCP, UDP, or another supported transport protocol.
* Standard DNS queries and responses use UDP, while TCP is only required for DNS zone transfers (AXFR) or exceptionally large responses.
* When a DNS Virtual Server is incorrectly configured with TCP, UDP-based DNS queries are dropped, causing all requests to fail.
Why the other options are incorrect:
* A. Protocol profile (Client) to DNS_OPTIMIZEDA DNS profile enhances DNS functionality but does not correct an incorrect transport protocol configuration.
* B. Type to Performance (HTTP)Performance (HTTP) Virtual Servers are designed for HTTP traffic and are not suitable for DNS services.
* C. Source Address to 192.168.10.0/24The existing source IPs already fall within the allowed range, so this setting does not address the failure.
Correct Resolution:
Changing the Protocol to UDP aligns the Virtual Server with standard DNS transport requirements, allowing DNS queries to be successfully processed and load-balanced.
質問 # 32
A web server administrator informs the BIG-IP Administrator that web servers currently load-balanced require encrypted traffic. Starting next month, the web server administrator will offload SSL. Starting next month, the BIG-IP device will terminate SSL to reduce web server load. The BIG-IP device is already using Client SSL, Client port, and iRules on HTTP traffic. What actions should the BIG-IP Administrator take to achieve the desired configuration? (Choose one answer)
正解：A
解説：
To solve this requirement, we must distinguish between the two "legs" of an SSL connection in a BIG-IP environment: Client-side and Server-side.
* Current State (SSL Bridging): The administrator states the servers currently require encrypted traffic.
This means the BIG-IP is likely performing "SSL Bridging." In this setup, a Client SSL profile terminates encryption from the user, and a Server SSL profile re-encrypts the traffic before sending it to the back-end servers.
* Target State (SSL Offloading): The requirement is to "offload SSL" to reduce web server load. This means the BIG-IP will continue to handle the encryption for the users (keeping the Client SSL profile) but will communicate with the back-end servers using unencrypted HTTP.
Why Option A is correct:
* Remove the Server SSL profile: By removing this profile, the BIG-IP stops attempting to initiate an SSL
/TLS handshake with the pool members.
* Configure Pool Members to use HTTP: The service port for the pool members must be changed (typically from port 443 to port 80) so that the BIG-IP sends standard HTTP traffic to the servers.
Why other options are incorrect:
* B & D: These suggest removing the Client SSL profile. If you remove this, the users can no longer connect via HTTPS, which violates the requirement for encrypted communication between the users and the BIG-IP.
* C: Changing the Virtual Server to accept HTTP traffic would mean the user-to-BIG-IP connection is no longer encrypted, which is the opposite of SSL termination/offloading.
質問 # 33
In a pool there are 2 pool members (older servers) that can handle fewer connections than the other 3 newer servers.
Which load balancing method would allow more traffic to be directed to the newer servers? (Choose one answer)
正解：A
解説：
This scenario requires unequal load distribution based on server capacity. The newer servers must receive more connections than the older ones, while still dynamically accounting for active connection counts.
According to BIG-IP Administration: Data Plane Configuration documentation:
* Weighted Least Connections (member) combines:
* Connection awareness (least connections)
* Administrator-defined weights (ratios) to reflect server capacity
* Pool members with higher weights receive proportionally more new connections than members with lower weights, even when using the same load balancing algorithm.
Why B is correct:
* Allows assigning higher weights to newer servers and lower weights to older servers
* Ensures smarter traffic distribution based on both capacity and real-time load Why the other options are incorrect:
* A. Global AvailabilityUsed for disaster recovery and site failover, not intra-pool load distribution.
* C. Round RobinDistributes connections evenly without considering server capacity.
* D. Least Connections (member)Balances only by current connection count and does not account for differences in server performance or capacity.
Correct Resolution:
Use Weighted Least Connections (member) and assign higher weights to newer servers so they receive more traffic while protecting older servers from overload.
質問 # 34
A BIG-IP Administrator configures a node with a standard icmp Health Monitor. The Node shows as DOWN although the Backend Server is configured to answer ICMP requests. Which step should the administrator take next to find the root cause of this issue?
正解：C
解説：
In the F5 BIG-IP ecosystem, a standard ICMP health monitor functions by sending an ICMP echo request to a target node and expecting an ICMP echo reply within a specified timeout period. When a node is marked " DOWN " despite the backend server being configured to respond to ICMP, the issue typically lies in the network path or the specific packet exchange between the BIG-IP ' s self IP and the node ' s IP. Running a tcpdump is the most effective next step because it provides a real-time packet capture of the actual monitor traffic leaving the BIG-IP and any return traffic coming back from the server. This allows the administrator to verify if the BIG-IP is actually sending the echo request, if the request is reaching the server, and if the server is indeed replying or if the reply is being dropped by an intermediate firewall or a security policy.
While other tools have their place, they are inappropriate for this specific layer 3/4 connectivity issue. A qkview is a comprehensive diagnostic file used primarily for F5 Support to analyze the entire system ' s state but is overkill for initial connectivity troubleshooting. An ssldump is used for inspecting SSL/TLS handshakes and encrypted payloads, which is irrelevant for a non-encrypted ICMP monitor. A curl command is a tool for testing HTTP/HTTPS application-level responses; it cannot be used to troubleshoot ICMP (ping) connectivity directly. By using tcpdump -ni < vlan_name > host < node_ip > , the administrator can see the ICMP " type 8 " (request) and " type 0 " (reply) packets, immediately identifying if the monitor failure is due to a " Destination Unreachable " message or a simple lack of response, thereby pinpointing the root cause in the data plane.
質問 # 35
Users are unable to reach an application. The Virtual Server shows a red diamond status.
What is the cause?
正解：D
解説：
A red diamond indicates that the Virtual Server is enabled but unavailable, typically due to all pool members being down.
