| Section | Weight | Objectives |
|---|---|---|
| Network Observability | 10% | - Layer 7 visibility and flow monitoring - Hubble UI and troubleshooting basics - Hubble architecture and CLI usage |
| Cluster Mesh | 10% | - Cross-cluster load balancing and failover - Multi-cluster connectivity and service discovery |
| Service Mesh | 16% | - Sidecar vs sidecarless architecture - Transparent traffic encryption - Ingress and Gateway API integration |
| Network Policy | 18% | - Cilium vs Kubernetes network policies - Identity-aware and L3–L7 policy models - Policy enforcement modes |
| Architecture | 20% | - CNI integration and kube-proxy replacement - Cilium core architecture and components |
| BGP and External Networking | 6% | - External gateway integration - BGP peering and service advertisement |
| eBPF | 10% | - eBPF fundamentals and relevance to Cilium - eBPF-based networking, security, and observability |
| Installation and Configuration | 10% | - Deployment methods (Helm, cilium-cli) - Post-install validation and connectivity testing |
>> Practice Linux Foundation Cilium-Associate Mock <<
Compared with the other products in the market, our Cilium-Associate latest questions grasp of the core knowledge and key point of the real exam, the targeted and efficient Cilium Certified AssociateCCA study training dumps guarantee our candidates to pass the test easily. Passing exam won’t be a problem anymore as long as you are familiar with our Cilium-Associate Exam Material (only about 20 to 30 hours practice). High accuracy and high quality are the reasons why you should choose us.
NEW QUESTION # 46
Which of these observability features is NOT supported by Hubble?
Answer: D
Explanation:
Technical explanation
Hubble does not obtain Layer 7 protocol visibility exclusively through eBPF without a proxy. By default, Cilium's datapath exposes Layer 3 and Layer 4 flow information. To produce supported application-layer events, traffic is selected through an L7 Cilium policy and redirected to the node-local Envoy proxy. Envoy parses the application protocol and forwards access-log information that Cilium and Hubble expose as Layer
7 flow events.
The other capabilities are supported. Hubble flow records contain the observing node, and the CLI provides node-based filtering. HTTP-aware flows can contain response status codes, enabling inspection or filtering for results such as 200 and 404. Hubble also records forwarding verdicts and drop reasons. Operators can filter for DROPPED traffic and distinguish policy-denied connections from forwarded traffic and other failure conditions.
This separation is fundamental to Cilium's architecture: eBPF provides efficient kernel-level forwarding, security enforcement, and L3/L4 observability, while Envoy supplies protocol parsing when request-level context is required. The integration remains transparent to applications, but the proxy is still present in the traffic path for Layer 7 visibility.
Therefore, B describes the unsupported mechanism and is the correct answer.
Official references
Layer 7 Protocol Visibility ; Envoy ; Hubble CLI .
Study Guide topic: Network Observability.
NEW QUESTION # 47
When using Cilium with the kube-proxy replacement enabled, which underlying technology is effectively replaced with eBPF?
Answer: B
Explanation:
Technical explanation
Kubernetes kube-proxy conventionally implements Service translation and load balancing through either iptables or IPVS. With Cilium's kube-proxy replacement enabled, eBPF programs and maps perform Kubernetes Service handling directly in the kernel, including ClusterIP, NodePort, LoadBalancer, ExternalIP, and related service translation functions. C is therefore correct.
The replacement can operate at socket hooks and packet-processing hooks. Service and backend information is stored in eBPF maps, allowing the datapath to select backends and perform address translation without traversing the kube-proxy-generated iptables or IPVS rules normally used for Kubernetes Services.
BGP is not replaced. Cilium's BGP Control Plane is a separate feature used to advertise routes and service addresses to external routers. Routing itself is also not eliminated; Cilium can implement and accelerate routing decisions with eBPF, but packets still require a valid forwarding model. firewalld is a host firewall- management service and is not the underlying Kubernetes Service implementation replaced by kube-proxy replacement.
Relevant installations must satisfy the kernel and device requirements for Cilium's eBPF service load- balancer functionality.
Official references
Kubernetes Without kube-proxy
Study Guide topic: kube-proxy replacement, eBPF service maps, iptables, and IPVS.
NEW QUESTION # 48
If you are required to block ingress traffic from external IPs for all pods in your cluster, which of the following network policies would be the best fit?
Answer: B
Explanation:
Technical explanation
A cluster-wide requirement is best implemented with CiliumClusterwideNetworkPolicy , whose correct resource spelling is CiliumClusterwideNetworkPolicy . Unlike a namespaced CiliumNetworkPolicy , this Cilium CRD is non-namespaced and can select endpoints across the entire cluster.
To deny external ingress for every Cilium-managed pod, a cluster-wide policy can use an empty endpointSelector and an ingressDeny rule selecting the world entity. Cilium defines world as network endpoints outside the cluster. An alternative allow-list construction can permit only the cluster entity, thereby excluding external sources, but an explicit deny rule usually communicates the requirement more directly.
A standard Kubernetes NetworkPolicy and a CiliumNetworkPolicy are namespaced, requiring repeated resources in every applicable namespace. CiliumGlobalPolicy is not a valid Cilium resource type. Although the option capitalizes "Wide" differently from the actual kind, D unmistakably identifies the intended cluster- scoped policy.
Official references
Cilium Deny Policies , Cilium Network Policy Types
Study Guide topic: Cluster-scoped policies, external traffic, and reserved entities.
NEW QUESTION # 49
Review the Cilium Network Policy in the YAML file.
It was deployed in the ns-cca namespace on cluster1
Cluster Mesh CiliumNetworkPolicy exhibit
Which statement Is correct?
Answer: C
Explanation:
Technical explanation
The policy's endpointSelector selects the ship workload in the namespace containing the CiliumNetworkPolicy , which is ns-cca . It also explicitly includes io.cilium.k8s.policy.cluster: cluster1 , confirming that the selected source endpoint belongs to cluster1.
The egress rule authorizes communication to an endpoint carrying name: base and the cluster label io.cilium.
k8s.policy.cluster: cluster2 . Because the namespaced policy does not specify a different destination namespace through k8s:io.kubernetes.pod.namespace , the intended destination is the corresponding base workload in ns-cca on cluster2. Therefore, A matches the policy.
Options C and D incorrectly describe the rule as a deny rule. Cilium policy rules use an allow-list model unless an explicit egressDeny or ingressDeny section is present. The exhibit contains an ordinary egress rule, so matching traffic is authorized. Option B incorrectly places the destination in default .
Current Cilium versions require explicit cluster targeting for remote endpoints, which this policy provides through the cluster label.
Official references
Cluster Mesh Network Policy , Namespaces in Cilium Policy
Study Guide topic: Cluster Mesh labels, namespaced policies, and cross-cluster endpoint selection.
NEW QUESTION # 50
What is the correct statement about the masquerading feature?
Answer: C
Explanation:
Technical explanation
Masquerading performs source network address translation for qualifying traffic that leaves the cluster.
Because pod addresses are often private and not routable by the external network, Cilium replaces the pod's source address with an address belonging to the egress node. Return traffic can then reach that node, which reverses the translation and delivers the response to the originating pod. B correctly summarizes this behavior.
Masquerading is a form of SNAT, not DNAT. DNAT modifies the destination address, commonly to direct incoming traffic toward another endpoint, so C is incorrect.
Cilium documents its eBPF-based masquerading implementation as the more efficient implementation. The iptables version is the legacy alternative, making A false. Conversely, eBPF masquerading depends on appropriate kernel eBPF capabilities and Cilium's BPF NodePort functionality. It cannot be assumed to work on every kernel version, so D is false. The legacy iptables implementation is the mode documented as broadly working across kernel versions.
Cilium can exclude natively routable CIDRs from masquerading, and administrators may configure separate IPv4 and IPv6 masquerading behavior.
Official references
Cilium Masquerading , Cilium System Requirements
Study Guide topic: SNAT, native-routing exclusions, and eBPF versus iptables masquerading.
NEW QUESTION # 51
......
