質問 # 10
A network administrator is planning to add a trunk to a single BIG-IP system. What does a trunk provide?
(Pick the 2 correct responses below)
正解：A、D
解説：
In the F5 BIG-IP ecosystem, atrunkis a logical grouping of two or more physical interfaces that the system treats as a single data path. This configuration is based on the Link Aggregation Control Protocol (LACP) or static link aggregation.
Trunks provide two primary benefits to the data plane:
* Increased Bandwidth:By aggregating multiple physical interfaces (e.g., combining two 10Gbps interfaces), the aggregate throughput of the logical connection is increased. This allows the BIG-IP to handle higher traffic volumes than a single interface could support.
* Link Redundancy:Trunks provide high availability at the physical layer. If one physical interface within the trunk fails or the cable is disconnected, the BIG-IP system automatically redistributes traffic across the remaining active interfaces in the trunk. This prevents a single cable or port failure from causing a network outage.
Why the other options are incorrect:
* Option C:While VLAN tags are often usedontrunks, the ability to use tagged VLANs is a property of theVLANconfiguration and 802.1Q tagging, not the trunk itself. A single interface can support tagged VLANs without being part of a trunk.
* Option D:Trunks are agnostic to the type of application traffic (such as VoIP) passing through them.
They operate at Layer 2 to provide a reliable pipe for any Layer 3+ traffic.
質問 # 11
The diagram below shows the TCP connection setup for an application.
Which of the following virtual server types applies? (Choose one answer)
正解：B
解説：
The diagram illustrates a specific TCP handshake sequence where the BIG-IP system acts as a transparent forwarder rather than a full proxy. The key indicators that identify this as a Forwarding (IP) virtual server are as follows:
* Initial Packet Processing: The diagram explicitly states that the LTM evaluates the packet looking only at the destination IP address. This is the fundamental characteristic of a Forwarding IP virtual server, which uses the system's routing table to make forwarding decisions instead of load balancing to a pool of members.
* Handshake Sequence: Unlike a Standard virtual server, which completes the three-way handshake with the client (SYN, SYN-ACK, ACK) before initiating a separate connection to the server, the Forwarding IP virtual server passes the client's original SYN packet directly to the destination node.
* Response Timing: The BIG-IP system waits for the SYN-ACK from the destination node before it sends a SYN-ACK back to the client. It essentially "passes through" the handshake signals while still maintaining a state entry in the connection table to track the flow.
* Packet-by-Packet Logic: While it tracks the state, it does not perform address translation (unless SNAT is specifically configured) or deep packet inspection like a full proxy would.
Why other options are incorrect:
* Standard virtual server: A Standard virtual server is a "full proxy." It would finish the handshake with the client first and only then open a second, independent TCP connection to the backend server.
* Stateless virtual server: A stateless virtual server does not track connections in the connection table.
The diagram shows the system meticulously passing sequence numbers ($seq\_num$) and acknowledgment numbers ($ack\_num$) between the two sides, which requires stateful tracking of the TCP flow.
質問 # 12
A BIG-IP Administrator is making adjustments to an iRule and needs to identify which of the 235 virtual server configured on the BIG-IP device will be affected. How should the administrator obtain this information in an effective way? (Choose one answer)
正解：D
解説：
In a large-scale BIG-IP environment with hundreds of virtual servers, the Network Map is the most effective tool for visualizing and auditing the relationships between various ADC objects.
* The Network Map Functionality: The Network Map provides a hierarchical view of the local traffic objects. It allows an administrator to see the status and dependencies of Virtual Servers, Pools, Pool Members, and associated iRules all in one screen.
* Search and Filter: By navigating to Local Traffic > Network Map, the administrator can use the Advanced Filter. This feature allows for searching specifically for an iRule name or a string within an iRule definition. Once the filter is applied, the system displays only the Virtual Servers that are associated with that specific iRule.
* Efficiency: While the "Virtual Server List" (Option D) can be customized to show columns for iRules, it is often cumbersome to scroll through hundreds of entries. The "iRules List" (Option B) displays the scripts themselves but does not provide a reverse-lookup list of all associated virtual servers in a single view as efficiently as the Network Map.
* Summary of Relationships: The Network Map is specifically designed to answer the question, "What is this object connected to?" making it the primary administrative interface for impact analysis during configuration changes.
質問 # 13
The BIG-IP Administrator needs to ensure that if a pool member is marked down by the monitor, the BIG-IP system sends existing connections to another available pool member. Which task should the BIG-IP Administrator perform to meet this goal?
正解：A
解説：
By default, when a pool member is marked "down" by a monitor, the BIG-IP system stops sendingnew connections to that member, but it typically allows existing connections to time out naturally (or resets them depending on profile settings).
* Action on Service Down:This setting is configured at thePoollevel.
* Reselect:When set toReselect, if a pool member is marked down, the BIG-IP system will immediately attempt to pick a different available pool member for any existing, active connections associated with the failed member.
* Client Experience:This is used to maintain the user session by transparently moving the traffic to a healthy server without the client needing to re-establish the connection to the Virtual Server.
質問 # 14
What is the result when a BIG-IP Administrator manually disables a pool member? (Choose one answer)
正解：C
解説：
In BIG-IP LTM, a pool member state directly affects how traffic is handled at the data plane level. When a pool member is manually disabled, BIG-IP changes the member's availability state to disabled, which has specific and predictable traffic-handling consequences.
According to BIG-IP Administration Data Plane Concepts:
* A disabled pool member:
* Does not accept new connections
* Continues to process existing non-persistent connections until they naturally close
* Is removed from load-balancing decisions, including persistence lookups Most importantly for this question:
* Persistent connections (such as those created using source-address persistence, cookie persistence, or SSL persistence) are not honored for a disabled pool member
* BIG-IP will not send new persistent traffic to a disabled member, even if persistence records exist Therefore, when a pool member is manually disabled, it stops processing persistent connections, while allowing existing non-persistent flows to drain gracefully.
Why the Other Options Are Incorrect:
* B - Persistent connections are not honored for a disabled pool member
* C - Existing connections are not immediately terminated when a pool member is disabled
* D - Only the disabled pool member stops accepting new connections, not all pool members Key Data Plane Concept Reinforced:
Manually disabling a pool member is a graceful administrative action that prevents new and persistent traffic from reaching the member while allowing existing connections to complete, which is critical for maintenance and troubleshooting scenarios.
質問 # 15
......
