| Section | Weight | Objectives |
|---|---|---|
| Mobility Design | 25% | - Roaming optimization
|
| Wireless Site Survey | 25% | - RF propagation and attenuation analysis - Design requirements collection and constraint evaluation
- Pre-deployment survey and validation |
| Wireless Infrastructure Design | 30% | - Wired-wireless integration design
|
| WLAN High Availability and Security Design | 20% | - Security architecture design
|
>> Reliable 300-110 Test Braindumps <<
With these two Designing Cisco Wireless Networks 300-110 practice exams, you will get the actual Cisco 300-110 exam environment. Whereas the DumpsFree PDF file is ideal for restriction-free test preparation. You can open this PDF file and revise 300-110 Real Exam Questions at any time. Choose the right format of Designing Cisco Wireless Networks 300-110 actual questions and start Cisco 300-110 preparation today.
NEW QUESTION # 42
A customer has two Cisco Catalyst 9800 Series WLCs named WLC-A and WLC-B in an N+1 configuration with the same WLANs but different Layer 3 interfaces for each WLC, and APs in local mode. WLC-A manages Building A APs and WLC-B manages Building B APs. The customer wants users to remain connected and retain their session state including the IP address when moving between buildings. How must this requirement be incorporated into the design?
Answer: D
Explanation:
The requirement for users to retain their session state and IP address when roaming between buildings managed by different WLCs is a Layer 3 roaming scenario. In Cisco ' s wireless architecture, IP address preservation across controller boundaries is achieved through inter-controller mobility - specifically the foreign-anchor mobility tunnel mechanism. When a client roams from Building A (WLC-A) to Building B (WLC-B), WLC-B becomes the foreign controller and WLC-A becomes the anchor controller. WLC-B tunnels the client ' s traffic back to WLC-A, allowing the client to retain its original IP address even while physically associated to an AP managed by WLC-B. This requires a mobility tunnel between WLC-A and WLC-B with both controllers configured in the same mobility group name - the group name is the trust identifier that permits the mobility tunnel and anchor-foreign relationship to form. Without the same group name, the controllers will not form a trusted mobility peer relationship. AP groups (Option C) control SSID and VLAN assignments per AP cluster but have no impact on inter-controller roaming. HA cluster configuration (Option B) creates SSO redundancy, not roaming capability between separate N+1 controllers.
Redundancy port connection (Option D) is used for SSO keepalive and state sync, not mobility tunneling.
Reference: WLSD Study Guide - Inter-Controller Mobility, Mobility Tunnels, Layer 3 Roaming and IP Address Preservation.
NEW QUESTION # 43
Refer to the exhibit. A wireless engineer is using the Ekahau Site Survey tool to conduct a post- deployment survey. The engineer analyzes the pictured output to determine if SNR meets the voice requirements. How is the voice support based on the output?
Ekahau SNR Heatmap -- Post-Deployment Survey Output
Answer: C
Explanation:
Voice over WLAN (VoWLAN) deployments require a minimum SNR threshold to maintain acceptable Mean Opinion Score (MOS) values for call quality. Cisco's 300-110 WLSD curriculum specifies that VoWLAN requires a minimum SNR of 25 dB throughout the coverage area. In an Ekahau post- deployment survey SNR heatmap, when the heatmap displays a consistent color indicating SNR at or above this threshold across the entire surveyed area -- including all rooms, corridors, and common areas such as the lobby -- the conclusion is that voice service is supported in all locations. The color coding in Ekahau's SNR heatmap uses green tones to indicate adequate SNR (typically 25 dB) and shifts toward yellow and red for degraded conditions. When the exhibit heatmap shows uniform adequate coverage across all surveyed areas without yellow or red zones, it confirms the SNR requirement for VoWLAN is universally met.
NEW QUESTION # 44
An engineer is designing a wireless network in a historic building that has large rooms and ornate wall coverings. Which approach must be considered first when placing access points?
Answer: C
Explanation:
When designing a wireless network for any environment, including a historic building with ornate wall coverings and aesthetic constraints, RF coverage must always be considered first when placing access points.
RF coverage is the fundamental requirement - without adequate signal strength throughout the space, no other design objective can be met. The engineer must first determine AP locations that provide the required signal strength and coverage to all areas before addressing aesthetics, overlap calculations, or interference mitigation. In a historic building specifically, the ornate wall coverings and dense construction materials may cause unexpected signal attenuation, making it even more important to model RF coverage before committing to AP positions. Once RF coverage requirements are established, aesthetic concerns (Option A) can guide the choice of AP form factor, enclosures, or cabling routes. Cell overlap (Option C) is derived from coverage calculations. RF interference (Option D) analysis follows after RF coverage baseline is established.
Reference: WLSD Study Guide - Site Survey Methodology, AP Placement Priority, Special Environment Wireless Design.
NEW QUESTION # 45
An engineer is performing a passive survey report. The coverage heat map shows the entire site with all signal levels. To see only the desired coverage, which action must the engineer take?
Answer: C
Explanation:
To focus the coverage heat map on the desired coverage threshold, the engineer should use the RSSI slider to set the heat map to the desired cutoff filter. This action adjusts the display to show only the signal levels that meet or exceed the specified RSSI value, effectively filtering out weaker signals and highlighting areas with sufficient coverage. In Ekahau and similar survey tools, the RSSI slider provides a dynamic way to set minimum signal thresholds, allowing the engineer to quickly validate whether coverage meets design targets such as -67 dBm for voice or -70 dBm for data. Changing the color scheme (Option A) only modifies the visual representation without filtering data. The RSSI calibration tool (Option B) adjusts how the tool perceives signal levels, not the display filter. Filtering by AP (Option D) would remove APs from the view, potentially hiding coverage gaps. Reference: WLSD Study Guide - Post-Deployment Survey, Ekahau Heat Map Tools, RSSI Coverage Filtering.
NEW QUESTION # 46
An engineer in a branch office that does not have a wired backhaul must ensure that local clients can be switched locally and authenticated centrally. In which mode must the AP be configured?
Answer: C
Explanation:
Flex+Bridge mode is a specialized AP operating mode that combines two distinct Cisco wireless capabilities: FlexConnect (for local switching of client data traffic and central authentication via the WLC) and Bridge/Mesh mode (enabling wireless backhaul when no wired Ethernet uplink is available). In a branch environment without wired backhaul, a standard FlexConnect AP (Option D) cannot operate because FlexConnect still requires an Ethernet connection for its control plane.
Bridge mode alone provides mesh backhaul but does not support the local switching with central authentication model required here. MAP (Option A) is a Mesh Access Point role for wireless backhaul, and RAP (Option C) is a Root Access Point with a wired connection -- neither meets the no-wired-backhaul requirement with local switching. Flex+Bridge uniquely satisfies both requirements: the Flex component allows locally switched VLANs to be bridged directly to the access layer without traversing the WAN, while the Bridge component enables the AP to use a wireless mesh link for its backhaul uplink. Central authentication is maintained via the CAPWAP control tunnel over the mesh link.
NEW QUESTION # 47
......
