Due to extremely high competition, passing the BIG-IP Administration Data Plane Concepts (F5CAB2) (F5CAB2) exam is not easy; however, possible. You can use Pass4sures products to pass the BIG-IP Administration Data Plane Concepts (F5CAB2) (F5CAB2) exam on the first attempt. The BIG-IP Administration Data Plane Concepts (F5CAB2) (F5CAB2) practice exam gives you confidence and helps you understand the criteria of the testing authority and pass the BIG-IP Administration Data Plane Concepts (F5CAB2) (F5CAB2) exam on the first attempt.
| Certification Vendor: | F5 |
|---|---|
| Exam Name: | BIG-IP Administration Data Plane Concepts |
| Exam Number: | F5CAB2 |
| Available Languages: | English |
| Related Certifications: | F5 Certified Administrator, BIG-IP (F5-CA) |
| Exam Duration: | 30 minutes |
| Passing Score: | Pass/Fail (Scaled scoring, specific threshold not publicly disclosed per sub-exam) |
| Real Exam Qty: | 30 |
| Exam Format: | Multiple Choice, Scenario-based |
| Exam Price: | $50 USD |
| Sample Questions: | F5 F5CAB2 Sample Questions |
| Exam Way: | Online (Pearson VUE) |
| Pre Condition: | None specified. It is one of five exams required for the F5 Certified Administrator, BIG-IP credential. |
| Official Syllabus URL: | https://education.f5.com/courses/1089 |
>> Valid F5CAB2 Test Answers <<
Our company committed all versions of F5CAB2 practice materials attached with free update service. When F5CAB2 exam preparation has new updates, the customer services staff will send you the latest version. So we never stop the pace of offering the best services and F5CAB2 practice materials for you. And we offer you the free demo of our F5CAB2 Learning Materials to check the quality before payment. Tens of thousands of candidates have fostered learning abilities by using our F5CAB2 Learning materials you can be one of them definitely.
| Topic | Details |
|---|---|
| Topic 1 |
|
| Topic 2 |
|
| Topic 3 |
|
NEW QUESTION # 67
Refer to the exhibit above.
A BIG-IP pool is configured with Priority Group Activation = Less than 2 available members. The pool members have different priority groups and availability states. Which pool members are receiving traffic?
(Choose one answer)
Answer: C
Explanation:
This question tests understanding of Priority Group Activation (PGA) and how BIG-IP determines which pool members are eligible to receive traffic.
Key BIG-IP Priority Group Concepts:
* Higher priority group numbers = higher priority
* BIG-IP will only send traffic to the highest priority group that meets the Priority Group Activation condition
* Lower priority groups are activated only when the condition is met
* Only available (green) members count toward the activation threshold
Configuration from the Exhibit:
* Priority Group Activation: Less than 2 available members
* Pool Members and Status:
Pool Member
Priority Group
Status
serv1
2
Active (available)
serv2
2
Inactive (down)
serv3
1
Active (available)
serv4
1
Active (available)
Step-by-Step Traffic Decision:
* BIG-IP first evaluates the highest priority group (Priority Group 2)
* Priority Group 2 has:
* serv1 # available
* serv2 # unavailable
* Total available members = 1
* Activation rule is Less than 2 available members
* Condition is true (1 < 2)
* BIG-IP activates the next lower priority group (Priority Group 1)
* Traffic is now sent to:
* serv1 (Priority Group 2)
* serv3 and serv4 (Priority Group 1)
Final Result:
Traffic is distributed to serv1, serv3, and serv4
Why the Other Options Are Incorrect:
* A - Ignores activation of the lower priority group
* B - serv4 is also active and eligible
* C - serv2 is down and cannot receive traffic
Key Data Plane Concept Reinforced:
Priority Group Activation controls when lower-priority pool members are allowed to receive traffic, based strictly on the number of available members in the higher-priority group. In this case, the failure of one high-priority member caused BIG-IP to expand traffic distribution to lower-priority members to maintain availability.
NEW QUESTION # 68
Which virtual server type is being configured in the screenshot? (Choose one answer.)
Answer: A
Explanation:
The configuration shown matches a Performance Layer 4 virtual server because it is explicitly using a FastL4 profile:
* The screenshot shows Protocol: TCP and Protocol Profile (Client): fastL4.In BIG-IP data plane terms, FastL4 is the hallmark of a Performance (Layer 4) virtual server, designed to process connections at Layer 4 with minimal overhead (high throughput/low latency) compared to full proxy L7 processing.
* The screenshot also shows HTTP Profile (Client): None (and HTTP server profile effectively not in use).A Standard virtual server commonly uses full-proxy features and frequently includes L7 profiles (like HTTP) when doing HTTP-aware load balancing, header manipulation, cookie persistence, etc. In contrast, a Performance L4 virtual server typically does not use an HTTP profile because it is not doing HTTP-aware (Layer 7) processing.
* It is not a Forwarding IP virtual server:A Forwarding (IP) virtual server is used to route/forward packets (often without load balancing to pool members in the same way as Standard/Performance VS) and is selected by choosing a forwarding type. The presence of a TCP protocol with a FastL4 client profile aligns with a Layer 4 load-balancing style virtual server, not a packet-forwarding virtual server type.
Conclusion: Because the configuration is TCP-based and explicitly uses fastL4 with no HTTP profile, the expected BIG-IP virtual server type is Performance Layer 4 (Option C).
NEW QUESTION # 69
An ecommerce company is experiencing latency issues with online shops during Black Friday's peak season. The BIG-IP Administrator detects an overall high CPU load on the BIG-IP device and wants to move the top utilized Virtual Servers to a dedicated BIG-IP device. Where should the BIG-IP Administrator determine the problematic Virtual Servers? (Choose one answer)
Answer: B
Explanation:
Comprehensive and Detailed Explanation From BIG-IP Administration Data Plane Concepts documents:
When troubleshooting performance and latency issues on BIG-IP, especially under peak load conditions, it is critical to identify which Virtual Servers are consuming the most resources. This is a core data plane analysis task.
BIG-IP provides multiple views of configuration and status, but only certain areas expose real-time and historical traffic statistics that correlate directly with CPU usage and throughput.
Why Option C Is Correct:
Statistics > Module Statistics > Local Traffic > Virtual Servers provides:
Real-time and cumulative statistics per Virtual Server
Metrics such as:
Bits in / Bits out
Packets in / Packets out
Current connections
Connection rate
Total requests
The ability to identify high-traffic or high-connection Virtual Servers, which are the most likely contributors to elevated CPU utilization These statistics allow the administrator to objectively determine which Virtual Servers are the top consumers of system resources and therefore good candidates for migration to a dedicated BIG-IP device.
Why the Other Options Are Incorrect:
A . Local Traffic > Virtual Servers > Virtual Server List
Primarily a configuration view
Does not provide sufficient performance or utilization statistics to identify CPU-heavy Virtual Servers B . System > Platform Displays hardware-level information such as CPU cores, memory, disk, and platform type Does not break down utilization by Virtual Server D . Local Traffic > Network Map Provides a logical topology view of Virtual Servers, pools, and pool members Useful for understanding relationships, but not for identifying high-utilization Virtual Servers Key Data Plane Concept Reinforced:
To diagnose performance problems and plan traffic redistribution, BIG-IP administrators must rely on Module and object-level statistics, not configuration screens. The Virtual Server statistics view is the authoritative location for identifying traffic hotspots that directly impact CPU and latency during peak events such as Black Friday.
NEW QUESTION # 70
The owner of a web application asks the BIG-IP Administrator to change the port that the BIG-IP device sends traffic to. This change must be made for each member in the server pool named app_pool for the Virtual Server named app_vs. In which area of the BIG-IP Configuration Utility should the BIG-IP Administrator make this change?
Answer: B
Explanation:
In the BIG-IP object hierarchy, the destination port for backend traffic is defined at thePool Memberlevel.
While a Virtual Server listens on a specific port, the Pool determines where that traffic is directed after the load balancing decision is made.
* Pools and Pool Members: A pool is a collection of devices, often called pool members, to which the BIG-IP system passes traffic. Each pool member is defined by an IP address and a service port.
* Port Translation: When an administrator needs to change the port the BIG-IP uses to communicate with backend servers, they must navigate to the specific Pool and modify the service port for each member within that pool.
* Logical Separation:
* Virtual Serversdefine the "front-end" port where clients connect.
* Poolsdefine the "back-end" port where the application resides.
* Nodesrepresent the physical server's IP address and do not contain port-specific configuration.
NEW QUESTION # 71
A BIG-IP Administrator assigns the default http health monitor to a pool that has three members listening on port 80. When the administrator connects to each pool member via the CURL utility, two of the members respond with a status of 404 Not Found while the third responds with 200 OK. What will the pool show for member availability?
Answer: D
Explanation:
The behavior of a health monitor is determined by itsSend StringandReceive String.
* Default HTTP Monitor:The pre-configured default HTTP monitor on a BIG-IP system has an empty Receive String.
* Success Criteria:When the Receive String is blank, the BIG-IP system considers the health check successful if it receivesany valid HTTP responsefrom the server.
* Status Code Interpretation:Because a 404 Not Found is a valid HTTP status code (it is a properly formatted response from a running web server process), the BIG-IP interprets this as the application being "alive".
* Result:All three members (including the two returning 404s and the one returning 200) will be marked asUP/Available(Green).
NEW QUESTION # 72
......
