| Section | Objectives |
|---|---|
| Topic 1: Special Inspection Requirements | - Inspector duties and responsibilities - Special inspection procedures for tall mass timber buildings - Inspection of connections and protective materials |
| Topic 2: Code Compliance and Related Requirements | - Sound transmission requirements - Documentation and verification of compliance - Energy code requirements applicable to mass timber buildings |
| Topic 3: Structural Inspection | - Connections and fastening systems - Structural loads and related code requirements - Mass timber structural elements |
| Topic 4: Fire Protection and Fire-Resistance | - Noncombustible protection and protection of mass timber elements - Fire-resistance requirements - Fire protection systems and related provisions |
| Topic 5: Construction Fire Safety | - Protection of mass timber during construction - International Fire Code requirements - Construction-phase fire safety requirements |
| Topic 6: Tall Mass Timber Building Code Provisions | - Mass timber materials and construction requirements - Types IV-A, IV-B and IV-C construction - International Building Code requirements for tall mass timber construction |
>> 93-Tall-Mass-Timber-Buildings Latest Dumps Sheet <<
We believe that the best brands are those that go beyond expectations. They don't just do the job – they go deeper and become the fabric of our lives. Therefore, our company as the famous brand, even though we have been very successful we have never satisfied with the status quo, and always be willing to constantly update the contents of our 93-Tall-Mass-Timber-Buildings Exam Torrent in order to keeps latest information about 93-Tall-Mass-Timber-Buildings exam.
NEW QUESTION # 61
Based on the definition of cross-laminated timber (CLT), panels are manufactured as follows:
Answer: A
Explanation:
The 2021 IBC definition of cross-laminated timber describes a prefabricated engineered wood product consisting of not less than three layers of solid-sawn lumber or structural composite lumber. The adjacent layers are cross oriented and bonded with structural adhesive to form a solid wood element. Accordingly, option C is correct.
Cross orientation means that the principal grain direction of one layer is arranged approximately perpendicular to that of the adjoining layer. This configuration distinguishes CLT from products in which all laminations run parallel, such as conventional glued-laminated timber. The cross-oriented layup provides two- way panel behavior, dimensional stability, and structural capacity in both principal directions.
Option A is incorrect because CLT must contain at least three layers. Option B describes a mechanically laminated product rather than structural glued CLT; nail-laminated timber uses mechanical fasteners, whereas code-compliant CLT uses structural adhesives and must conform to the applicable manufacturing standard.
Option D eliminates the defining cross-lamination characteristic and would instead describe a parallel- laminated product.
During inspection, the product label and certification documentation should be checked to confirm the panel was manufactured under the required quality-assurance program.
References/Topics: 2021 IBC Chapter 2 definition of "Cross-Laminated Timber"; Sections 602.4 and
2303.1.4; ANSI/APA PRG 320.
NEW QUESTION # 62
Refer to the exhibit by clicking on the EXHIBIT button above.
In the detail shown, if the connections at the glulam beam and the steel plate required a fire-resistance rating of one (1) hour and the wood cover is designed per AWC Technical Report 10 to provide the entire one (1) hour of protection, the minimum required thickness for the wood block member providing protection for the bolt connections is _____ inches.
Answer: C
Explanation:
The required minimum wood protection thickness is 1.75 inches , making option B correct. AWC Technical Report No. 10 establishes a thermal-separation methodology for protecting steel connectors and fasteners with sacrificial wood cover. Because the question specifies that the wood cover itself must provide the entire 60- minute fire-protection period, the protection thickness must be calculated using the thermal-separation provisions rather than relying on residual fire resistance from the connector or steel plate.
TR10 applies a reduction to the protection contribution of the base wood layer. Its connection examples use the relationship in Section 4.4.1.3, with the required thermal protection time divided by 0.85. For a 60-minute requirement, back-calculating the prescribed nonlinear wood charring equation gives approximately 1.71 inches of required wood thickness. The practical minimum corresponding to the available choices is therefore
1.75 inches.
The principle is critical for special inspection: steel connection components have high thermal conductivity and must remain below the temperature limits assumed by the connection fire design. The inspector must verify actual wood-cover thickness, fastening, continuity, and any gaps before concealment.
References/Topics: AWC Technical Report No. 10, Sections 4.4.1.3 and 4.5; connection thermal separation; wood protection of steel connectors. TR10 demonstrates the same calculation methodology for wood-covered steel connections.
NEW QUESTION # 63
All of the following combustible elements may be used in mass timber buildings except:
Answer: D
Explanation:
A conventional 2 × 6 solid-sawn stud is a light-frame member and does not satisfy the minimum cross- sectional dimensions associated with mass timber or heavy-timber construction. Therefore, option A is the exception.
The IBC defines mass timber as Type IV structural elements primarily composed of solid, built-up, panelized or engineered wood products that meet the minimum cross-sectional dimensions required for Type IV construction. A nominal 2 × 6 stud is substantially smaller than those dimensions and is ordinarily classified as conventional light-frame construction. Its use might be permitted in a particular nonstructural partition or another specifically authorized application, but it is not itself a qualifying mass timber structural element.
CLT is expressly recognized as a mass timber panel product. Parallel-strand lumber is a form of structural composite lumber and can qualify where it satisfies the applicable minimum dimensions, product-standard requirements and approved structural design. Dowel-laminated timber is a built-up panelized timber product and may likewise serve as a mass timber element when its dimensions, engineering and approval satisfy the construction documents and code.
The classification depends on the completed element's dimensions and approved structural function-not merely on the fact that it is manufactured from wood.
References/Topics: 2021 IBC Chapter 2 definitions of "Mass Timber" and "Conventional Light-Frame Construction"; Sections 602.4 and 2304.11.
NEW QUESTION # 64
What fire-resistance rating is required for Type IV-C exterior and interior bearing walls?
Answer: B
Explanation:
IBC Table 601 requires both exterior and interior bearing walls in Type IV-C construction to have a minimum two-hour fire-resistance rating. Option B is correct.
For exterior bearing walls, the Table 601 rating is not the only applicable criterion. Section 602.1 also requires exterior walls to satisfy Table 705.5 based on occupancy and fire separation distance. Where Table 705.5 or another provision imposes a more restrictive rating, the higher requirement governs.
The two-hour rating may be achieved through the calculated structural fire resistance of the mass timber, approved noncombustible protection, or an approved combination of the two. Connections, intersections, penetrations, and abutting edges must not create a premature failure path or compromise the rated assembly.
A one-hour reduction can be permitted for bearing walls supporting a roof only under Table 601, Footnote
"a," but that exception does not apply to a wall carrying floors or other qualifying structural loads. The inspector must confirm the actual load path before accepting any reduced protection at the uppermost level.
References/Topics: 2021 IBC Sections 601, 602.1 and 602.4; Tables 601 and 705.5; Type IV-C bearing walls.
NEW QUESTION # 65
The maximum allowable height for a Group E building of Type IV-A construction with an automatic sprinkler system in accordance with Section 903.3.1.1 is _____ stories.
Answer: C
Explanation:
The controlling provision is 2021 IBC Section 504.4 and Table 504.4, which establish the allowable number of stories above grade plane according to occupancy classification, construction type, and sprinkler protection.
The question identifies three controlling variables: Group E occupancy, Type IV-A construction, and an NFPA 13 automatic sprinkler system installed in accordance with Section 903.3.1.1.
In the Group E row, the sprinklered "S" value for Type IV-A construction is nine stories above grade plane.
Therefore, option D is correct. The three-story value applies to the nonsprinklered Type IV-A condition and must not be used because the question expressly states that the building is sprinklered. The six-story value corresponds to Type IV-B construction under the same sprinklered Group E condition, while the four-story value-although not listed as an answer-would apply to Type IV-C.
The special inspector should distinguish the story limitation in Table 504.4 from the separate building-height- in-feet limitation in Table 504.3. Both requirements apply concurrently; compliance with one does not permit the other to be exceeded.
References/Topics: 2021 IBC Section 504.4; Table 504.4, Group E, sprinklered Type IV-A construction; Section 903.3.1.1.
