| Section | Objectives |
|---|---|
| BIG-IP System Architecture | - Traffic processing pipeline (data plane vs control plane)
|
| Application Delivery Concepts | - Session persistence
|
| Traffic Policies and iRules | - iRules fundamentals
|
| Load Balancing and Traffic Management | - Health monitoring
|
| NAT and Address Translation | - SNAT and NAT concepts
|
KoreaDumps의 F5 F5CAB2덤프로F5 F5CAB2시험준비를 하면 시험패스는 간단한 일이라는걸 알게 될것입니다. F5 F5CAB2덤프는 최근F5 F5CAB2시험의 기출문제모음으로 되어있기에 적중율이 높습니다.시험에서 떨어지면 덤프비용 전액 환불해드리기에 우려없이 덤프를 주문하셔도 됩니다.
질문 # 56
Active connections to pool members are unevenly distributed. The load balancing method is Least Connections (member). Priority Group Activation is disabled.
What is a potential cause of the uneven distribution? (Choose one answer)
정답：A
설명：
Comprehensive and Detailed Explanation (BIG-IP Administration - Data Plane Concepts):
With Least Connections (member), BIG-IP attempts to send new connections to the pool member with the fewest current connections. In a perfectly "stateless" scenario (no affinity), this often trends toward a fairly even distribution over time.
However, persistence overrides load balancing:
When a persistence profile is applied, BIG-IP will continue sending a client (or client group) to the same pool member based on the persistence record (cookie / source address / SSL session ID, etc.).
This means even if another pool member has fewer connections, BIG-IP may still select the persisted member to honor session affinity.
The result can be uneven active connection counts, even though the configured load balancing method is Least Connections.
Why the other options are not the best cause:
A . Priority Group Activation is disabled
Priority Group Activation only affects selection when priority groups are configured; disabling it does not inherently create uneven distribution under Least Connections.
B . SSL Profile Server is applied
A server-side SSL profile affects encryption to pool members, but it does not by itself cause skewed selection across pool members. (Skew could happen indirectly if members have different performance/latency, but that's not the primary, expected exam answer.) D . Incorrect load balancing method Least Connections is a valid method and does not itself explain unevenness unless something is overriding it (like persistence) or pool members are not all eligible.
Conclusion:
A persistence profile is the most common and expected reason that active connections become unevenly distributed, because persistence takes precedence over the Least Connections load-balancing decision.
질문 # 57
Refer to the exhibit.
The network team creates a new VLAN on the switches. The BIG-IP Administrator creates a new VLAN and a Self IP on the BIG-IP device, but the servers on the new VLAN are NOT reachable from the BIG-IP device.
Which action should the BIG-IP Administrator take to resolve this issue? (Choose one answer)
정답：B
설명：
For BIG-IP to send or receive traffic on a VLAN, that VLAN must be bound to a physical interface or a trunk. Creating a VLAN object and a Self IP alone is not sufficient to establish data-plane connectivity.
From the exhibit:
* The VLAN (vlan_1033) exists and has a tag defined.
* A Self IP is configured and associated with the VLAN.
* However, traffic cannot reach servers on that VLAN.
This indicates a Layer 2 connectivity issue, not a Layer 3 or HA issue.
Why assigning a physical interface fixes the problem:
* BIG-IP VLANs do not carry traffic unless they are explicitly attached to:
* A physical interface (e.g., 1.1), or
* A trunk
* Without an interface assignment, the VLAN is effectively isolated and cannot transmit or receive frames, making servers unreachable regardless of correct IP addressing.
Why the other options are incorrect:
* A. Set Port Lockdown to Allow AllPort Lockdown controls which services can be accessed on the Self IP (management-plane access), not whether BIG-IP can reach servers on that VLAN.
* B. Change Auto Last Hop to enabledAuto Last Hop affects return traffic routing for asymmetric paths. It does not fix missing Layer 2 connectivity.
* D. Create a Floating Self IP addressFloating Self IPs are used for HA failover. They do not resolve reachability issues on a single device when the VLAN itself is not connected to an interface.
Conclusion:
The servers are unreachable because the VLAN has no physical interface assigned. To restore connectivity, the BIG-IP Administrator must assign a physical interface (or trunk) to the VLAN, enabling Layer 2 traffic flow.
질문 # 58
What is the result when a BIG-IP Administrator manually disables a pool member? (Choose one answer)
정답：C
설명：
In BIG-IP LTM, a pool member state directly affects how traffic is handled at the data plane level. When a pool member is manually disabled, BIG-IP changes the member's availability state to disabled, which has specific and predictable traffic-handling consequences.
According to BIG-IP Administration Data Plane Concepts:
A disabled pool member:
Does not accept new connections
Continues to process existing non-persistent connections until they naturally close Is removed from load-balancing decisions, including persistence lookups Most importantly for this Questio n:
Persistent connections
(such as those created using source-address persistence, cookie persistence, or SSL persistence) are not honored for a disabled pool member BIG-IP will not send new persistent traffic to a disabled member, even if persistence records exist Therefore, when a pool member is manually disabled, it stops processing persistent connections, while allowing existing non-persistent flows to drain gracefully.
Why the Other Options Are Incorrect:
B - Persistent connections are not honored for a disabled pool member
C - Existing connections are not immediately terminated when a pool member is disabled D - Only the disabled pool member stops accepting new connections, not all pool members Key Data Plane Concept Reinforced:
Manually disabling a pool member is a graceful administrative action that prevents new and persistent traffic from reaching the member while allowing existing connections to complete, which is critical for maintenance and troubleshooting scenarios.
질문 # 59
A BIG-IP Administrator is making adjustments to an iRule and needs to identify which of the 235 Virtual Servers configured on the BIG-IP device will be affected. How should the administrator obtain this information in an efficient way?
정답：A
설명：
When managing a large environment with hundreds of Virtual Servers, the most efficient way to identify the relationship between an iRule and the objects it manages is to view the properties of the iRule itself.
* iRule Properties:Within the BIG-IP Configuration Utility, navigating toLocal Traffic > iRulesand selecting a specific iRule provides a "Statistics" or "Usage" tab (depending on the version). This view explicitly lists all Virtual Servers currently associated with that specific iRule.
* Centralized Management:Instead of manually checking 235 individual Virtual Servers under the
"Virtual Servers" menu, the iRules menu acts as a central point of reference for that specific logic.
* Data Plane Impact:Because iRules can modify traffic flow, headers, and load balancing decisions, seeing the full list of affected Virtual Servers is critical before making adjustments to avoid unintended side effects across the application portfolio.
질문 # 60
Refer to the exhibit.
During a planned upgrade to a BIG-IP HA pair running Active/Standby, an outage to application traffic is reported shortly after the Active unit is forced to Standby. Reverting the failover resolves the outage. What should the BIG-IP Administrator modify to avoid an outage during the next failover event? (Choose one answer)
정답：A
설명：
In an Active/Standby BIG-IP design, application availability during failover depends on both units having equivalent data-plane connectivity for the networks that carry application traffic. Specifically:
VLANs are bound to specific interfaces (and optionally VLAN tags).
Floating self IPs / traffic groups move to the new Active device during failover.
For traffic to continue flowing after failover, the new Active device must have the same VLANs available on the correct interfaces that connect to the upstream/downstream networks.
What the symptom tells you:
Traffic works when Device A is Active
Traffic fails when Device B becomes Active
Failback immediately restores traffic
This pattern strongly indicates the Standby unit does not have the VLAN connected the same way (wrong physical interface assignment), so when it becomes Active, it owns the floating addresses but cannot actually pass traffic on the correct network segment.
Why Interface mismatch is the best match:
If the Active unit is already working, its interface mapping is correct.
The fix is to make the Standby unit's VLAN/interface assignment match the Active unit.
That corresponds to changing the Standby device interface to 1.1.
Why the Tag options are less likely here (given the choices and the exhibit intent):
Tag issues can also break failover traffic, but the question/options are clearly driving toward the classic HA requirement: consistent VLAN-to-interface mapping on both devices so the data plane remains functional after the traffic group moves.
Conclusion: To avoid an outage on the next failover, the BIG-IP Administrator must ensure the Standby device uses the same interface (1.1) for the relevant VLAN(s) that carry the application traffic, so when it becomes Active it can forward/receive traffic normally.
