きみはJuniperのJN0-352認定テストに合格するためにたくさんのルートを選択肢があります。JPNTestは君のために良い訓練ツールを提供し、君のJuniper認証試に高品質の参考資料を提供しいたします。あなたの全部な需要を満たすためにいつも頑張ります。
| Section | Weight | Objectives |
|---|---|---|
| BGP | 15-20% | - Neighbor relationships and session establishment - Route advertisement, attributes and path selection - Routing policies, filtering and common troubleshooting |
| Tunnels and Overlays | 5-10% | - GRE, IP-IP and dynamic tunnel configuration - Overlay network design and connectivity - Tunnel types, encapsulation and operation |
| Layer 2 Security | 10-15% | - DHCP snooping, Dynamic ARP Inspection and IP Source Guard - Port security, MAC limiting and storm control - Layer 2 firewall filters and security features |
| IS-IS | 10-15% | - Adjacency establishment, levels and metrics - Scalable enterprise deployment and troubleshooting - Configuration and route exchange |
| Protocol Independent Routing | 10-15% | - Routing tables, static routes and route preference - Routing instances and route selection criteria - Basic routing policy and filter operation |
| OSPF | 15-20% | - Neighbor formation, area design and LSA types - Route summarization and redistribution - Configuration, verification and troubleshooting |
| Layer 2 Switching and VLANs | 15-20% | - Spanning Tree Protocol (STP, RSTP, MSTP) operation and configuration - VLAN concepts, configuration, trunking and tagging - Link Aggregation Groups (LAG) and Virtual Chassis |
| High Availability and Resiliency | 5-10% | - Redundancy protocols and failover mechanisms - Graceful restart and non-stop routing - Network resiliency design and troubleshooting |
| IP Multicast | 5-10% | - IGMP operation and configuration - Multicast routing monitoring and troubleshooting - PIM Dense Mode, Sparse Mode and RP mechanisms |
JuniperのJN0-352の認定試験に合格すれば、就職機会が多くなります。この試験に合格すれば君の専門知識がとても強いを証明し得ます。JuniperのJN0-352の認定試験は君の実力を考察するテストでございます。
質問 # 26
Your company has a branch location that uses a Juniper Networks EX Series Switch. You are asked to troubleshoot a spanning-tree issue that keeps reoccurring within the branch environment. After investigation, you discover that end-devices running a virtualization application are generating BPDUs, which are disrupting the spanning-tree topology and causing periodic outages.
Which solution will prevent this problem from reoccurring?
正解：C
解説：
This scenario describes end hosts - virtualization hosts running software switches or virtual bridging stacks
- unexpectedly generating and transmitting BPDUs on ports that are supposed to be pure edge (host-facing) ports where no BPDUs should ever legitimately be received. BPDU protection (BPDU guard) is the Junos feature purpose-built for exactly this situation: when applied to an edge-designated interface, it continuously monitors that port for any incoming BPDU, and the moment one is detected, it immediately and automatically disables the port, preventing the unexpected BPDU source from ever participating in or influencing the spanning-tree topology calculation, thereby protecting the stable, intended topology from disruption caused by unauthorized or accidental BPDU generation at the access edge. This directly and precisely resolves the described problem at its source, since the root cause is illegitimate BPDUs arriving on ports that were never meant to see them. Increasing the max-age timer only adjusts how long stale topology information is retained before being aged out and has no effect on preventing rogue BPDUs from being processed in the first place.
Disabling RSTP outright on access interfaces would eliminate spanning tree's loop-prevention protection on those ports entirely, introducing a much more severe risk of undetected Layer 2 loops. Root protection (root guard) defends specifically against a port attempting to become the root port by receiving a superior BPDU claiming a better path to root; it addresses a different threat model than blocking any BPDU outright on a true edge port. Reference topics: Junos Enterprise Switching - Spanning Tree Protocols, BPDU Protection on Edge Interfaces.
質問 # 27
What are three well-known mandatory BGP attributes? (Choose three.)
正解：A、D、E
質問 # 28
Which two statements describe NSR? (Choose two.)
正解：A、C
質問 # 29
Click the Exhibit button. You are asked to ensure that there will not be any unwanted STP topology changes affecting your root bridge placement because a rogue switch was introduced into the network at the access layer. Referring to the exhibit, which interfaces will need to have root protection applied to accomplish this task?
正解：D
解説：
Root protection (root guard) must always be applied on the ports of the switches you trust to remain root-bridge-eligible, specifically on the interfaces facing away from the legitimate root and toward parts of the network where an untrusted or rogue device could plausibly appear and begin transmitting superior BPDUs. In this topology, Switch-1 is the intended, permanent root bridge (lowest priority, 4k), and Switch-2 is its aggregation-layer peer; both sit above the access layer, where Switch-3 and Switch-4 connect downstream toward end-user-facing infrastructure and where an accidental or malicious rogue switch is realistically most likely to be introduced. The ge-
0/0/6 and ge- 0/0/8 interfaces on Switch-1 and Switch-2 are precisely the downlink ports facing that access layer, meaning they are the exact points at which a rogue switch's superior BPDU (one advertising a lower priority than the legitimate root) would first be received if such a device appeared beneath Switch-3 or Switch-4. Applying root protection on those specific interfaces causes Junos to immediately block (move to a root-inconsistent, discarding state) any port that receives a superior BPDU, preventing the rogue device from ever being accepted as root, while normal, non-superior BPDUs continue to be processed without disruption. Applying root guard on Switch-1 and Switch-2's peer link (ge- 0/0/12/13) would be inappropriate, since that link legitimately connects two trusted, root-eligible switches.
質問 # 30
You want to redistribute the static routes into BGP, but they do not show as BGP routes.
What causes this result to occur?
正解：C
質問 # 31
......
