NEW QUESTION # 47
Refer to the exhibit.
A user with IP address 192.168.162.70 is unable to connect to an HTTP application. What is a possible cause within the Virtual Server configuration?
Answer: D
Explanation:
The failure to connect is caused by a restrictive Source Address filter configured on the Virtual Server.
Source Address Filtering: In the BIG-IP system, the Source Address field on a Virtual Server acts as an implicit Access Control List (ACL). Only traffic originating from a client IP address that matches the specified network range will be accepted and processed by the Virtual Server.
Analyzing the Exhibit: The provided configuration for vs_http shows the Source Address is set to 10.128.10.0/24. This means the Virtual Server will only accept connections from the subnet ranging from 10.128.10.1 to 10.128.10.254.
Identifying the Conflict: The user trying to connect has the IP address 192.168.162.70. Since 192.168.162.70 does not fall within the allowed 10.128.10.0/24 range, the BIG-IP system will not match this traffic to the Virtual Server, effectively blocking the connection attempt.
Evaluation of Other Options:
All Ports (Option A): Configuring a Virtual Server for "All Ports" (port 0) allows it to handle traffic for any destination port, which would not block a standard HTTP application.
Destination Address (Option B): The destination address 192.168.162.80 is the Virtual IP (VIP) users should be connecting to; this is a standard configuration and not the cause of the failure for a user reaching out to it.
Standard Type (Option C): A "Standard" Virtual Server is the most common type used for HTTP applications as it allows for Layer 7 profiles and full proxy capabilities.
NEW QUESTION # 48
A gateway_icmp health monitor is configured on a pool. The BIG-IP Administrator is investigating why the pool is reported as down while the server is online. Other pools with servers in the same subnet are correctly monitored.
What can cause this behavior? (Choose one answer)
Answer: D
Explanation:
A gateway_icmp monitor checks basic network reachability by sending ICMP echo requests (pings) to the pool member or its gateway. If the pool is marked DOWN while the server is confirmed to be online, the most likely cause is that ICMP traffic is being blocked.
A host-based firewall active on the server (Option C) can block ICMP echo requests or replies, preventing BIG-IP from receiving a successful response to the health check. This results in the monitor failing and the pool member being marked down, even though the server and application are otherwise functioning normally. This explanation is consistent with the scenario where other servers in the same subnet work correctly, indicating that routing and BIG-IP configuration are not the issue.
The other options are unrelated to ICMP monitoring. Logged-in users (Option A), missing patches (Option B), and stopped HTTP services (Option D) do not affect a gateway_icmp monitor. BIG-IP troubleshooting best practices recommend verifying ICMP reachability and firewall policies when diagnosing ICMP-based monitor failures.
NEW QUESTION # 49
A BIG-IP Administrator needs to determine why only one pool member is showing connections from the virtual server, resulting in uneven load balancing. What two reasons would cause uneven load balancing? (Choose two answers)
Answer: B,D
Explanation:
Uneven load balancing on a BIG-IP system typically occurs when traffic is not distributed evenly across all available pool members. One common reason is thatmonitors have marked down multiple pool members (Option B). When health monitors fail for specific pool members, BIG-IP automatically removes those members from load-balancing decisions. As a result, traffic is sent only to the remaining healthy member, creating the appearance that load balancing is not functioning correctly.
This behavior is expected and aligns with BIG-IP's design to ensure traffic is sent only to healthy resources.
Another frequent cause isthe presence of a persistence profile on the pool or virtual server (Option C). Persistence (such as source address or cookie persistence) forces subsequent client connections to be sent to the same pool member for session continuity. While persistence is critical for certain applications, it can override the load-balancing algorithm and cause most or all traffic to be directed to a single pool member, especially during low traffic volumes or testing scenarios.
NEW QUESTION # 50
A pool member is exhibiting frequent up-and-down state changes, leading the BIG-IP Administrator to suspect a health monitor issue. Which specific log file should the BIG-IP Administrator review to diagnose the problem?
Answer: C
Explanation:
The Local Traffic Manager (LTM) log file is the primary repository for all events related to load balancing objects, including virtual servers, pools, and nodes.
* Monitor Logging: When a health monitor marks a pool member as "UP" or "DOWN," the system generates a log entry in /var/log/ltm.
* Diagnosing Flaps: To troubleshoot "flapping" (frequent state changes), an administrator would look for messages like 01010028:3: Pool /Common/http_pool member /Common/10.10.1.1:80 monitor status down followed quickly by an "up" status. This log provides the timestamp and the specific monitor that triggered the state change.
NEW QUESTION # 51
A BIG-IP Administrator uses backend servers to host multiple services per server. There are multiple virtual servers and pools defined, referencing the same backend servers. Which load balancing algorithm is most appropriate to have an equal number of connections on each backend server?17
Answer: B
Explanation:
Comprehensive and Detailed Explanation From BIG-IP Administration Support and Troubleshooting documents: When load balancing is not working as 23expected and connections appear skewed across physical hardware, the administrator must distinguish between "member"24 and "node" level balancing. A
"member" refers to a specific IP and Port combination (e.g., 10.1.1.1:80), whereas a "node" refers to the underlying IP address (10.1.1.1) regardless of the port25. If a single server hosts multiple services (Web, FTP, API) across different pools, using "Least Connections (member)" would only balance connections within each individual pool26. This could lead to a scenario where one server is overwhelmed because it is winning the
"least connections" count in three different pools simultaneously. By selecting "Least Connections (node)," the BIG-IP tracks the total number of concurrent connections to the physical IP address across all pools it belongs to27. This ensures that the administrator can maintain an equal distribution of work across the hardware, preventing performance degradation on backend servers that host multiple application services.
