NEW QUESTION # 64
A BIG-IP Administrator creates a new Virtual Server. The end user is unable to access the page. During troubleshooting, the administrator learns that the connection between the BIG-IP system and server is NOT set up correctly. What should the administrator do to solve this issue? (Choose one answer)
Answer: C
Explanation:
The issue described is a classic symptom of asymmetric routing, which frequently occurs when the BIG-IP system and the back-end servers reside on the same subnet (often referred to as a "one-arm" deployment).
* The Routing Problem: By default, the BIG-IP system preserves the original client source IP address when forwarding traffic to a pool member. If the server is in the same subnet as the client or if the server's default gateway is not the BIG-IP, the server will attempt to send its response directly back to the client's IP address, bypassing the BIG-IP.
* Stateful Failure: Since the BIG-IP is a Full Proxy, it maintains a state table. Because the response packet never returns through the BIG-IP, the system cannot complete the three-way handshake or manage the application session, resulting in a connection failure for the user.
* The Solution (SNAT): Enabling Source Network Address Translation (SNAT) solves this by changing the source IP address of the request to an IP address owned by the BIG-IP (typically a self-IP).
* Requirement for Subnet Alignment: To ensure the server sends the response back to the BIG-IP, the translation address must be reachable. By using a self-IP configured in the same subnet as the servers, the BIG-IP ensures that the server sees the request coming from a local "neighbor." The server will then naturally send the response back to that self-IP, allowing the BIG-IP to translate the packet back and forward it to the client.
Why other options are incorrect:
* A: Disabling address translation would ensure the server-side traffic uses the client IP, making asymmetric routing inevitable in this scenario.
* B: This is technically contradictory; "Auto Map" specifically uses existing self-IPs and does not require or use a "SNAT pool" configuration.
* C: While using a specific translation address can work, it does not inherently guarantee the Layer 2
/Layer 3 reachability mentioned in the scenario as effectively as ensuring the self-IP is correctly placed in the server's subnet.
NEW QUESTION # 65
Refer to the exhibit.
DNS queries from two internal DNS servers are being load-balanced to external DNS servers via a virtual server on a BIG-IP device. The DNS queries originate from:
192.168.10.100
192.168.10.200
and target:
192.168.2.150
All DNS queries destined for the external DNS servers fail.
Which property change should the BIG-IP Administrator make in the Virtual Server to resolve this issue?
(Choose one answer)
Answer: C
Explanation:
DNS traffic is primarily transported using UDP port 53. In the exhibit, the Virtual Server is configured with the Protocol set to TCP, which prevents standard DNS queries from being processed correctly. BIG-IP Virtual Servers must be configured with the correct Layer 4 protocol to match the application traffic they are handling.
According to the BIG-IP Administration: Data Plane Configuration documentation:
The Protocol setting on a Virtual Server defines whether traffic is processed as TCP, UDP, or another supported transport protocol.
Standard DNS queries and responses use UDP, while TCP is only required for DNS zone transfers (AXFR) or exceptionally large responses.
When a DNS Virtual Server is incorrectly configured with TCP, UDP-based DNS queries are dropped, causing all requests to fail.
Why the other options are incorrect:
A). Protocol profile (Client) to DNS_OPTIMIZEDA DNS profile enhances DNS functionality but does not correct an incorrect transport protocol configuration.
B). Type to Performance (HTTP)Performance (HTTP) Virtual Servers are designed for HTTP traffic and are not suitable for DNS services.
C). Source Address to 192.168.10.0/24The existing source IPs already fall within the allowed range, so this setting does not address the failure.
Correct Resolution:
Changing the Protocol to UDP aligns the Virtual Server with standard DNS transport requirements, allowing DNS queries to be successfully processed and load-balanced.
NEW QUESTION # 66
Application administrators are reporting that nodes different from those configured in the pool are selected.
The use of an iRule is suspected. How can the BIG-IP Administrator check if an iRule is used for this traffic?
(Pick the 2 correct responses below)
Answer: A,C
NEW QUESTION # 67
Application administrators are reporting that nodes different from those configured in the pool are selected. The use of an iRule is suspected.
How can the BIG-IP Administrator check if an iRule is used for this traffic? (Choose two answers)
Answer: C,D
Explanation:
In BIG-IP systems, iRules influence traffic only when they are attached to a Virtual Server. If application traffic is being sent to nodes or pool members that are not defined in the pool, this typically indicates that an iRule is overriding the default load-balancing behavior by explicitly selecting a pool or node.
According to BIG-IP Administration: Data Plane Configuration and official F5 guidance:
iRules are associated with Virtual Servers, not directly with pools or nodes.
To determine whether an iRule is actively affecting traffic, the administrator must inspect the Virtual Server configuration.
Explanation of the correct answers:
B . Via the GUI at the Resources tab for the virtual server
The Resources tab in the Configuration Utility displays all traffic-handling objects applied to the Virtual Server, including assigned iRules. This is the primary GUI location to verify whether an iRule is influencing data plane traffic.
C . Via TMSH with the list /ltm virtual <virtual_server> command
This TMSH command displays the full Virtual Server configuration, including any iRules listed under the rules section. It is the authoritative CLI method to confirm iRule usage.
Why the other options are incorrect:
A . Via TMSH with the list /ltm rule <irule> command
This command only shows the contents of an iRule and does not indicate whether the iRule is attached to or used by any Virtual Server.
D . Via the GUI at the iRule tab for the virtual server
BIG-IP does not provide a dedicated "iRule" tab on Virtual Servers. iRules are viewed and managed under the Resources tab.
Correct Conclusion:
To verify whether an iRule is responsible for unexpected node selection, the BIG-IP Administrator must examine the Virtual Server configuration, either through the Resources tab in the GUI or by using TMSH to list the Virtual Server configuration.
NEW QUESTION # 68
Local Traffic Network Map: VS_HTTP # POOL_WEB # 192.168.212.30:80 Pool Member | Parent Node
192.168.212.30 Port 80
Why is the virtual server unresponsive to incoming connections?
Answer: D
Explanation:
In the BIG-IP object hierarchy, a Pool Member is a child object of a Node . A pool member represents a specific IP:Port combination, while the parent node represents the underlying server IP address. When a node is disabled , all pool members that are children of that node are rendered unavailable - regardless of the individual pool member ' s own health or enabled state.
The Network Map depicted shows the pool member (192.168.212.30:80) with its Parent Node (192.168.212.30) disabled. This parent-child dependency means that even if the pool member itself is healthy and enabled, the disabled node cascades its unavailable state downward, causing the pool to have no available members and rendering VS_HTTP unresponsive to incoming connections.
The other options can be eliminated as follows:
* Pool member monitor failed - the monitor status is not indicated as failed in the Network Map display.
* Pool member is disabled - the pool member itself is not shown as disabled; the parent node is.
* Node monitor failed - no monitor failure is indicated; the node ' s administrative state is explicitly disabled.
Understanding the node-to-member inheritance of availability state is fundamental to accurate BIG-IP traffic troubleshooting.
Reference: BIG-IP Administration - Data Plane Configuration, Module: Pool Members, Nodes, and Availability State Inheritance.
