NEW QUESTION # 40
Refer to the exhibit.
DNS queries from two internal DNS servers are being load-balanced to external DNS servers via a virtual server on a BIG-IP device. The DNS queries originate from:
192.168.10.100
192.168.10.200
and target:
192.168.2.150
All DNS queries destined for the external DNS servers fail.
Which property change should the BIG-IP Administrator make in the Virtual Server to resolve this issue?
(Choose one answer)
Answer: D
Explanation:
DNS traffic is primarily transported using UDP port 53. In the exhibit, the Virtual Server is configured with the Protocol set to TCP, which prevents standard DNS queries from being processed correctly. BIG-IP Virtual Servers must be configured with the correct Layer 4 protocol to match the application traffic they are handling.
According to the BIG-IP Administration: Data Plane Configuration documentation:
* The Protocol setting on a Virtual Server defines whether traffic is processed as TCP, UDP, or another supported transport protocol.
* Standard DNS queries and responses use UDP, while TCP is only required for DNS zone transfers (AXFR) or exceptionally large responses.
* When a DNS Virtual Server is incorrectly configured with TCP, UDP-based DNS queries are dropped, causing all requests to fail.
Why the other options are incorrect:
* A. Protocol profile (Client) to DNS_OPTIMIZEDA DNS profile enhances DNS functionality but does not correct an incorrect transport protocol configuration.
* B. Type to Performance (HTTP)Performance (HTTP) Virtual Servers are designed for HTTP traffic and are not suitable for DNS services.
* C. Source Address to 192.168.10.0/24The existing source IPs already fall within the allowed range, so this setting does not address the failure.
Correct Resolution:
Changing the Protocol to UDP aligns the Virtual Server with standard DNS transport requirements, allowing DNS queries to be successfully processed and load-balanced.
NEW QUESTION # 41
A BIG-IP Administrator needs to configure health monitors for a pool containing HTTP, HTTPS, FTP, and SSH services.
Which configuration ensures accurate member status?
Answer: C
Explanation:
Using "at least one" ensures each member is marked up based on its relevant service monitor.
NEW QUESTION # 42
A BIG-IP Administrator creates a new Virtual Server. The end user is unable to access the page. During troubleshooting, the administrator learns that the connection between the BIG-IP system and server is NOT set up correctly. What should the administrator do to solve this issue? (Choose one answer)
Answer: A
Explanation:
The issue described is a classic symptom of asymmetric routing, which frequently occurs when the BIG-IP system and the back-end servers reside on the same subnet (often referred to as a "one-arm" deployment).
The Routing Problem: By default, the BIG-IP system preserves the original client source IP address when forwarding traffic to a pool member. If the server is in the same subnet as the client or if the server's default gateway is not the BIG-IP, the server will attempt to send its response directly back to the client's IP address, bypassing the BIG-IP.
Stateful Failure: Since the BIG-IP is a Full Proxy, it maintains a state table. Because the response packet never returns through the BIG-IP, the system cannot complete the three-way handshake or manage the application session, resulting in a connection failure for the user.
The Solution (SNAT): Enabling Source Network Address Translation (SNAT) solves this by changing the source IP address of the request to an IP address owned by the BIG-IP (typically a self-IP).
Requirement for Subnet Alignment: To ensure the server sends the response back to the BIG-IP, the translation address must be reachable. By using a self-IP configured in the same subnet as the servers, the BIG-IP ensures that the server sees the request coming from a local "neighbor." The server will then naturally send the response back to that self-IP, allowing the BIG-IP to translate the packet back and forward it to the client.
Why other options are incorrect:
A: Disabling address translation would ensure the server-side traffic uses the client IP, making asymmetric routing inevitable in this scenario.
B: This is technically contradictory; "Auto Map" specifically uses existing self-IPs and does not require or use a "SNAT pool" configuration.
C: While using a specific translation address can work, it does not inherently guarantee the Layer 2/Layer 3 reachability mentioned in the scenario as effectively as ensuring the self-IP is correctly placed in the server's subnet.
NEW QUESTION # 43
How can a BIG-IP Administrator identify a configuration object that has been configured within an iApp?
Answer: C
Explanation:
In F5 BIG-IP systems, an iApp is a template-driven framework used to deploy and manage application- specific configurations. When an iApp is deployed, the system creates a specialized folder or " Application Service " container to hold all the resulting Local Traffic Manager (LTM) objects, such as virtual servers, pools, and profiles. This container is visually and programmatically identified by the .app extension in its path name.
The naming convention for these objects follows a specific hierarchical structure: / < partition > / < iapp_name > .app/ < object_name > . For example, if an administrator creates an iApp named " testhttp " in the " /Common " partition, the virtual server created by that iApp would be identified in the configuration (TMSH) and the GUI as /Common/testhttp.app/testhttp. This structure allows the BIG-IP system to distinguish between manually created objects and those managed by the iApp ' s automation logic.
This identification is crucial because iApp-managed objects typically have Strict Updates enabled, which prevents administrators from making direct manual changes to the object settings outside of the iApp ' s reconfigure interface. Attempting to modify such an object directly will result in an error message stating that the application service must be updated using an application management interface. By recognizing the .app path and the repeated name within the structure, an administrator can immediately identify that the object belongs to an iApp and should be managed through the iApp ' s specific management screen rather than standard LTM configuration menus.
NEW QUESTION # 44
To increase available bandwidth of an existing Trunk, the BIG-IP Administrator is adding additional interfaces. Which command should the BIG-IP Administrator run from within the bash shell?
Answer: A
Explanation:
This question tests precise knowledge of both TMSH command syntax and BIG-IP object namespace hierarchy . Two critical distinctions must be correctly identified:
1. create vs. modify: Since the Trunk already exists and the administrator is adding interfaces to it, the correct verb is modify - not create . Using create on an existing object would either throw an error or attempt to overwrite the object entirely, neither of which is the desired outcome.
2. /sys vs. /net namespace: Trunk objects in BIG-IP reside within the /net namespace, which encompasses network-layer constructs including Trunks, VLANs, Self IPs, and Routes. The /sys namespace is reserved for system-level objects such as management settings, software, and licensing - it does not contain Trunk objects.
Therefore, the only syntactically and functionally correct command is:
tmsh modify /net trunk trunk_A interfaces add {1.3 1.4}
This command appends interfaces 1.3 and 1.4 to the existing trunk_A object without disrupting currently assigned interfaces, increasing aggregated bandwidth accordingly.
Options A and C use the incorrect /sys namespace, and options A and B incorrectly use the create verb for an existing object.
Reference: BIG-IP Administration - Data Plane Configuration, Module: TMSH Command Syntax - Network Object Management.
NEW QUESTION # 45
......
