NEW QUESTION # 71
A BIG-IP system receives a client connection destined to 1.0.0.10:8080. Multiple virtual servers are configured on the system. Which virtual server will process the connection? (Choose one answer)
Answer: C
Explanation:
Comprehensive and Detailed Explanation From BIG-IP Administration Data Plane Concepts documents:
BIG-IP uses a virtual server matching and precedence algorithm to determine which virtual server processes an incoming connection. This decision is made entirely in the data plane and is based on how specifically a virtual server matches the destination IP address and port.
BIG-IP Virtual Server Selection Rules (Simplified):
When multiple virtual servers could match a packet, BIG-IP selects the most specific match, using the following precedence:
Exact IP address and exact port
Exact IP address with wildcard port (port 0 / any)
Wildcard IP address with exact port
Wildcard IP address and wildcard port
Applying the Rules to This Scenario:
Incoming traffic destination: 1.0.0.10:8080
Option C: 1.0.0.10:8080
Exact IP match
Exact port match
Highest possible specificity
If the virtual server is available (green), it wins the match
Option B: 1.0.0.10:any
Exact IP match, but wildcard port
Lower priority than an exact IP + exact port match
Option D: 0.0.0.0:8080
Wildcard IP, exact port
Lower priority than an exact IP match
Option A: 0.0.0.0:any
Wildcard IP and wildcard port
Lowest priority, used only if no more specific virtual server exists
Final Determination:
Because a virtual server configured with destination 1.0.0.10:8080 exactly matches both the IP address and port of the incoming connection-and is available-it will always be selected to process the traffic.
Key Data Plane Concept Reinforced:
BIG-IP always processes traffic using the most specific matching virtual server. Exact destination IP and port matches take precedence over any wildcard or forwarding virtual server definitions.
NEW QUESTION # 72
What type of Virtual Server is configured with no Pool-members, and proxies traffic to the destination IP address specified by the client device?
Answer: B
NEW QUESTION # 73
Active connections to pool members are unevenly distributed. The load balancing method is Least Connections (member). Priority Group Activation is disabled.
What is a potential cause of the uneven distribution? (Choose one answer)
Answer: C
Explanation:
With Least Connections (member), BIG-IP attempts to send new connections to the pool member with the fewest current connections. In a perfectly "stateless" scenario (no affinity), this often trends toward a fairly even distribution over time.
However, persistence overrides load balancing:
When a persistence profile is applied, BIG-IP will continue sending a client (or client group) to the same pool member based on the persistence record (cookie / source address / SSL session ID, etc.).
This means even if another pool member has fewer connections, BIG-IP may still select the persisted member to honor session affinity.
The result can be uneven active connection counts, even though the configured load balancing method is Least Connections.
Why the other options are not the best cause:
A . Priority Group Activation is disabled
Priority Group Activation only affects selection when priority groups are configured; disabling it does not inherently create uneven distribution under Least Connections.
B . SSL Profile Server is applied
A server-side SSL profile affects encryption to pool members, but it does not by itself cause skewed selection across pool members. (Skew could happen indirectly if members have different performance/latency, but that's not the primary, expected exam answer.) D . Incorrect load balancing method Least Connections is a valid method and does not itself explain unevenness unless something is overriding it (like persistence) or pool members are not all eligible.
Conclusion:
A persistence profile is the most common and expected reason that active connections become unevenly distributed, because persistence takes precedence over the Least Connections load-balancing decision.
NEW QUESTION # 74
Refer to the exhibit.
The network team creates a new VLAN on the switches. The BIG-IP Administrator creates a new VLAN and a Self IP on the BIG-IP device, but the servers on the new VLAN are NOT reachable from the BIG-IP device.
Which action should the BIG-IP Administrator take to resolve this issue? (Choose one answer)
Answer: D
Explanation:
For BIG-IP to send or receive traffic on a VLAN, that VLAN must be bound to a physical interface or a trunk. Creating a VLAN object and a Self IP alone is not sufficient to establish data-plane connectivity.
From the exhibit:
* The VLAN (vlan_1033) exists and has a tag defined.
* A Self IP is configured and associated with the VLAN.
* However, traffic cannot reach servers on that VLAN.
This indicates a Layer 2 connectivity issue, not a Layer 3 or HA issue.
Why assigning a physical interface fixes the problem:
* BIG-IP VLANs do not carry traffic unless they are explicitly attached to:
* A physical interface (e.g., 1.1), or
* A trunk
* Without an interface assignment, the VLAN is effectively isolated and cannot transmit or receive frames, making servers unreachable regardless of correct IP addressing.
Why the other options are incorrect:
* A. Set Port Lockdown to Allow AllPort Lockdown controls which services can be accessed on the Self IP (management-plane access), not whether BIG-IP can reach servers on that VLAN.
* B. Change Auto Last Hop to enabledAuto Last Hop affects return traffic routing for asymmetric paths. It does not fix missing Layer 2 connectivity.
* D. Create a Floating Self IP addressFloating Self IPs are used for HA failover. They do not resolve reachability issues on a single device when the VLAN itself is not connected to an interface.
Conclusion:
The servers are unreachable because the VLAN has no physical interface assigned. To restore connectivity, the BIG-IP Administrator must assign a physical interface (or trunk) to the VLAN, enabling Layer 2 traffic flow.
NEW QUESTION # 75
A BIG-IP Administrator assigns the default http health monitor to a pool that has three members listening on port 80. When the administrator connects to each pool member via the CURL utility, two of the members respond with a status of 404 Not Found while the third responds with 200 OK. What will the pool show for member availability?
Answer: D
Explanation:
The behavior of a health monitor is determined by itsSend StringandReceive String.
* Default HTTP Monitor:The pre-configured default HTTP monitor on a BIG-IP system has an empty Receive String.
* Success Criteria:When the Receive String is blank, the BIG-IP system considers the health check successful if it receivesany valid HTTP responsefrom the server.
* Status Code Interpretation:Because a 404 Not Found is a valid HTTP status code (it is a properly formatted response from a running web server process), the BIG-IP interprets this as the application being "alive".
* Result:All three members (including the two returning 404s and the one returning 200) will be marked asUP/Available(Green).
NEW QUESTION # 76
......
