질문 # 20
A new SD-WAN branch has completed factory-default onboarding and Versa Director has pushed the staging configuration. After reboot, the branch still tries to connect to the staging server instead of the Controller.
Which configuration item is most likely incorrect or missing in the stage-two configuration?
정답：A
설명：
The correct answer is A . During Versa SD-WAN onboarding, the branch uses the staging server only in the early part of the process. Versa documentation states that in Stage 1 , the branch starts an IKE session with the staging server, receives an IP address, and is informed of the Versa Director IP address. In Stage 2 , Versa Director pushes the stage-two configuration to the branch through the staging server. In this stage-two configuration, the Controller IP address is given as the remote IP address in the IPsec profile , and the branch is rebooted. After reboot, the branch should establish the IKE session with the Controller.
If the branch keeps trying to connect to the staging server after the stage-two reboot, the most likely issue is that the stage-two IPsec profile still points to the staging server or does not contain the correct Controller remote IP. Analytics, DHCP, and URL filtering settings do not determine whether the branch moves from staging-server connectivity to Controller IKE connectivity.
질문 # 21
Examine the exhibit below.
An SD-WAN administrator has configured Direct Internet Access (DIA) for INET and INET-2 and wants to use SaaS Application Monitoring and SD-WAN policies to steer certain applications to the best Internet path on a certain VOS device.
Which two statements are true regarding the configuration shown in the exhibit? (Choose two.)
정답：B,D
설명：
The correct answers are B and D . In the exhibit, the Next-Hop Selection Method is configured as Load Balance , and both INET and INET-2 have the same next-hop priority value of 1 . Versa SD-WAN guidance states that load balancing between WAN paths is achieved by configuring at least two circuits with equal priority. Therefore, when both INET and INET-2 satisfy the SLA requirements, sessions can be load-balanced across those two internet circuits.
Option D is also correct because the exhibit shows SLA Violation Action: Forward . This means that if no next hop is SLA-compliant, the VOS device is still allowed to forward traffic instead of dropping it. This behavior is consistent with Versa SD-WAN traffic-steering concepts, where forwarding profiles define circuit or path priorities, connection methods, load-balancing behavior, and SLA handling for traffic that matches an SD-WAN policy.
Option A is incorrect because the exhibit does not use the Automatic next-hop selection method. Versa' s performance-based SaaS optimization uses monitoring metrics to select the best path when configured for automatic/performance-based selection, but this exhibit shows Load Balance instead. Option C is not the best answer because LTE has lower priority 2 and would be considered only after the higher- priority INET and INET-2 paths are unavailable or unusable, not merely when one INET circuit fails.
질문 # 22
Which two methods would be used to upgrade deployed VOS branch devices? (Choose two.)
정답：B,C
설명：
The correct answers are A and C . Versa supports upgrading deployed VOS branch devices either directly on the VOS appliance or centrally through Versa Director. The Director-based method is performed from the Administration > Appliances area: Versa documentation says to select one or more Controller nodes or VOS devices, click the Upgrade Selected Appliances icon, choose the software image package, and proceed with the appliance upgrade. The same upgrade procedure is referenced for remaining VOS branch devices, including the option to upgrade branches individually or all at once.
A CLI-based upgrade using a software .bin package is also a valid operational method when the image is copied to the device and installed locally, particularly for controlled or recovery-style maintenance.
Option B is not the best answer for already deployed branch upgrades because the Preferred Software Version field applies to zero-touch provisioning; Versa states that during ZTP, Director upgrades a branch to the preferred version if applicable. That setting influences onboarding behavior, not the normal upgrade workflow for already deployed branches. Option D is incorrect because System > Director Upgrade is used to upgrade the Versa Director node itself, not VOS branch appliances.
질문 # 23
You need to determine the VOS image currently running on a branch CPE before scheduling a software upgrade. Which command provides this information?
정답：C
설명：
The correct answer is A . Versa's handy troubleshooting CLI command reference lists show system package- info as the command used to view information about the VOS software image running on the CPE .
This command is useful before upgrade planning because it confirms the installed software package and helps validate whether the device is on the expected release. Administrators can compare the running version against the target upgrade image, verify upgrade prerequisites, and ensure that branch and Controller releases are compatible with required features such as internet speed testing, SD-WAN policy behavior, or security services.
show system uptime only tells how long the system has been running. show interfaces brief provides operational and administrative interface status, MAC address, tenant, VRF, and IP address information. show class-of-services interfaces brief helps troubleshoot QoS or shaping behavior. None of those commands directly identifies the VOS software package. Therefore, for checking the running image before an upgrade, the correct command is show system package-info.
질문 # 24
You need to quickly check interface administrative status, operational status, tenant ID, VRF, MAC address, and IP address on a VOS device. Which command should you use?
정답：D
설명：
The correct answer is A . Versa's handy CLI command reference lists show interfaces brief as the command used to view a list of interfaces along with their MAC addresses, operational and administrative status, tenant ID, VRF, and IP addresses. This is one of the first commands administrators run when validating device bring- up, staging interface assignment, WAN/LAN mapping, or whether a template applied interface addressing as expected.
For deeper interface troubleshooting, show interfaces detail provides additional information such as interface index, host interface, MTU, speed and duplex settings, RX/TX errors, and bridge information. However, for a quick overview of state and addressing across interfaces, show interfaces brief is the correct choice.
show system package-info identifies the running VOS software package. show system storage reports system storage resources. show coredumps shows generated core files. These are valuable operational commands, but they do not provide the requested interface status and addressing summary.
질문 # 25
......
