NEW QUESTION # 110
Which interfaces on FortiSwitch send out FortiLink discovery frames by default in order to detect a FortiGate with an enabled FortiLink interface?
Answer: C
Explanation:
* Fortinet FortiLink Protocol:The FortiLink protocol is Fortinet's proprietary mechanism for managing FortiSwitch units from a FortiGate firewall. It simplifies configuration and security policy enforcement across the connected network devices.
* Auto-Discovery:FortiLink's auto-discovery feature means that by default, all ports on a FortiSwitch will actively send out discovery frames. This allows them to locate a FortiGate device that has a FortiLink interface enabled, streamlining the device management process.
* No Configuration Needed:You don't have to manually configure individual ports for FortiLink discovery on FortiSwitch devices.
References
* FortiSwitchOS FortiLink Guide (FortiSwitch Devices Managed by FortiOS 7.2):Refer to pages 13 and 14 for details on zero-touch management and FortiLink configuration. [https://fortinetweb.s3.
amazonaws.com/docs.fortinet.com/v2/attachments/27f63c72-b083-11ec-9fd1-fa163e15d75b
/FortiSwitchOS-7.2.0-FortiLink_Guide%E2%80%94FortiSwitch_Devices_Managed_by_FortiOS_7.2.
pdf]
NEW QUESTION # 111
Refer to the exhibit.
Port24 is the only uplink port connected to the network where you need access to FortiSwitch management services. However, FortiSwitch is not accessible on its management interface with IP address 10.0.13.3.
Based on the configuration shown in the exhibit, which two actions should you take to fix the issue and access FortiSwitch? (Choose two answers)
Answer: A,B
Explanation:
According to theFortiSwitchOS 7.6 Administration Guide (Page 320), management traffic on a FortiSwitch is associated with a specific logical interface, which in this case is the " internal " interface. The exhibit shows that the " internal " interface is configured onVLAN 4094(both as native and allowed). This means that for any management traffic (such as HTTPS, SSH, or SNMP) to reach the switch CPU, it must be able to traverse the physical uplink on VLAN 4094.
However, the configuration forport24(the uplink) is currently restricted. It is set withnative VLAN 100and an allowed-vlans list that only includes100 and 200. Because VLAN 4094 is not included in the allowed list of port24, all frames belonging to the management VLAN (4094) are dropped by the switch ' s ingress/egress filters on the uplink.
To resolve this and restore management access, the administrator has two valid configuration paths based on the provided options:
* Option B:Change thenative VLAN on port24 to VLAN 4094. By making 4094 the native VLAN, untagged management traffic can traverse the port, effectively allowing the " internal " interface to communicate with the network.
* Option D:Add VLAN 4094 to the allowed VLANs on port24. This ensures that VLAN 4094 is no longer filtered out, allowing management frames to pass through the uplink while maintaining the current native VLAN for other traffic.
Option C is irrelevant as removing a working VLAN (200) does not help the management traffic. While Option A describes an alternate architectural approach (moving management into an already-allowed VLAN), Options B and D represent the direct fixes for the mismatch described in the 7.6 administration documentation.
NEW QUESTION # 112
Refer to the exhibits.
Three FortiSwitch devices in standalone mode are interconnected. The CLI command diagnose stp instance list is executed on Core-2. Based on the output shown in the exhibit, what can you conclude about Core-2?
(Choose one answer)
Answer: D
Explanation:
According to theFortiSwitchOS 7.6 Administration Guideand theFortiSwitch 7.6 Study Guide, the output of the diagnose stp instance list command provides critical information about the Spanning Tree Protocol (STP) state of a switch within a given instance. In the provided exhibit, the output forInstance ID 0 (CST)onCore-
2shows several key indicators of its role and connectivity within the STP topology.
First, the output explicitly identifies aRootbridge with MAC address 02090f000701 and a priority of 4096.
Core-2 itself has a MAC address of 02090f000702 and a priority of 32768. Because Core-2 knows the MAC address and priority of the Root bridge, it must have received this information viaBridge Protocol Data Units (BPDUs). Furthermore, the port table shows thatport3on Core-2 has been assigned the role ofROOTand is in theFORWARDINGstate. In STP/RSTP, a Root Port is the port on a non-root switch that has the lowest path cost to the root bridge. To elect a Root Port and maintain its state, the switch must continuously receive BPDUs from the root bridge (or a bridge closer to the root) on that port.
Option B is incorrect because Core-2 has aRoot Port, which is only present on non-root bridges. Option C is incorrect because ports 1, 2, 4, 5, and the internal port are all in theFORWARDINGstate. Option D is incorrect as the output does not show any ports in anALTERNATErole; all active ports are either ROOT or DESIGNATED. Therefore, the most accurate conclusion is that Core-2 has successfully received BPDUs to identify the root and determine its own port roles.
NEW QUESTION # 113
To enhance service in emergency situations, to which LLDP-MED Type-Length-Values does Forti-Switch advertise to IP phones?
Answer: A
Explanation:
Location (C): FortiSwitch uses LLDP-MED (Link Layer Discovery Protocol - Media Endpoint Discovery) to advertise various attributes to IP phones, among which "Location" is crucial in emergency situations. This information helps emergency responders to determine the physical location of the calling device, which is vital for prompt response in critical situations.
NEW QUESTION # 114
Refer to the exhibit.
Which two configurations can you use for the FortiLink interface in a basic single FortiGate-single FortiSwitch topology? (Choose two.)
Answer: B,D
Explanation:
According to the FortiOS 7.6 Study Guide and the FortiSwitch 7.6 FortiLink Guide , when establishing a FortiLink connection between a standalone FortiGate unit and a single managed FortiSwitch unit, Fortinet supports two valid FortiLink interface architectures:
* Single Physical Port (Option A): In basic or entry-level deployments, FortiLink can be enabled directly on a dedicated individual physical interface of the FortiGate (such as a hardware port designated for FortiLink or any unassigned internal Ethernet port). Under this deployment mode, a single physical Ethernet or fiber cable connects the FortiGate physical port directly to the FortiSwitch discovery port.
* Link Aggregation Group (LAG) (Option D): Fortinet best-practice architecture recommends configuring the FortiLink interface as an 802.3ad aggregate interface (LAG). Even when connecting a single FortiGate to a single FortiSwitch, a LAG interface can bundle multiple physical links together to provide link redundancy, increased aggregate bandwidth, and seamless scalability for future link additions without disrupting the management tunnel.
Regarding the incorrect options:
* Option B (Port channel): " Port channel " is vendor-specific terminology primarily used in Cisco IOS
/NX-OS platforms. In Fortinet documentation and GUI/CLI commands, 802.3ad multi-link bundles are strictly defined and configured as 802.3ad aggregate or LAG interfaces.
* Option C (Switchport mode trunk): " Switchport mode trunk " is also Cisco syntax. Within Fortinet FortiOS and FortiSwitchOS environments, trunking and tagging behavior is defined by setting the Native VLAN and adding secondary subnets into the Allowed VLANs list on a physical or aggregate interface, rather than using Cisco switchport command modes.
NEW QUESTION # 115
......
